FT415W Battery Powered Pulse Output, Wall Mount 96

Option Code(s) Description

32 Tamper-Evident Kit, Wire, Seal 1

64 Non-Resettable Total 7

126 Hinged Display Cover 3

Note: Use of Hinged Display Cover is recommended for all outdoor applications.

FT420W 12-24 Vdc, Pulse Output & 4-20 mA Outputs, Wall Mount 70

FT420P 12-24 Vdc, Pulse Output & 4-20 mA Outputs, Panel Mount 70

FT420W-27 12-24 Vdc,110 Vac Dual Power Supply, Hard Wired, Wall Mount 70

FT420W-65 12-24 Vdc, 110 Vac Single Power Supply, Hard Wired Wall Mount 43

Option Code(s) Description

32 Tamper-Evident Kit, Wire, Seal 1

64 Non-Resettable Total 7

98 Dual Relay Output 9

126 Hinged Display Cover 3

Note: Use of Hinged Display Cover is recommended for all outdoor applications.

Note: Option -32 & -126 not available with -27 or -65.

FT520 AC/DC Rate/Total/Batch Regeneration 98

Option Code(s) Description

84 Regeneration Control NC

86 Alarm Relay Output NC

121 220 Vac Input 39

Note: FT520 Cannot be meter mounted.

FT522 Usage Monitor, Wall/Panel Mount 98

Option Code(s) Description

121 220 Vac Input 39

Note: FT522 Cannot be meter mounted.

2014 Industrial  List V2 Page 6 January 01, 2014

Rev. 050114

FT415 Parts and Accessories

Model # Description

100373 Battery, Lithium, 3.6V, 8.5Ah, C Size 6

100411 Gasket, Upper Housing 3

100469 FT415 Replacement Module 91

100414 Screw/Washer Kit, Upper housing (Qty 4) 1

101850 Cord Grip, 1/2″ NPT 8

100364 Cord Grip 1/4″ I.D. 2

101949 Hinged Display Cover 7

FT420 Parts and Accessories

Model # Description

100557 PCA, FT420/421 Relay Option, w/ Wire and Tape 4

100411 Gasket, Upper Housing 3

100495 FT420 Replacement Module 65

100545 FT420-65 Replacement Module, For 110 Vac 73

100414 Screw/Washer Kit, Upper housing (Qty 4) 1

101850 Cord Grip, 1/2″ NPT 8

100364 Cord Grip 1/4″ I.D. 2

100018 Cord Grip, Large Cable, Black 8

103324 Strain Relief Kit, .069″ to .25″ Cable 2

101949 Hinged Display Cover 7

FT520 Parts & Accessories

Model # Description

101850 Cord Grip, 1/2″ NPT 8

2014 Industrial  List V2 Page 7 January 01, 2014

Rev. 050114

DL76 Data Logger

Model # Description

DL76W Data Logger, Wall Mount 55

DC3 Data Logger Cable, Serial 8

DC3S Data Logger Cable, Serial IP68 36

102513 Software, FlowInspector, Unlimited Licenses NC

Option Code(s) Description

32 Tamper-Evident Kit, Wire, Seal 1

DL76 Parts & Accessories

Model # Description

100373 Battery, Lithium, 3.6V, 8.5Ah, C Size 6

101480 DL76 Replacement Module 50

101245 DL76ME Replacement Module 50

100414 Screw/Washer Kit, Upper housing (Qty 4) 1

102177 Screw/Washer Kit, DL76ME 4

101850 Cord Grip, 1/2″ NPT 8

100364 Cord Grip 1/4″ I.D. 2

100853 Seal, Security, w/12″ of Wire

100854 Wire, for Security Seal, 12″

AO55 Analog Transmitter (4 to 20 mA)

Model # Description

AO55W Blind 4-20 mA Converter, Analog Transmitter, Wall Mount 70

Option Code(s) Description

06 LMI Pump 4-Pin Connector 0

106 Roytronics® Series-A Pump 5 Pin Connector 0

AO55 Parts & Accessories

Model # Description

100471 AO55 Replacement Module 65

100414 Screw/Washer Kit, Upper housing (Qty 4) 1

100364 Cord Grip 1/4″ I.D. 2

101850 Cord Grip, 1/2″ NPT 8

2014 Industrial  List V2 Page 8 January 01, 2014

Rev. 050114

PC-Series Power Converters

Model # Description

PC3 110-115 Vac, 24 Vdc, Unregulated 6

PC12 110-115 VAC, 12 VDC, Regulated 54

PC42 Dual Power Converter 110-115 Vac, 12-24 Vdc, Regulated 28

RSP5 Solar Panel

Model # Description

RSP5W Solar Panel Kit, 5 Watt 85

PT35 Counter Timer

Model # Description

PT35 Dual Counter/Timer, Feed & Bleed 00

PT35S Dual Counter/Timer, Feed & Bleed, Solid State Output 61

PT35 Parts & Accessories

Model # Description

100018 Cord Grip, Large Cable, Black 8

PD10 Pulse Divider

Model # Description

PD10W Pulse Divider, Wall Mount (Includes LMI 4 Pin Connector) 85

Option Code(s) Description

37 10 Ft. Cable for LMI Connector 2

106 Roytronics® Series-A Pump 5 Pin Connector 0

Note: If ordering a PD10W-106 the 5-Pin connector is substituted for the 4-Pin connector.

The 0 option  is not added.

PD10 Parts & Accessories

Model # Description

100470 PD10 Replacement Module 57

PS40 Pulse Splitter

Model # Description

PS40 Pulse Splitter, Single Input, 4 Outputs 62

Model # Description

EX810B Fixed Depth Insertion Magmeter, Brass, 1″-3″ 90

EX810P Fixed Depth Insertion Magmeter, PVC, 1″-3″ 98

EX810S Fixed Depth Insertion Magmeter, 316 SS, 1″-3″ 21

EX820B Fixed Depth Insertion Magmeter, Brass, 4″-10″ 19

EX820P Fixed Depth Insertion Magmeter, PVC, 4″-10″ 19

EX820S Fixed Depth Insertion Magmeter, 316 SS, 4″-10″ 97

EX830B Fixed Depth Insertion Magmeter, Brass, 12″ 87

EX830P Fixed Depth Insertion Magmeter, PVC, 12″ 80

EX830S Fixed Depth Insertion Magmeter, 316 SS, 12″ 83

Option Code(s) Description

15 Reverse Flow 49

40 Immersible 0

50 Low Power NC

125 Viton® O-Ring 6

EX801 Series Fixed Depth Insertion Magmeter (FT420 Meter Mount)

Model # Description

EX811B Fixed Depth Insertion Magmeter, Brass, 1″-3″, FT420 160

EX811P Fixed Depth Insertion Magmeter, PVC, 1″-3″, FT420 068

EX811S Fixed Depth Insertion Magmeter, 316 SS, 1″-3″, FT420 291

EX821B Fixed Depth Insertion Magmeter, Brass, 4″-10″, FT420 189

EX821P Fixed Depth Insertion Magmeter, PVC, 4″-10″, FT420 089

EX821S Fixed Depth Insertion Magmeter, 316 SS, 4″-10″, FT420 367

EX831B Fixed Depth Insertion Magmeter, Brass, 12″, FT420 257

EX831P Fixed Depth Insertion Magmeter, PVC, 12″, FT420 150

EX831S Fixed Depth Insertion Magmeter, 316 SS, 12″, FT420 453

Option Code(s) Description

15 Reverse Flow 49

32 Tamper-Evident Kit, Wire, Seal 1

50 Low Power NC

64 Non-Resettable Total 7

98 Dual Relay Output 9

125 Viton® O-Ring 6

126 Hinged Display Cover 3

2014 Industrial  List V2 Page 12 January 01, 2014

Rev. 050114

EX802 Series Fixed Depth Insertion Magmeter (AO55 Meter Mount)

Model # Description

EX812B Fixed Depth Insertion Magmeter, Brass, 1″-3″, AO55 060

EX812P Fixed Depth Insertion Magmeter, PVC, 1″-3″, AO55 68

EX812S Fixed Depth Insertion Magmeter, 316 SS, 1″-3″, AO55 191

EX822B Fixed Depth Insertion Magmeter, Brass, 4″-10″, AO55 089

EX822P Fixed Depth Insertion Magmeter, PVC, 4″-10″, AO55 89

EX822S Fixed Depth Insertion Magmeter, 316 SS, 4″-10″, AO55 267

EX832B Fixed Depth Insertion Magmeter, Brass, 12″, AO55 157

EX832P Fixed Depth Insertion Magmeter, PVC, 12″, AO55 050

EX832S Fixed Depth Insertion Magmeter, 316 SS, 12″, AO55 353

Option Code(s) Description

06 LMI Pump 4-Pin Connector 0

15 Reverse Flow 49

50 Low Power NC

106 Roytronics® Series-A Pump 5 Pin Connector 0

125 Viton® O-Ring 6

2014 Industrial  List V2 Page 13 January 01, 2014

Rev. 050114

EX806 Series Fixed Depth Insertion Magmeter (DL76 Meter Mount)

Model # Description

EX816B Fixed Depth Insertion Magmeter, Brass, 1″-3″, DL76 045

EX816P Fixed Depth Insertion Magmeter, PVC, 1″-3″, DL76 53

EX816S Fixed Depth Insertion Magmeter, 316 SS, 1″-3″, DL76 176

EX826B Fixed Depth Insertion Magmeter, Brass, 4″-10″, DL76 074

EX826P Fixed Depth Insertion Magmeter, PVC, 4″-10″, DL76 74

EX826S Fixed Depth Insertion Magmeter, 316 SS, 4″-10″, DL76 252

EX836B Fixed Depth Insertion Magmeter, Brass, 12″, DL76 142

EX836P Fixed Depth Insertion Magmeter, PVC, 12″, DL76 035

EX836S Fixed Depth Insertion Magmeter, 316 SS, 12″, DL76 338

Option Code(s) Description

15 Reverse Flow 49

32 Tamper-Evident Kit, Wire, Seal 1

50 Low Power NC

125 Viton® O-Ring 6

EX808 Series Fixed Depth Insertion Magmeter (PD10 Meter Mount)

Model # Description

EX818B Fixed Depth Insertion Magmeter, Brass, 1″-3″, PD10 48

EX818P Fixed Depth Insertion Magmeter, PVC, 1″-3″, PD10 56

EX818S Fixed Depth Insertion Magmeter, 316 SS, 1″-3″, PD10 79

EX828B Fixed Depth Insertion Magmeter, Brass, 4″-10″, PD10 77

EX828P Fixed Depth Insertion Magmeter, PVC, 4″-10″, PD10 77

EX828S Fixed Depth Insertion Magmeter, 316 SS, 4″-10″, PD10 055

EX838B Fixed Depth Insertion Magmeter, Brass, 12″, PD10 45

EX838P Fixed Depth Insertion Magmeter, PVC, 12″, PD10 38

EX838S Fixed Depth Insertion Magmeter, 316 SS, 12″, PD10 141

Option Code(s) Description

06 LMI Pump 4-Pin Connector 0

15 Reverse Flow 49

37 10 Ft. Cable for LMI Connector 2

50 Low Power NC

106 Roytronics® Series-A Pump 5 Pin Connector 0

125 Viton® O-Ring 6

2014 Industrial  List V2 Page 14 January 01, 2014

Rev. 050114

EX800 Series Tee Fittings

Model # Description

Bronze

EF81T-B-100 Tee Fitting, Bronze, Threaded, 1″, EX 44

EF81T-B-150 Tee Fitting, Bronze, Threaded, 1-1/2″, EX 59

EF81T-B-200 Tee Fitting, Bronze, Threaded, 2″, EX 79

EF81T-B-300 Tee Fitting, Bronze, Threaded, 3″, EX 44

EF81T-B-400 Tee Fitting, Bronze, Threaded, 4″, EX 76

EF81TC-B-100 Tee Fitting, Bronze, Sweat, 1″, EX 44

EF81TC-B-150 Tee Fitting, Bronze, Sweat, 1-1/2″, EX 59

EF81TC-B-200 Tee Fitting, Bronze, Sweat, 2″, EX 79

EF81TC-B-300 Tee Fitting, Bronze, Sweat, 3″, EX 44

EF81TC-B-400 Tee Fitting, Bronze, Sweat, 4″, EX 76

PVC

EF81T-P-100 Tee Fitting, PVC, 1″, EX 24

EF81T-P-150 Tee Fitting, PVC, 1-1/2″, EX 28

EF81T-P-200 Tee Fitting, PVC, 2″, EX 35

EF81T-P-200-18 Tee Fitting, PVC, Flanged Ends, 2″,EX 45

Carbon Steel

EF81T-C-100 Tee Fitting, Carbon Steel, 1″, EX 79

EF81T-C-150 Tee Fitting, Carbon Steel, 1-1/2″, EX 20

EF81T-C-200 Tee Fitting, Carbon Steel, 2″, EX 61

EF81T-C-200-34 Tee Fitting, Carbon Steel, Flanged Ends, 2″, EX 41

Stainless Steel

EF81T-S-100 Tee Fitting, 304 SS, 1″,EX 57

EF81T-S-150 Tee Fitting, 304 SS, 1-1/2″, EX 67

EF81T-S-200 Tee Fitting, 304 SS, 2″, EX 77

EF81T-S-100-14 Tee Fitting, 316 SS, 1″,EX 18

EF81T-S-150-14 Tee Fitting, 316 SS , 1-1/2″, EX 38

EF81T-S-200-14 Tee Fitting, 316 SS, 2″, EX 63

EF81T-S-200-20 Tee Fitting, 304 SS, Flanged Ends, 2″, EX 17

EF81T-S-200-14-20 Tee Fitting, 316 SS, Flanged Ends, 2″, EX 003

2014 Industrial  List V2 Page 15 January 01, 2014

Rev. 050114

EX800 Series Saddle Fittings

Model # Description

Ductile Iron

EF82S-F-300 Saddle, Iron, 3″, EX 72

EF82S-F-400 Saddle, Iron, 4″, EX 06

EF82S-F-600 Saddle, Iron, 6″, EX 61

EF82S-F-800 Saddle, Iron, 8″, EX 95

EF82S-F-1000 Saddle, Iron, 10″, EX 67

EF82S-F-1200 Saddle, Iron, 12″, EX 55

PVC

EF82S-P-300 Saddle, PVC, 3″, EX 15

EF82S-P-400 Saddle, PVC, 4″, EX 31

EF82S-P-600 Saddle, PVC, 6″, EX 51

EF82S-P-800 Saddle, PVC, 8″, EX 79

Note: PVC saddles supplied with Buna-O O-rings only.

For Chemical service, O-ring must be removed and saddle glued to pipe with PVC cement.

See Instructions for more detail.

EF82S-P-300-16 Saddle, PVC, 3″, w/ 16″ Pipe Stub, EX 84

EF82S-P-400-16 Saddle, PVC, 4″, w/ 16″ Pipe Stub, EX 05

EF82S-P-600-16 Saddle, PVC, 6″, w/ 16″ Pipe Stub, EX 30

EF82S-P-800-16 Saddle, PVC, 8″, w/ 16″ Pipe Stub, EX 63

PVC saddles ordered with -16 option will be calibrated for K-Factor before shipping.

Bronze

EF82S-B-300 Saddle, Bronze, 3″, EX 74

EF82S-B-400 Saddle, Bronze, 4″, EX 16

2014 Industrial  List V2 Page 16 January 01, 2014

Rev. 050114

EX800 Series Weld/Braze Fittings

Model # Description

Brass

EF82W-B-300 Weldolet, Brass, 3″, EX 40

EF82W-B-400 Weldolet, Brass, 4″, EX 40

EF82W-B-600 Weldolet, Brass, 6″, EX 40

EF82W-B-800 Weldolet, Brass, 8″, EX 40

EF82W-B-1000 Weldolet, Brass, 10″, EX 40

EF82W-B-1200 Weldolet, Brass, 12″, EX 40

Carbon Steel

EF82W-C-300 Weldolet, Carbon Steel, 3″, EX 18

EF82W-C-400 Weldolet, Carbon Steel, 4″, EX 18

EF82W-C-600 Weldolet, Carbon Steel, 6″, EX 18

EF82W-C-800 Weldolet, Carbon Steel, 8″, EX 18

EF82W-C-1000 Weldolet, Carbon Steel, 10″, EX 18

EF82W-C-1200 Weldolet, Carbon Steel, 12″, EX 18

Stainless Steel

EF82W-S-300 Weldolet, 316 SS, 3″, EX 06

EF82W-S-400 Weldolet, 316 SS, 4″, EX 06

EF82W-S-600 Weldolet, 316 SS, 6″, EX 06

EF82W-S-800 Weldolet, 316 SS, 8″, EX 06

EF82W-S-1000 Weldolet, 316 SS, 10″, EX 06

EF82W-S-1200 Weldolet, 316 SS, 12″, EX 06

2014 Industrial  List V2 Page 17 January 01, 2014

Rev. 050114

EX800 Series Parts & Accessories

Model # Description

100248 Cap, Blind, PVC, EX/IP/TX80 series 1

100249 Cap, Blind, Polypro, EX/IP/TX80 series 1

100250 Cap, Blind, SS, EX/IP/TX80 series 0

100251 Cap, Blind, Brass, EX/IP/TX 80 Series 1

100662 Housing Assy, Upper, Blind (Gasket, Screws, Washers, Label) 2

100411 Gasket, Upper Housing 3

100414 Screw/Washer Kit, Upper housing (Qty 4) 1

100264 O-Ring, EPDM, Black 4

100219 O-Ring, Viton®, Brown 8

101850 Cord Grip, 1/2″ NPT 8

100154 U-Clip, Retainer 6

2014 Industrial  List V2 Page 18 January 01, 2014

Rev. 050114

EX110/210 Adjustable Depth Insertion Magmeter (Sensor Only)

Model # Description

EX110B Adj Depth Insertion Magmeter, Brass, 3-10″ 092

EX110S Adj Depth Insertion Magmeter, 316 SS, 3-10″ 369

EX210B Adj Depth Insertion Magmeter, Brass, 10-48″ 273

EX210S Adj Depth Insertion Magmeter, 316 SS, 10-48″ 491

Option Code(s) Description

02 Adapter Fitting, 2″ NPT Threads, Brass 9

02 Adapter Fitting, 2″ NPT Threads, SS 6

15 Reverse Flow 49

23 Adapter, 1-1/2″ BSP Thread Tapered, Brass (2 piece) 3

24 Adapter, 1-1/2″ BSP Thread Tapered, SS (2 piece) 7

35 Old Style (2 piece) Adapter (1-1/2″ NPT thread) 03

40 Immersible 0

50 Low Power NC

72 12″ Extension (210/250 Series Only) 02

EX150/250 Hot-Tap Adjustable Depth Insertion Magmeter (Sensor Only)

Model # Description

EX150B Hot Tap Adj Depth Insertion Magmeter, Brass, 3-10″ 331

EX150S Hot Tap Adj Depth Insertion Magmeter, 316 SS, 3-10″ 576

EX250B Hot Tap Adj Depth Insertion Magmeter, Brass, 10-48″ 593

EX250S Hot Tap Adj Depth Insertion Insertion Magmeter, 316 SS, 10-48″ 864

Option Code(s) Description

08 316 SS Valve Assembly 97

09 No Valve Assembly (Deduct ) (8)

15 Reverse Flow 49

40 Immersible 0

50 Low Power NC

72 12″ Extension (210/250 Series Only) 02

2014 Industrial  List V2 Page 19 January 01, 2014

Rev. 050114

EX111/211 Adjustable Depth Insertion Magmeter (FT420 Meter Mount)

Model # Description

EX111B Adj Depth Insertion Magmeter, Brass, 3-10″, FT420 562

EX111S Adj Depth Insertion Magmeter, 316 SS, 3-10″, FT420 839

EX211B Adj Depth Insertion Magmeter, Brass, 10-48″, FT420 743

EX211S Adj Depth Insertion Magmeter, 316 SS, 10-48″, FT420 961

Option Code(s) Description

02 Adapter Fitting, 2″ NPT Threads, Brass 9

02 Adapter Fitting, 2″ NPT Threads, SS 6

15 Reverse Flow 49

23 Adapter, 1-1/2″ BSP Thread Tapered, Brass (2 piece) 3

24 Adapter, 1-1/2″ BSP Thread Tapered, SS (2 piece) 7

32 Tamper-Evident Kit, Wire, Seal 1

35 Old Style (2 piece) Adapter (1-1/2″ NPT thread) 03

50 Low Power NC

64 Non-Resettable Total 7

72 12″ Extension (210/250 Series Only) 02

98 Dual Relay Output 9

126 Hinged Display Cover 3

EX151/251 Hot-Tap Adjustable Depth Insertion Magmeter (FT420 Meter Mount)

Model # Description

EX151B Hot Tap Adj Depth Insertion Magmeter, Brass, 3-10″, FT420 801

EX151S Hot Tap Adj Depth Insertion Magmeter, 316 SS, 3-10″, FT420 046

EX251B Hot Tap Adj Depth Insertion Magmeter, Brass, 10-48″, FT420 063

EX251S Hot Tap Adj Depth Insertion Magmeter, 316 SS, 10-48″, FT420 334

Option Code(s) Description

08 316 SS Valve Assembly 97

09 No Valve Assembly (Deduct ) (8)

15 Reverse Flow 49

32 Tamper-Evident Kit, Wire, Seal 1

50 Low Power NC

72 12″ Extension (210/250 Series Only) 02

64 Non-Resettable Total 7

98 Dual Relay Output 9

126 Hinged Display Cover 3

2014 Industrial  List V2 Page 20 January 01, 2014

Rev. 050114

EX112/212 Adjustable Depth Insertion Magmeter (AO55 Meter Mount)

Model # Description

EX112B Adj Depth Insertion Magmeter, Brass, 3-10″, AO55 462

EX112S Adj Depth Insertion Magmeter, 316 SS, 3-10″, AO55 739

EX212B Adj Depth Insertion Magmeter, Brass, 10-48″, AO55 643

EX212S Adj Depth Insertion Magmeter, 316 SS, 10-48″, AO55 861

Option Code(s) Description

02 Adapter Fitting, 2″ NPT Threads, Brass 9

02 Adapter Fitting, 2″ NPT Threads, SS 6

06 LMI Pump 4-Pin Connector 0

15 Reverse Flow 49

23 Adapter, 1-1/2″ BSP Thread Tapered, Brass (2 piece) 3

24 Adapter, 1-1/2″ BSP Thread Tapered, SS (2 piece) 7

35 Old Style (2 piece) Adapter (1-1/2″ NPT thread) 03

50 Low Power NC

72 12″ Extension (210/250 Series Only) 02

106 Roytronics® Series-A Pump 5 Pin Connector 0

EX152/252 Hot-Tap Adjustable Depth Insertion Magmeter (AO55 Meter Mount)

Model # Description

EX152B Hot Tap Adj Depth Insertion Magmeter, Brass, 3-10″, AO55 701

EX152S Hot Tap Adj Depth Insertion Magmeter, 316 SS, 3-10″, AO55 946

EX252B Hot Tap Adj Depth Insertion Magmeter, Brass, 10-48″, AO55 963

EX252S Hot Tap Adj Depth Insertion Magmeter, 316 SS, 10-48″, AO55 234

Option Code(s) Description

06 LMI Pump 4-Pin Connector 0

08 316 SS Valve Assembly 97

09 No Valve Assembly (Deduct ) (8)

15 Reverse Flow 49

50 Low Power NC

72 12″ Extension (210/250 Series Only) 02

106 Roytronics® Series-A Pump 5 Pin Connector 0

2014 Industrial  List V2 Page 21 January 01, 2014

Rev. 050114

EX116/216 Adjustable Depth Insertion Magmeter (DL76 Meter Mount)

Model # Description

EX116B Adj Depth Insertion Magmeter, Brass, 3-10″, DL76 447

EX116S Adj Depth Insertion Magmeter, 316 SS, 3-10″, DL76 724

EX216B Adj Depth Insertion Magmeter, Brass, 10-48″, DL76 628

EX216S Adj Depth Insertion Magmeter, 316 SS, 10-48″, DL76 846

Option Code(s) Description

02 Adapter Fitting, 2″ NPT Threads, Brass 9

02 Adapter Fitting, 2″ NPT Threads, SS 6

15 Reverse Flow 49

23 Adapter, 1-1/2″ BSP Thread Tapered, Brass (2 piece) 3

24 Adapter, 1-1/2″ BSP Thread Tapered, SS (2 piece) 7

32 Tamper-Evident Kit, Wire, Seal 1

35 Old Style (2 piece) Adapter (1-1/2″ NPT thread) 03

50 Low Power NC

72 12″ Extension (210/250 Series Only) 02

EX156/256 Hot-Tap Adjustable Depth Insertion Magmeter (DL76 Meter Mount)

Model # Description

EX156B Hot Tap Adj Depth Insertion Magmeter, Brass, 3-10″, DL76 686

EX156S Hot Tap Adj Depth Insertion Magmeter, 316 SS, 3-10″, DL76 931

EX256B Hot Tap Adj Depth Insertion Magmeter, Brass, 10-48″, DL76 948

EX256S Hot Tap Adj Depth Insertion Magmeter, 316 SS, 10-48″, DL76 219

Option Code(s) Description

08 316 SS Valve Assembly 97

09 No Valve Assembly (Deduct ) (8)

15 Reverse Flow 49

32 Tamper-Evident Kit, Wire, Seal 1

50 Low Power NC

72 12″ Extension (210/250 Series Only) 02

2014 Industrial  List V2 Page 22 January 01, 2014

Rev. 050114

EX118/218 Adjustable Depth Insertion Magmeter (PD10 Meter Mount)

Model # Description

EX118B Adj Depth Insertion Magmeter, Brass, 3-10″, PD10 250

EX118B Adj Depth Insertion Magmeter, 316 SS, 3-10″, PD10 527

EX218B Adj Depth Insertion Magmeter, Brass, 10-48″, PD10 431

EX218S Adj Depth Insertion Magmeter, 316 SS, 10-48″, PD10 649

Option Code(s) Description

02 Adapter Fitting, 2″ NPT Threads, Brass 9

02 Adapter Fitting, 2″ NPT Threads, SS 6

06 LMI Pump 4-Pin Connector 0

15 Reverse Flow 49

23 Adapter, 1-1/2″ BSP Thread Tapered, Brass (2 piece) 3

24 Adapter, 1-1/2″ BSP Thread Tapered, SS (2 piece) 7

35 Old Style (2 piece) Adapter (1-1/2″ NPT thread) 03

37 10 Ft. Cable for LMI Connector 2

50 Low Power NC

72 12″ Extension (210/250 Series Only) 02

106 Roytronics® Series-A Pump 5 Pin Connector 0

EX158/258 Hot-Tap Adjustable Depth Insertion Magmeter (PD10 Meter Mount)

Model # Description

EX158B Hot Tap Adj Depth Insertion Magmeter, Brass, 3-10″, PD10 489

EX158S Hot Tap Adj Depth Insertion Magmeter, 316 SS, 3-10″, PD10 734

EX258B Hot Tap Adj Depth Insertion Magmeter, Brass, 10-48″, PD10 751

EX258S Hot Tap Adj Depth Insertion Magmeter, 316 SS, 10-48″, PD10 022

Option Code(s) Description

08 316 SS Valve Assembly 97

09 No Valve Assembly (Deduct ) (8)

06 LMI Pump 4-Pin Connector 0

15 Reverse Flow 49

37 10 Ft. Cable for LMI Connector 2

50 Low Power NC

72 12″ Extension (210/250 Series Only) 02

106 Roytronics® Series-A Pump 5 Pin Connector 0

2014 Industrial  List V2 Page 23 January 01, 2014

Rev. 050114

EX110/210 Series Saddle Fittings

Model # Description

MF101F-300-150 Saddle, Iron, NPT Thread, 3″ X 1-1/2″ 36

MF101F-400-150 Saddle, Iron, NPT Thread, 4″ X 1-1/2″ 44

MF101F-600-150 Saddle, Iron, NPT Thread, 6″ X 1-1/2″ 48

MF101F-800-150 Saddle, Iron, NPT Thread, 8″ X 1-1/2″ 78

MF101F-1000-150 Saddle, Iron, NPT Thread, 10″ X 1-1/2″ 58

MF101F-1200-150 Saddle, Iron, NPT Thread, 12″ X 1-1/2″ 20

MF101F-1400-150 Saddle, Iron, NPT Thread, 14″ X 1-1/2″ 90

MF101F-1600-150 Saddle, Iron, NPT Thread, 16″ X 1-1/2″ 55

MF101F-1800-150 Saddle, Iron, NPT Thread, 18″ X 1-1/2″ 29

MF101F-2000-150 Saddle, Iron, NPT Thread, 20″ X 1-1/2″ 02

MF101F-2200-150 Saddle, Iron, NPT Thread, 22″ X 1-1/2″ 50

MF101F-2400-150 Saddle, Iron, NPT Thread, 24″ X 1-1/2″ 95

MF101B-300-150 Saddle, Bronze, NPT Thread, 3″ X 1-1/2″ 93

MF101B-400-150 Saddle, Bronze, NPT Thread 4″ X 1-1/2″ 24

EX150/250 Series Saddle Fittings

Model # Description

MF101F-300-200 Saddle, Iron, NPT Thread, 3″ X 2″ 36

MF101F-400-200 Saddle, Iron, NPT Thread, 4″ X 2″ 44

MF101F-600-200 Saddle, Iron, NPT Thread, 6″ X 2″ 48

MF101F-800-200 Saddle, Iron, NPT Thread, 8″ X 2″ 78

MF101F-1000-200 Saddle, Iron, NPT Thread, 10″ X 2″ 58

MF101F-1200-200 Saddle, Iron, NPT Thread, 12″ X 2″ 20

MF101F-1400-200 Saddle, Iron, NPT Thread, 14″ X 2″ 90

MF101F-1600-200 Saddle, Iron, NPT Thread, 16″ X 2″ 55

MF101F-1800-200 Saddle, Iron, NPT Thread, 18″ X 2″ 29

MF101F-2000-200 Saddle, Iron, NPT Thread, 20″ X 2″ 02

MF101F-2200-200 Saddle, Iron, NPT Thread, 22″ X 2″ 50

MF101F-2400-200 Saddle, Iron, NPT Thread, 24″ X 2″ 95

MF101B-300-200 Saddle, Bronze, NPT Thread, 3″ X 2″ 93

MF101B-400-200 Saddle, Bronze, NPT Thread, 4″ X 2″ 24

2014 Industrial  List V2 Page 24 January 01, 2014

Rev. 050114

EX110/210 Series Parts & Accessories

Model # Description

100345 O-Ring, EPDM 4

100662 Housing Assy, Upper, Blind (Gasket, Screws, Washers, Label) 2

100411 Gasket, Upper Housing 3

100414 Screw/Washer Kit, Upper housing (Qty 4) 1

101850 Cord Grip, 1/2″ NPT 8

100853 Seal, Security, w/12″ of Wire

100854 Wire, for Security Seal, 12″

EX150/250 Series Parts & Accessories

Model # Description

100345 O-Ring, EPDM 4

100069 Valve Assy, Brass, Hot-Tap 49

100119 Valve Assy, 316 SS, Hot-Tap 45

100062 Cap, Blind, Brass IP/TX 1

100063 Cap, Blind, SS, IP 7

100662 Housing Assy, Upper, Blind (Gasket, Screws, Washers, Label) 2

100411 Gasket, Upper Housing 3

100414 Screw/Washer Kit, Upper housing (Qty 4) 1

101850 Cord Grip, 1/2″ NPT 8

100853 Seal, Security, w/12″ of Wire

100854 Wire, for Security Seal, 12″

Model # Description

TX810B Fixed Depth Insertion Turbine Meter, Brass, 1-1/2″-3″ 93

TX810P Fixed Depth Insertion Turbine Meter, PVC, 1-1/2″-3″ 96

TX810S Fixed Depth Insertion Turbine Meter, 316 SS, 1-1/2″-3″ 23

TX810S-HP Fixed Depth Insertion Turbine Meter, 316 SS, Hi Pres, 1-1/2″-3″ 98

TX820B Fixed Depth Insertion Turbine Meter, Brass, 4″-8″ 23

TX820P Fixed Depth Insertion Turbine Meter, PVC, 4″-8″ 17

TX820S Fixed Depth Insertion Turbine Meter, 316 SS, 4″-8″ 01

TX820S-HP Fixed Depth Insertion Turbine Meter, 316 SS, Hi Pres, 4″-8″ 76

Option Code(s) Description

04 Micropower Pickup (For Battery Powered Meters) NC

06 LMI Pump 4-Pin Connector 0

07 Seametrics Control Connector 0

40 Immersible 0

60 Viton® O-Ring 6

106 Roytronics® Series-A Pump 5-Pin Connector 0

Note: If the -HP option is ordered, a Carbon or Stainless fitting must also be ordered.

HP units are not interchangable with standard units.

TX801 Series Fixed Depth Insertion Turbine Meter (FT420 Meter Mount)

Model # Description

TX811B Fixed Depth Insertion Turbine Meter, Brass, 1-1/2″-3″, FT420 163

TX811P Fixed Depth Insertion Turbine Meter, PVC, 1-1/2″-3″, FT420 066

TX811S Fixed Depth Insertion Turbine Meter, 316 SS, 1-1/2″-3″, FT420 293

TX811S-HP Fixed Depth Insertion Turbine Meter, 316 SS, Hi Pres, 1-1/2″-3″, FT420 368

TX821B Fixed Depth Insertion Turbine Meter, Brass, 4″-8″, FT420 193

TX821P Fixed Depth Insertion Turbine Meter, PVC, 4″-8″, FT420 087

TX821S Fixed Depth Insertion Turbine Meter, 316 SS, 4″-8″, FT420 371

TX821S-HP Fixed Depth Insertion Turbine Meter, 316 SS, Hi Pres, 4″-8″, FT420 446

Option Code(s) Description

32 Tamper-Evident Kit, Wire, Seal 1

60 Viton® O-Ring 6

64 Non-Resettable Total 7

98 Dual Relay Output 9

126 Hinged Display Cover 3

Note: If the -HP option is ordered, a Carbon or Stainless fitting must also be ordered.

HP units are not interchangable with standard units.

2014 Industrial  List V2 Page 28 January 01, 2014

Rev. 050114

TX802 Series Fixed Depth Insertion Turbine Meter (AO55 Meter Mount)

Model # Description

TX812B Fixed Depth Insertion Turbine Meter, Brass, 1-1/2″-3″, AO55 063

TX812P Fixed Depth Insertion Turbine Meter, PVC, 1-1/2″-3″, AO55 66

TX812S Fixed Depth Insertion Turbine Meter, 316 SS, 1-1/2″-3″, AO55 193

TX812S-HP Fixed Depth Insertion Turbine Meter, 316 SS, Hi Pres, 1-1/2″-3″, AO55 268

TX822B Fixed Depth Insertion Turbine Meter, Brass, 4″-8″, AO55 093

TX822P Fixed Depth Insertion Turbine Meter, PVC, 4″-8″, AO55 87

TX822S Fixed Depth Insertion Turbine Meter, 316 SS, 4″-8″, AO55 271

TX822S-HP Fixed Depth Insertion Turbine Meter, 316 SS, Hi Pres, 4″-8″, AO55 346

Option Code(s) Description

06 LMI Pump 4-Pin Connector 0

60 Viton® O-Ring 6

106 Roytronics® Series-A Pump 5-Pin Connector 0

Note: If the -HP option is ordered, a Carbon or Stainless fitting must also be ordered.

HP units are not interchangable with standard units.

TX804 Series Fixed Depth Insertion Turbine Meter (FT415 Meter Mount)

Model # Description

TX814B Fixed Depth Insertion Turbine Meter, Brass, 1-1/2″-3″, FT415 189

TX814P Fixed Depth Insertion Turbine Meter, PVC, 1-1/2″-3″, FT415 092

TX814S Fixed Depth Insertion Turbine Meter, 316 SS, 1-1/2″-3″, FT415 319

TX814S-HP Fixed Depth Insertion Turbine Meter, 316 SS, Hi Pres, 1-1/2″-3″, FT415 394

TX824B Fixed Depth Insertion Turbine Meter, Brass, 4″-8″, FT415 219

TX824P Fixed Depth Insertion Turbine Meter, PVC, 4″-8″, FT415 113

TX824S Fixed Depth Insertion Turbine Meter, 316 SS, 4″-8″, FT415 397

TX824S-HP Fixed Depth Insertion Turbine Meter, 316 SS, Hi Pres, 4″-8″, FT415 472

Option Code(s) Description

32 Tamper-Evident Kit, Wire, Seal 1

60 Viton® O-Ring 6

64 Non-Resettable Total 7

126 Hinged Display Cover 3

Note: If the -HP option is ordered, a Carbon or Stainless fitting must also be ordered.

HP units are not interchangable with standard units.

2014 Industrial  List V2 Page 29 January 01, 2014

Rev. 050114

TX806 Series Fixed Depth Insertion Turbine Meter (DL76 Meter Mount)

Model # Description

TX816B Fixed Depth Insertion Turbine Meter, Brass, 1-1/2″-3″, DL76 048

TX816P Fixed Depth Insertion Turbine Meter, PVC, 1-1/2″-3″, DL76 51

TX816S Fixed Depth Insertion Turbine Meter, 316 SS, 1-1/2″-3″, DL76 178

TX816S-HP Fixed Depth Insertion Turbine Meter, 316 SS, Hi Pres, 1-1/2″-3″, DL76 253

TX826B Fixed Depth Insertion Turbine Meter, Brass, 4″-8″, DL76 078

TX826P Fixed Depth Insertion Turbine Meter, PVC, 4″-8″, DL76 72

TX826S Fixed Depth Insertion Turbine Meter, 316 SS, 4″-8″, DL76 256

TX826S-HP Fixed Depth Insertion Turbine Meter, 316 SS, Hi Pres, 4″-8″, DL76 331

Option Code(s) Description

32 Tamper-Evident Kit, Wire, Seal 1

60 Viton® O-Ring 6

Note: If the -HP option is ordered, a Carbon or Stainless fitting must also be ordered.

HP units are not interchangable with standard units.

TX808 Series Fixed Depth Insertion Turbine Meter (PD10 Meter Mount)

Model # Description

TX818B Fixed Depth Insertion Turbine Meter, Brass, 1-1/2″-3″, PD10 51

TX818P Fixed Depth Insertion Turbine Meter, PVC, 1-1/2″-3″, PD10 54

TX818S Fixed Depth Insertion Turbine Meter, 316 SS, 1-1/2″-3″, PD10 81

TX818S-HP Fixed Depth Insertion Turbine Meter, 316 SS, Hi Pres, 1-1/2″-3″, PD10 056

TX828B Fixed Depth Insertion Turbine Meter, Brass, 4″-8″, PD10 81

TX828P Fixed Depth Insertion Turbine Meter, PVC, 4″-8″, PD10 75

TX828S Fixed Depth Insertion Turbine Meter, 316 SS, 4″-8″, PD10 059

TX828S-HP Fixed Depth Insertion Turbine Meter, 316 SS, Hi Pres, 4″-8″, PD10 134

Option Code(s) Description

06 LMI Pump 4-Pin Connector 0

37 10 Ft. Cable for LMI Connector 2

60 Viton® O-Ring 6

106 Roytronics® Series-A Pump 5-Pin Connector 0

Note: If the -HP option is ordered, a Carbon or Stainless fitting must also be ordered.

HP units are not interchangable with standard units.

2014 Industrial  List V2 Page 30 January 01, 2014

Rev. 050114

TX800 Series Tee Fittings

Model # Description

Bronze

TF81T-B-150 Tee Fitting, Bronze, Threaded, 1-1/2″, TX 59

TF81T-B-200 Tee Fitting, Bronze, Threaded, 2″, TX 79

TF81T-B-300 Tee Fitting, Bronze, Threaded, 3″, TX 44

TF81T-B-400 Tee Fitting, Bronze, Threaded, 4″, TX 76

TF81TC-B-150 Tee Fitting, Bronze, Sweat, 1-1/2″, TX 59

TF81TC-B-200 Tee Fitting, Bronze, Sweat, 2″, TX 79

TF81TC-B-300 Tee Fitting, Bronze, Sweat, 3″, TX 44

TF81TC-B-400 Tee Fitting, Bronze, Sweat, 4″, TX 76

PVC

TF81T-P-150 Tee Fitting, PVC, 1-1/2″, TX 28

TF81T-P-200 Tee Fitting, PVC, 2″, TX 35

Carbon Steel

TF81T-C-150 Tee Fitting, Carbon Steel, 1-1/2″, TX 20

TF81T-C-200 Tee Fitting, Carbon Steel, 2″, TX 61

TF81T-C-150-HP Tee Fitting, Carbon Steel, Hi Pres, 1-1/2″, TX 35

TF81T-C-200-HP Tee Fitting, Carbon Steel, Hi Pres, 2″, TX 76

Stainless Steel

TF81T-S-150 Tee Fitting, 304 SS, 1-1/2″, TX 67

TF81T-S-200 Tee Fitting, 304 SS, 2″, TX 77

TF81T-S-150-14 Tee Fitting, 316 SS, 1-1/2″, TX 38

TF81T-S-200-14 Tee Fitting, 316 SS, 2″, TX 63

TF81T-S-150-HP Tee Fitting, 304 SS, Hi Pres, 1-1/2″, TX 82

TF81T-S-200-HP Tee Fitting, 304 SS, Hi Pres, 2″, TX 92

TF81T-S-150-14-HP Tee Fitting, 316 SS, Hi Pres, 1-1/2″, TX 53

TF81T-S-200-14-HP Tee Fitting, 316 SS, Hi Pres, 2″, TX 78

2014 Industrial  List V2 Page 31 January 01, 2014

Rev. 050114

TX800 Series Saddle Fittings

Model # Description

Bronze

MF82S-B-300 Saddle, Bronze, 3″ 74

MF82S-B-400 Saddle, Bronze, 4″ 15

PVC

MF82S-P-300 Saddle, PVC, 3″ 15

MF82S-P-400 Saddle, PVC, 4″ 31

MF82S-P-600 Saddle, PVC, 6″ 51

MF82S-P-800 Saddle, PVC, 8″ 79

Note: PVC saddles supplied with Buna-O O-rings only.

For Chemical service, O-ring must be removed and saddle glued to pipe with PVC cement.

See Instructions for more detail.

MF82S-P-300-16 Saddle, PVC, 3″, w/ 16″ Pipe Stub 84

MF82S-P-400-16 Saddle, PVC, 4″, w/ 16″ Pipe Stub 05

MF82S-P-600-16 Saddle, PVC, 6″, w/ 16″ Pipe Stub 30

MF82S-P-800-16 Saddle, PVC, 8″, w/ 16″ Pipe Stub 63

PVC saddles ordered with -16 option will be calibrated for K-Factor before shipping.

Ductile Iron

MF82S-F-300 Saddle, Iron, 3″ 72

MF82S-F-400 Saddle, Iron, 4″ 06

MF82S-F-600 Saddle, Iron, 6″ 61

MF82S-F-800 Saddle, Iron, 8″ 95

2014 Industrial  List V2 Page 32 January 01, 2014

Rev. 050114

TX800 Series Weld/Braze Fittings

Model # Description

Brass

MF82W-B-300 Weldolet, Brass, 3″ 40

MF82W-B-400 Weldolet, Brass, 4″ 40

MF82W-B-600 Weldolet, Brass, 6″ 40

MF82W-B-800 Weldolet, Brass, 8″ 40

Carbon Steel

MF82W-C-300 Weldolet, Carbon Steel, 3″ 18

MF82W-C-400 Weldolet, Carbon Steel, 4″ 18

MF82W-C-600 Weldolet, Carbon Steel, 6″ 18

MF82W-C-800 Weldolet, Carbon Steel, 8″ 18

MF82W-C-300-HP Weldolet, Carbon Steel, Hi Pres, 3″ 33

MF82W-C-400-HP Weldolet, Carbon Steel, Hi Pres, 4″ 33

MF82W-C-600-HP Weldolet, Carbon Steel, Hi Pres, 6″ 33

MF82W-C-800-HP Weldolet, Carbon Steel, Hi Pres, 8″ 33

Stainless Steel

MF82W-S-300 Weldolet, 316 SS, 3″ 06

MF82W-S-400 Weldolet, 316 SS, 4″ 06

MF82W-S-600 Weldolet, 316 SS, 6″ 06

MF82W-S-800 Weldolet, 316 SS, 8″ 06

MF82W-S-300-HP Weldolet, 316 SS, Hi Pres, 3″ 21

MF82W-S-400-HP Weldolet, 316 SS, Hi Pres, 4″ 21

MF82W-S-600-HP Weldolet, 316 SS, Hi Pres, 6″ 21

MF82W-S-800-HP Weldolet, 316 SS, Hi Pres, 8″ 21

2014 Industrial  List V2 Page 33 January 01, 2014

Rev. 050114

TX800 Series Parts & Accessories

Model # Description

103315 Bearing Assembly Kit, IP/TX, Kynar 8

100251 Cap, Blind, Brass, EX/IP/TX 80 Series 1

100249 Cap, Blind, Polypro, EX/IP/TX80 series 1

100248 Cap, Blind, PVC, EX/IP/TX80 series 1

100250 Cap, Blind, SS, EX/IP/TX80 series 0

100264 O-Ring, EPDM, Black 4

100219 O-Ring, Viton®, Brown 8

100508 Sensor Assy, Grey Micropowered, 18′ (For Battery Powered Displays) 00

100419 Sensor Assy, Blue, Low Power, 18′ (For External Powered Displays) 00

100298 Sensor Retaining Screw 1

100375 Spanner Tool, Sensor, Retain Screw 9

101850 Cord Grip, 1/2″ NPT 8

100154 U-Clip, Retainer 6

100853 Seal, Security, w/12″ of Wire

100854 Wire, for Security Seal, 12″

102632 MK10, Mounting Kit, Meter Mount 6

102633 MK20, Mounting Kit, Wall Mount 19

For TX meters ordered BEFORE January 1, 2011. (White Rotor)

Model # Description

100326 Rotor, Polypro, Carbide Shaft 35

100327 Rotor, Kynar®, Ceramic Shaft 68

100324 Rotor Repair Kit, TX, Polypro, (Rotor, Bearings, Carbide Shaft) 59

100325 Rotor Repair Kit, TX, Kynar®, Ceramic Shaft (Rotor, Bearings, Shaft) 00

103312 Kit, Shaft Assembly, Ceramic, WT/TX 20

For TX meters ordered AFTER January 1, 2011. (Blue Rotor)

Model # Description

101862 Rotor Assy, Kynar® w/ Carbide Shaft, TX 35

101912 Rotor Repair Kit, TX, Kynar®, Carbide Shaft (Rotor, Bearings, Shaft) 59

2014 Industrial  List V2 Page 34 January 01, 2014

Rev. 050114

TX110/210 Adjustable Depth Insertion Turbine Meter (Sensor Only)

Model # Description

TX110B Adj Depth Insertion Turbine Meter, Brass, 3″-12″ 087

TX110S Adj Depth Insertion Turbine Meter, 316 SS, 3″-12″ 370

TX210B Adj Depth Insertion Turbine Meter, Brass, 12″- 40″ 267

TX210S Adj Depth Insertion Turbine Meter, 316 SS, 12″- 40″ 492

Option Code(s) Description

02 Adapter Fitting, 2″ NPT Threads, Brass 6

02 Adapter Fitting, 2″ NPT Threads, SS 6

03 Bi-Directional 13

04 Micropower Pickup (For Battery Powered Meters) NC

06 LMI Pump 4-Pin Connector 0

07 Seametrics Control Connector 0

23 Adapter, 1-1/2″ BSP Thread Tapered, Brass 3

24 Adapter, 1-1/2″ BSP Thread Tapered, SS 7

35 Old Style Adapter, 1-1/2″ NPT Thread 03

40 Immersible 0

72 12″ Extension (210/250 Series Only) 02

106 Roytronics® Series-A Pump 5-Pin Connector 0

TX150/250 Hot-Tap Adjustable Depth Insertion Turbine Meter (Sensor Only)

Model # Description

TX150B Hot Tap Adj Depth Insertion Turbine Meter, Brass, 3″-12″ 325

TX150S Hot Tap Adj Depth Insertion Turbine Meter, 316 SS, 3″-12″ 577

TX250B Hot Tap Adj Depth Insertion Turbine Meter, Brass, 12″- 40″ 586

TX250S Hot Tap Adj Depth Insertion Turbine Meter, 316 SS, 12″- 40″ 865

Option Code(s) Description

03 Bi-Directional 13

04 Micropower Pickup (For Battery Powered Meters) NC

06 LMI Pump 4-Pin Connector 0

07 Seametrics Control Connector 0

08 316 SS Valve Assembly 97

09 No Valve Assembly (Deduct ) (8)

40 Immersible 0

72 12″ Extension (210/250 Series Only) 02

106 Roytronics® Series-A Pump 5-Pin Connector 0

2014 Industrial  List V2 Page 35 January 01, 2014

Rev. 050114

TX111/211 Adjustable Depth Insertion Turbine Meter (FT420 Meter Mount)

Model # Description

TX111B Adj Depth Insertion Turbine Meter, Brass, 3″-12″, FT420 557

TX111S Adj Depth Insertion Turbine Meter, 316 SS, 3″-12″, FT420 840

TX211B Adj Depth Insertion Turbine Meter, Brass, 12″- 40″, FT420 737

TX211S Adj Depth Insertion Turbine Meter, 316 SS, 12″- 40″, FT420 962

Option Code(s) Description

03 Bi-Directional 13

02 Adapter Fitting, 2″ NPT Threads, Brass 6

02 Adapter Fitting, 2″ NPT Threads, SS 6

23 Adapter, 1-1/2″ BSP Thread Tapered, Brass 3

24 Adapter, 1-1/2″ BSP Thread Tapered, SS 7

32 Tamper-Evident Kit, Wire, Seal 1

35 Old Style Adapter, 1-1/2″ NPT Thread 03

64 Non-Resettable Total 7

72 12″ Extension (210/250 Series Only) 02

98 Dual Relay Output 9

126 Hinged Display Cover 3

TX151/251 Hot-Tap Adjustable Depth Insertion Turbine Meter (FT420 Meter Mount)

Model # Description

TX151B Hot Tap Adj Depth Insertion Turbine Meter, Brass, 3″-12″, FT420 795

TX151S Hot Tap Adj Depth Insertion Turbine Meter, 316 SS, 3″-12″, FT420 047

TX251B Hot Tap Adj Depth Insertion Turbine Meter, Brass, 12″- 40″, FT420 056

TX251S Hot Tap Adj Depth Insertion Turbine Meter, 316 SS, 12″- 40″, FT420 335

Option Code(s) Description

03 Bi-Directional 13

08 316 SS Valve Assembly 97

09 No Valve Assembly (Deduct ) (8)

32 Tamper-Evident Kit, Wire, Seal 1

35 Old Style Adapter, 1-1/2″ NPT Thread 03

64 Non-Resettable Total 7

72 12″ Extension (210/250 Series Only) 02

98 Dual Relay Output 9

126 Hinged Display Cover 3

2014 Industrial  List V2 Page 36 January 01, 2014

Rev. 050114

TX112/212 Adjustable Depth Insertion Turbine Meter (AO55 Meter Mount)

Model # Description

TX112B Adj Depth Insertion Turbine Meter, Brass, 3″-12″, AO55 457

TX112S Adj Depth Insertion Turbine Meter, 316 SS, 3″-12″, AO55 740

TX212B Adj Depth Insertion Turbine Meter, Brass, 12″- 40″, AO55 637

TX212S Adj Depth Insertion Turbine Meter, 316 SS, 12″- 40″, AO55 862

Option Code(s) Description

02 Adapter Fitting, 2″ NPT Threads, Brass 6

02 Adapter Fitting, 2″ NPT Threads, SS 6

03 Bi-Directional 13

06 LMI Pump 4-Pin Connector 0

23 Adapter, 1-1/2″ BSP Thread Tapered, Brass 3

24 Adapter, 1-1/2″ BSP Thread Tapered, SS 7

35 Old Style Adapter, 1-1/2″ NPT Thread 03

72 12″ Extension (210/250 Series Only) 02

106 Roytronics® Series-A Pump 5-Pin Connector 0

TX152/252 Hot-Tap Adjustable Depth Insertion Turbine Meter (AO55 Meter Mount)

Model # Description

TX152B Hot Tap Adj Depth Insertion Turbine Meter, Brass, 3″-12″, AO55 695

TX152S Hot Tap Adj Depth Insertion Turbine Meter, 316 SS, 3″-12″, AO55 947

TX252B Hot Tap Adj Depth Insertion Turbine Meter, Brass, 12″- 40″, AO55 956

TX252S Hot Tap Adj Depth Insertion Turbine Meter, 316 SS, 12″- 40″, AO55 235

Option Code(s) Description

03 Bi-Directional 13

06 LMI Pump 4-Pin Connector 0

08 316 SS Valve Assembly 97

09 No Valve Assembly (Deduct ) (8)

72 12″ Extension (210/250 Series Only) 02

106 Roytronics® Series-A Pump 5-Pin Connector 0

2014 Industrial  List V2 Page 37 January 01, 2014

Rev. 050114

TX114/214 Adjustable Depth Insertion Turbine Meter (FT415 Meter Mount)

Model # Description

TX114B Adj Depth Insertion Turbine Meter, Brass, 3″-12″, FT415 583

TX114S Adj Depth Insertion Turbine Meter, 316 SS, 3″-12″, FT415 866

TX214B Adj Depth Insertion Turbine Meter, Brass, 12″- 40″, FT415 763

TX214S Adj Depth Insertion Turbine Meter, 316 SS, 12″- 40″, FT415 988

Option Code(s) Description

02 Adapter Fitting, 2″ NPT Threads, Brass 6

02 Adapter Fitting, 2″ NPT Threads, SS 6

03 Bi-Directional 13

23 Adapter, 1-1/2″ BSP Thread Tapered, Brass 3

24 Adapter, 1-1/2″ BSP Thread Tapered, SS 7

32 Tamper-Evident Kit, Wire, Seal 1

35 Old Style Adapter, 1-1/2″ NPT Thread 03

64 Non-Resettable Total 7

72 12″ Extension (210/250 Series Only) 02

126 Hinged Display Cover 3

TX154/254 Hot-Tap Adjustable Depth Insertion Turbine Meter (FT415 Meter Mount)

Model # Description

TX154B Hot Tap Adj Depth Insertion Turbine Meter, Brass, 3″-12″, FT415 821

TX154S Hot Tap Adj Depth Insertion Turbine Meter, 316 SS, 3″-12″, FT415 073

TX254B Hot Tap Adj Depth Insertion Turbine Meter, Brass, 12″- 40″, FT415 082

TX254S Hot Tap Adj Depth Insertion Turbine Meter, 316 SS, 12″- 40″, FT415 361

Option Code(s) Description

03 Bi-Directional 13

08 316 SS Valve Assembly 97

09 No Valve Assembly (Deduct ) (8)

32 Tamper-Evident Kit, Wire, Seal 1

64 Non-Resettable Total 7

72 12″ Extension (210/250 Series Only) 02

126 Hinged Display Cover 3

2014 Industrial  List V2 Page 38 January 01, 2014

Rev. 050114

TX116/216 Adjustable Depth Insertion Turbine Meter (DL76 Meter Mount)

Model # Description

TX116B Adj Depth Insertion Turbine Meter, Brass, 3″-12″, DL76 442

TX116S Adj Depth Insertion Turbine Meter, 316 SS, 3″-12″, DL76 725

TX216B Adj Depth Insertion Turbine Meter, Brass, 12″- 40″, DL76 622

TX216S Adj Depth Insertion Turbine Meter, 316 SS, 12″- 40″, DL76 847

Option Code(s) Description

02 Adapter Fitting, 2″ NPT Threads, Brass 6

02 Adapter Fitting, 2″ NPT Threads, SS 6

03 Bi-Directional 13

23 Adapter, 1-1/2″ BSP Thread Tapered, Brass 3

24 Adapter, 1-1/2″ BSP Thread Tapered, SS 7

32 Tamper-Evident Kit, Wire, Seal 1

35 Old Style Adapter, 1-1/2″ NPT Thread 03

72 12″ Extension (210/250 Series Only) 02

TX156/256 Hot-Tap Adjustable Depth Insertion Turbine Meter (DL76 Meter Mount)

Model # Description

TX156B Hot Tap Adj Depth Insertion Turbine Meter, Brass, 3″-12″, DL76 680

TX156S Hot Tap Adj Depth Insertion Turbine Meter, 316 SS, 3″-12″, DL76 932

TX256B Hot Tap Adj Depth Insertion Turbine Meter, Brass, 12″- 40″, DL76 941

TX256S Hot Tap Adj Depth Insertion Turbine Meter, 316 SS, 12″- 40″, DL76 220

Option Code(s) Description

03 Bi-Directional 13

08 316 SS Valve Assembly 97

09 No Valve Assembly (Deduct ) (8)

32 Tamper-Evident Kit, Wire, Seal 1

72 12″ Extension (210/250 Series Only) 02

2014 Industrial  List V2 Page 39 January 01, 2014

Rev. 050114

TX118/218 Adjustable Depth Insertion Turbine Meter (PD10 Meter Mount)

Model # Description

TX118B Adj Depth Insertion Turbine Meter, Brass, 3″-12″, PD10 245

TX118S Adj Depth Insertion Turbine Meter, 316 SS, 3″-12″, PD10 528

TX218B Adj Depth Insertion Turbine Meter, Brass, 12″- 40″, PD10 425

TX218S Adj Depth Insertion Turbine Meter, 316 SS, 12″- 40″, PD10 650

Option Code(s) Description

02 Adapter Fitting, 2″ NPT Threads, Brass 6

02 Adapter Fitting, 2″ NPT Threads, SS 6

03 Bi-Directional 13

06 LMI Pump 4-Pin Connector 0

23 Adapter, 1-1/2″ BSP Thread Tapered, Brass 3

24 Adapter, 1-1/2″ BSP Thread Tapered, SS 7

35 Old Style Adapter, 1-1/2″ NPT Thread 03

37 10 Ft. Cable for LMI Connector 2

72 12″ Extension (210/250 Series Only) 02

106 Roytronics® Series-A Pump 5-Pin Connector 0

TX158/258 Hot-Tap Adjustable Depth Insertion Turbine Meter (PD10 Meter Mount)

Model # Description

TX158B Hot Tap Adj Depth Insertion Turbine Meter, Brass, 3″-12″, PD10 483

TX158S Hot Tap Adj Depth Insertion Turbine Meter, 316 SS, 3″-12″, PD10 735

TX258B Hot Tap Adj Depth Insertion Turbine Meter, Brass, 12″- 40″, PD10 744

TX258S Hot Tap Adj Depth Insertion Turbine Meter, 316 SS, 12″- 40″, PD10 023

Option Code(s) Description

03 Bi-Directional 13

06 LMI Pump 4-Pin Connector 0

08 316 SS Valve Assembly 97

09 No Valve Assembly (Deduct ) (8)

37 10 Ft. Cable for LMI Connector 2

72 12″ Extension (210/250 Series Only) 02

106 Roytronics® Series-A Pump 5-Pin Connector 0

2014 Industrial  List V2 Page 40 January 01, 2014

Rev. 050114

TX110/210 Saddle Fittings

Model # Description

MF101F-300-150 Saddle, Iron, NPT Thread, 3″ X 1-1/2″ 36

MF101F-400-150 Saddle, Iron, NPT Thread, 4″ X 1-1/2″ 44

MF101F-600-150 Saddle, Iron, NPT Thread, 6″ X 1-1/2″ 48

MF101F-800-150 Saddle, Iron, NPT Thread, 8″ X 1-1/2″ 78

MF101F-1000-150 Saddle, Iron, NPT Thread, 10″ X 1-1/2″ 58

MF101F-1200-150 Saddle, Iron, NPT Thread, 12″ X 1-1/2″ 20

MF101F-1400-150 Saddle, Iron, NPT Thread, 14″ X 1-1/2″ 90

MF101F-1600-150 Saddle, Iron, NPT Thread, 16″ X 1-1/2″ 55

MF101F-1800-150 Saddle, Iron, NPT Thread, 18″ X 1-1/2″ 29

MF101F-2000-150 Saddle, Iron, NPT Thread, 20″ X 1-1/2″ 02

MF101F-2200-150 Saddle, Iron, NPT Thread, 22″ X 1-1/2″ 50

MF101F-2400-150 Saddle, Iron, NPT Thread, 24″ X 1-1/2″ 95

MF101B-300-150 Saddle, Bronze, NPT Thread, 3″ X 1-1/2″ 93

MF101B-400-150 Saddle, Bronze, NPT Thread 4″ X 1-1/2″ 24

TX150/250 Saddle Fittings

Model # Description

MF101F-300-200 Saddle, Iron, NPT Thread, 3″ X 2″ 36

MF101F-400-200 Saddle, Iron, NPT Thread, 4″ X 2″ 44

MF101F-600-200 Saddle, Iron, NPT Thread, 6″ X 2″ 48

MF101F-800-200 Saddle, Iron, NPT Thread, 8″ X 2″ 78

MF101F-1000-200 Saddle, Iron, NPT Thread, 10″ X 2″ 58

MF101F-1200-200 Saddle, Iron, NPT Thread, 12″ X 2″ 20

MF101F-1400-200 Saddle, Iron, NPT Thread, 14″ X 2″ 90

MF101F-1600-200 Saddle, Iron, NPT Thread, 16″ X 2″ 55

MF101F-1800-200 Saddle, Iron, NPT Thread, 18″ X 2″ 29

MF101F-2000-200 Saddle, Iron, NPT Thread, 20″ X 2″ 02

MF101F-2200-200 Saddle, Iron, NPT Thread, 22″ X 2″ 50

MF101F-2400-200 Saddle, Iron, NPT Thread, 24″ X 2″ 95

MF101B-300-200 Saddle, Bronze, NPT Thread, 3″ X 2″ 93

MF101B-400-200 Saddle, Bronze, NPT Thread, 4″ X 2″ 24

2014 Industrial  List V2 Page 41 January 01, 2014

Rev. 050114

TX110/210 Parts & Accessories

Model # Description

100845 Brass Adapter Fitting, NPT Thread, 1-1/2″ 28

100846 SS Adapter Fitting, NPT Thread, 1-1/2″ 08

100816 Brass Adapter Fitting, NPT Thread, 2″ 0

100873 SS Adapter Fitting, NPT Thread, 2″ 03

100059 Brass Adapter Fitting, NPT Thread, 1-1/2″, 2pc, Old Style 28

100082 SS Adapter Fitting, NPT Thread, 1-1/2″, 2pc, OldStyle 08

100345 O-Ring, EPDM 4

103315 Bearing Assembly Kit, IP/TX, Kynar 8

100358 Compression Ferrule, Kynar® 4

100064 Nut, Compression, Brass 4

100084 Nut, Compression, SS 7

100662 Housing Assy, Upper, Blind (Gasket, Screws, Washers, Label) 2

100411 Gasket, Upper Housing 3

100414 Screw/Washer Kit, Upper housing (Qty 4) 1

100374 Mandrel, Rotor Housing, Tool, IP/TX 4

100508 Sensor Assy, Grey Micropowered, 18′ (For Battery Powered Displays) 00

100419 Sensor Assy, Blue, Low Power, 18′ (For External Powered Displays) 00

100360 Plug, Steel, 1/2″ 8

100218 Rotor Housing O-Ring, EPDM 4

101850 Cord Grip, 1/2″ NPT 8

100364 Cord Grip 1/4″ I.D. 2

100853 Seal, Security, w/12″ of Wire

100854 Wire, for Security Seal, 12″

For TX meters ordered BEFORE January 1, 2011. (White Rotor)

Model # Description

100326 Rotor, Polypro, Carbide Shaft 35

100327 Rotor, Kynar®, Ceramic Shaft 68

100339 Housing, Rotor, Brass, TX 4

100340 Housing, Rotor, 316 SS, TX 17

100324 Rotor Repair Kit, TX, Polypro, (Rotor, Bearings, Carbide Shaft) 59

100325 Rotor Repair Kit, TX, Kynar®, Ceramic Shaft (Rotor, Bearings, Shaft) 00

103312 Kit, Shaft Assembly, Ceramic, WT/TX 20

For TX meters ordered AFTER January 1, 2011. (Blue Rotor)

Model # Description

101862 Rotor Assy, Kynar® w/ Carbide Shaft, TX 35

101868 Housing, Rotor, Brass, TX 4

101869 Housing, Rotor, 316 SS, TX 17

101912 Rotor Repair Kit, TX, Kynar®, Carbide Shaft (Rotor, Bearings, Shaft) 59

2014 Industrial  List V2 Page 42 January 01, 2014

Rev. 050114

TX150/250 Parts & Accessories

Model # Description

100384 Adapter, Brass, Hot-Tap, NPT Thread 37

100385 Adapter, 316 SS, Hot-Tap, NPT Thread 23

100345 O-Ring, EPDM 4

100069 Valve Assy, Brass, Hot-Tap 49

100119 Valve Assy, 316 SS, Hot-Tap 45

103315 Bearing Assembly Kit, IP/TX, Kynar 8

100062 Cap, Blind, Brass IP/TX 1

100063 Cap, Blind, SS, IP 7

100061 Collar, Locking, Brass 42

100116 Collar, Locking, SS 07

100358 Compression Ferrule, Kynar® 4

100064 Nut, Compression, Brass 4

100084 Nut, Compression, SS 7

100662 Housing Assy, Upper, Blind (Gasket, Screws, Washers, Label) 2

100411 Gasket, Upper Housing 3

100414 Screw/Washer Kit, Upper housing (Qty 4) 1

100374 Mandrel, Rotor Housing, Tool, IP/TX 4

100508 Sensor Assy, Grey Micropowered, 18′ (For Battery Powered Displays) 00

100419 Sensor Assy, Blue, Low Power, 18′ (For External Powered Displays) 00

100360 Plug, Steel, 1/2″ 8

100218 Rotor Housing O-Ring, EPDM 4

101850 Cord Grip, 1/2″ NPT 8

100364 Cord Grip 1/4″ I.D. 2

100853 Seal, Security, w/12″ of Wire

100854 Wire, for Security Seal, 12″

For TX Series meters ordered BEFORE January 1, 2011 only. (White Rotor)

Model # Description

100326 Rotor, Polypro, Carbide Shaft 35

100327 Rotor, Kynar®, Ceramic Shaft 68

100339 Housing, Rotor, Brass, TX 4

100340 Housing, Rotor, 316 SS, TX 17

100324 Rotor Repair Kit, TX, Polypro, (Rotor, Bearings, Carbide Shaft) 59

100325 Rotor Repair Kit, TX, Kynar®, Ceramic Shaft (Rotor, Bearings, Shaft) 00

103312 Kit, Shaft Assembly, Ceramic, WT/TX 20

For TX Series meters ordered AFTER January 1, 2011 only. (Blue Rotor)

Model # Description

101862 Rotor Assy, Kynar® w/ Carbide Shaft, TX 35

101868 Housing, Rotor, Brass, TX 4

101869 Housing, Rotor, 316 SS, TX 17

101912 Rotor Repair Kit, TX, Kynar®, Carbide Shaft (Rotor, Bearings, Shaft) 59

2014 Industrial  List V2 Page 43 January 01, 2014

Model # Description

IP810B Fixed Depth Insertion Paddlewheel Meter, Brass, 1/2″-3″ 72

IP810S Fixed Depth Insertion Paddlewheel Meter, 316 SS, 1/2″-3″ 00

IP810P Fixed Depth Insertion Paddlewheel Meter, PVC, 1/2″-3″ 03

IP810Y Fixed Depth Insertion Paddlewheel Meter, Polypro, 1/2″-3″ 14

IP810S-HP Fixed Depth Insertion Paddlewheel Meter, 316 SS, Hi Pres, 1/2″-3″ 93

IP820B Fixed Depth Insertion Paddlewheel Meter, Brass, 4″-8″ 98

IP820S Fixed Depth Insertion Paddlewheel Meter, 316 SS, 4″-8″ 18

IP820P Fixed Depth Insertion Paddlewheel Meter, PVC, 4″-8″ 20

IP820Y Fixed Depth Insertion Paddlewheel Meter, Polypro, 4″-8″ 33

IP820S-HP Fixed Depth Insertion Paddlewheel Meter, 316 SS, Hi Pres, 4″-8″ 93

Option Code(s) Description

01 Rotor w/ Ceramic Shaft, PVDF, Kynar® 9

04 Micropower Pickup (For Battery Powered Meters) NC

06 Standard Power & LMI Pump Connector, 4-Pin 0

07 Standard Power & Seametrics Control Connector 0

40 Immersible 0

60 Viton® O-Ring 6

106 Standard Power & Roytronics® Series-A Pump 5 Pin Connector 0

Note: If the -HP option is ordered, a Carbon or Stainless fitting must also be ordered.

HP units are not interchangable with standard units.

IP801 Series Insertion Paddlewheel Meters (FT420 Meter Mount)

Model # Description

IP811B Fixed Depth Insertion Paddlewheel Meter, Brass, 1/2″-3″, FT420 42

IP811S Fixed Depth Insertion Paddlewheel Meter, 316 SS, 1/2″-3″, FT420 70

IP811P Fixed Depth Insertion Paddlewheel Meter, PVC, 1/2″-3″, FT420 73

IP811Y Fixed Depth Insertion Paddlewheel Meter, Polypro, 1/2″-3″, FT420 84

IP811S-HP Fixed Depth Insertion Paddlewheel Meter, 316 SS, Hi Pres,1/2″-3″,FT420 063

IP821B Fixed Depth Insertion Paddlewheel Meter, Brass, 4″-8″, FT420 68

IP821S Fixed Depth Insertion Paddlewheel Meter, 316 SS, 4″-8″, FT420 88

IP821P Fixed Depth Insertion Paddlewheel Meter, PVC, 4″-8″, FT420 90

IP821Y Fixed Depth Insertion Paddlewheel Meter, Polypro, 4″-8″, FT420 03

IP821S-HP Fixed Depth Insertion Paddlewheel Meter, 316 SS, Hi Pres, 4″-8″, FT420 063

Option Code(s) Description

01 Rotor w/ Ceramic Shaft, PVDF, Kynar® 9

32 Tamper-Evident Kit, Wire, Seal 1

60 Viton® O-Ring 6

64 Non-Resettable Total 7

98 Dual Relay Output 9

126 Hinged Display Cover 3

Note: If the -HP option is ordered, a Carbon or Stainless fitting must also be ordered.

HP units are not interchangable with standard units.

2014 Industrial  List V2 Page 46 January 01, 2014

Rev. 050114

IP802 Series Fixed Depth Insertion Paddlewheel Meters (AO55 Meter Mount)

Model # Description

IP812B Fixed Depth Insertion Paddlewheel Meter, Brass, 1/2″-3″, AO55 42

IP812S Fixed Depth Insertion Paddlewheel Meter, 316 SS, 1/2″-3″, AO55 70

IP812P Fixed Depth Insertion Paddlewheel Meter, PVC, 1/2″-3″, AO55 73

IP812Y Fixed Depth Insertion Paddlewheel Meter, Polypro, 1/2″-3″, AO55 84

IP812S-HP Fixed Depth Insertion Paddlewheel Meter, 316 SS, Hi Pres, 1/2″-3″,AO55 45

IP822B Fixed Depth Insertion Paddlewheel Meter, Brass, 4″-8″, AO55 68

IP822S Fixed Depth Insertion Paddlewheel Meter, 316 SS, 4″-8″, AO55 88

IP822P Fixed Depth Insertion Paddlewheel Meter, PVC, 4″-8″, AO55 90

IP822Y Fixed Depth Insertion Paddlewheel Meter, Polypro, 4″-8″, AO55 03

IP822S-HP Fixed Depth Insertion Paddlewheel Meter, 316 SS, Hi Pres, 4″-8″, AO55 33

Option Code(s) Description

01 Rotor w/ Ceramic Shaft, PVDF, Kynar® 9

06 Standard Power & LMI Pump Connector, 4-Pin 0

60 Viton® O-Ring 6

106 Standard Power & Roytronics® Series-A Pump 5 Pin Connector 0

Note: If the -HP option is ordered, a Carbon or Stainless fitting must also be ordered.

HP units are not interchangable with standard units.

IP804 Series Fixed Depth Insertion Paddlewheel Meters (FT415 Meter Mount)

Model # Description

IP814B Fixed Depth Insertion Paddlewheel Meter, Brass, 1/2″-3″, FT415 68

IP814S Fixed Depth Insertion Paddlewheel Meter, 316 SS, 1/2″-3″, FT415 96

IP814P Fixed Depth Insertion Paddlewheel Meter, PVC, 1/2″-3″, FT415 99

IP814Y Fixed Depth Insertion Paddlewheel Meter, Polypro, 1/2″-3″, FT415 10

IP814S-HP Fixed Depth Insertion Paddlewheel Meter, 316 SS,Hi Pres, 1/2″-3″,FT415 071

IP824B Fixed Depth Insertion Paddlewheel Meter, Brass, 4″-8″, FT415 94

IP824S Fixed Depth Insertion Paddlewheel Meter, 316 SS, 4″-8″, FT415 014

IP824P Fixed Depth Insertion Paddlewheel Meter, PVC, 4″-8″, FT415 16

IP824Y Fixed Depth Insertion Paddlewheel Meter, Polypro, 4″-8″, FT415 29

IP824S-HP Fixed Depth Insertion Paddlewheel Meter, 316 SS, Hi Pres, 4″-8″, FT415 089

Option Code(s) Description

01 Rotor w/ Ceramic Shaft, PVDF, Kynar® 9

32 Tamper-Evident Kit, Wire, Seal 1

60 Viton® O-Ring 6

64 Non-Resettable Total 7

126 Hinged Display Cover 3

Note: If the -HP option is ordered, a Carbon or Stainless fitting must also be ordered.

HP units are not interchangable with standard units.

2014 Industrial  List V2 Page 47 January 01, 2014

Rev. 050114

IP806 Series Fixed Depth Insertion Paddlewheel Meters (DL76 Meter Mount)

Model # Description

IP816B Fixed Depth Insertion Paddlewheel Meter, Brass, 1/2″-3″, DL76 27

IP816S Fixed Depth Insertion Paddlewheel Meter, 316 SS, 1/2″-3″, DL76 55

IP816P Fixed Depth Insertion Paddlewheel Meter, PVC, 1/2″-3″, DL76 58

IP816Y Fixed Depth Insertion Paddlewheel Meter, Polypro, 1/2″-3″, DL76 69

IP816S-HP Fixed Depth Insertion Paddlewheel Meter, 316 SS, Hi Pres, 1/2″-3″,DL76 30

IP826B Fixed Depth Insertion Paddlewheel Meter, Brass, 4″-8″, DL76 53

IP826S Fixed Depth Insertion Paddlewheel Meter, 316 SS, 4″-8″, DL76 73

IP826P Fixed Depth Insertion Paddlewheel Meter, PVC, 4″-8″, DL76 75

IP826Y Fixed Depth Insertion Paddlewheel Meter, Polypro, 4″-8″, DL76 88

IP826S-HP Fixed Depth Insertion Paddlewheel Meter, 316 SS, Hi Pres, 4″-8″, DL76 48

Option Code(s) Description

01 Rotor w/ Ceramic Shaft, PVDF, Kynar® 9

32 Tamper-Evident Kit, Wire, Seal 1

60 Viton® O-Ring 6

Note: If the -HP option is ordered, a Carbon or Stainless fitting must also be ordered.

HP units are not interchangable with standard units.

IP808 Series Fixed Depth Insertion Paddlewheel Meters (PD10 Meter Mount)

Model # Description

IP818B Fixed Depth Insertion Paddlewheel Meter, Brass, 1/2″-3″, PD10 30

IP818S Fixed Depth Insertion Paddlewheel Meter, 316 SS, 1/2″-3″, PD10 58

IP818P Fixed Depth Insertion Paddlewheel Meter, PVC, 1/2″-3″, PD10 61

IP818Y Fixed Depth Insertion Paddlewheel Meter, Polypro, 1/2″-3″, PD10 72

IP818S-HP Fixed Depth Insertion Paddlewheel Meter, 316 SS, Hi Pres, 1/2″-3″,PD10 33

IP828B Fixed Depth Insertion Paddlewheel Meter, Brass, 4″-8″, PD10 56

IP828S Fixed Depth Insertion Paddlewheel Meter, 316 SS, 4″-8″, PD10 76

IP828P Fixed Depth Insertion Paddlewheel Meter, PVC, 4″-8″, PD10 78

IP828Y Fixed Depth Insertion Paddlewheel Meter, Polypro, 4″-8″, PD10 91

IP828S-HP Fixed Depth Insertion Paddlewheel Meter, 316 SS, Hi Pres, 4″-8″, PD10 51

Option Code(s) Description

01 Rotor w/ Ceramic Shaft, PVDF, Kynar® 9

06 LMI Pump 4-Pin Connector 0

37 10 Ft. Cable for LMI Connector 2

60 Viton® O-Ring 6

106 Roytronics® Series-A Pump 5 Pin Connector 0

Note: If the -HP option is ordered, a Carbon or Stainless fitting must also be ordered.

HP units are not interchangable with standard units.

2014 Industrial  List V2 Page 48 January 01, 2014

Rev. 050114

IP800 Series Tee Fittings

Model # Description

Bronze

MF81TC-B-050 Tee Fitting, Bronze, Sweat, 1/2″, IP 24

MF81TC-B-075 Tee Fitting, Bronze, Sweat, 3/4″, IP 34

MF81TC-B-100 Tee Fitting, Bronze, Sweat, 1″, IP 44

MF81TC-B-150 Tee Fitting, Bronze, Sweat, 1-1/2″, IP 59

MF81TC-B-200 Tee Fitting, Bronze, Sweat, 2″, IP 79

MF81TC-B-300 Tee Fitting, Bronze, Sweat, 3″, IP 44

MF81TC-B-400 Tee Fitting, Bronze, Sweat, 4, IP 76

MF81T-B-050 Tee Fitting, Bronze, 1/2″, Threaded, IP 24

MF81T-B-075 Tee Fitting, Bronze, 3/4″, Threaded, IP 34

MF81T-B-100 Tee Fitting, Bronze, 1″, Threaded, IP 44

MF81T-B-150 Tee Fitting, Bronze, 1-1/2″, Threaded, IP 59

MF81T-B-200 Tee Fitting, Bronze, 2″, Threaded, IP 79

MF81T-B-300 Tee Fitting, Bronze, 3″, Threaded, IP 44

MF81T-B-400 Tee Fitting, Bronze, 4″, Threaded, IP 76

PVC

MF81T-P-050 Tee Fitting, PVC, 1/2″, IP 04

MF81T-P-075 Tee Fitting, PVC, 3/4″, IP 14

MF81T-P-100 Tee Fitting, PVC, 1″, IP 24

MF81T-P-150 Tee Fitting, PVC, 1-1/2″, IP 28

MF81T-P-200 Tee Fitting, PVC, 2″, IP 35

MF81T-P-200-18 Tee Fitting, PVC, Flanged Ends, 2″, IP 45

Carbon Steel

MF81T-C-050 Tee Fitting, Carbon Steel, 1/2″, IP 51

MF81T-C-075 Tee Fitting, Carbon Steel, 3/4″, IP 51

MF81T-C-100 Tee Fitting, Carbon Steel, 1″, IP 79

MF81T-C-150 Tee Fitting, Carbon Steel, 1-1/2″, IP 20

MF81T-C-200 Tee Fitting, Carbon Steel, 2″, IP 61

MF81T-C-200-34 Tee Fitting, Carbon Steel, Flanged Ends, 2″, IP 41

MF81T-C-050-HP Tee Fitting, Carbon Steel, Hi Pres, 1/2″, IP 66

MF81T-C-075-HP Tee Fitting, Carbon Steel, Hi Pres, 3/4″, IP 66

MF81T-C-100-HP Tee Fitting, Carbon Steel, Hi Pres, 1″, IP 94

MF81T-C-150-HP Tee Fitting, Carbon Steel, Hi Pres, 1-1/2″, IP 35

MF81T-C-200-HP Tee Fitting, Carbon Steel, Hi Pres, 2″, IP 76

MF81T-C-200-34-HP Tee Fitting, Carbon Steel, Flanged Ends, Hi Pres, 2″, IP 56

2014 Industrial  List V2 Page 49 January 01, 2014

Rev. 050114

IP800 Series Tee Fittings

Model # Description

Stainless Steel

MF81T-S-050 Tee Fitting, 304 SS, 1/2″, IP 16

MF81T-S-075 Tee Fitting, 304 SS, 3/4″, IP 16

MF81T-S-100 Tee Fitting, 304 SS, 1″, IP 57

MF81T-S-150 Tee Fitting, 304 SS, 1-1/2″, IP 67

MF81T-S-200 Tee Fitting, 304 SS, 2″, IP 77

MF81T-S-050-14 Tee Fitting, 316 SS, 1/2″, IP 52

MF81T-S-075-14 Tee Fitting, 316 SS, 3/4″, IP 62

MF81T-S-100-14 Tee Fitting, 316 SS, 1″, IP 18

MF81T-S-150-14 Tee Fitting, 316 SS, 1-1/2″, IP 38

MF81T-S-200-14 Tee Fitting, 316 SS, 2″, IP 63

MF81T-S-050-HP Tee Fitting, 304 SS, Hi Pres, 1/2″, IP 67

MF81T-S-075-HP Tee Fitting, 304 SS, Hi Pres, 3/4″, IP 77

MF81T-S-100-HP Tee Fitting, 304 SS, Hi Pres, 1″, IP 33

MF81T-S-150-HP Tee Fitting, 304 SS, Hi Pres, 1-1/2″, IP 53

MF81T-S-200-HP Tee Fitting, 304 SS, Hi Pres, 2″, IP 78

MF81T-S-050-14-HP Tee Fitting, 316 SS, Hi Pres, 1/2″, IP 67

MF81T-S-075-14-HP Tee Fitting, 316 SS, Hi Pres, 3/4″, IP 77

MF81T-S-100-14-HP Tee Fitting, 316 SS, Hi Pres, 1″, IP 33

MF81T-S-150-14-HP Tee Fitting, 316 SS, Hi Pres, 1-1/2″, IP 53

MF81T-S-200-14-HP Tee Fitting, 316 SS, Hi Pres, 2″, IP 78

MF81T-S-200-20 Tee Fitting, 304 SS, 2″, Flanged Ends, IP 17

MF81T-S-200-20-HP Tee Fitting, 304 SS,Flanged Ends, Hi Pres, 2″, IP 32

MF81T-S-200-14-20-HP Tee Fitting, 316 SS, Flanged Ends, Hi Pres, 2″, IP 118

IP800 Series Saddle Fittings

Model # Description

Ductile Iron

MF82S-F-300 Saddle, Iron, 3″ 72

MF82S-F-400 Saddle, Iron, 4″ 06

MF82S-F-600 Saddle, Iron, 6″ 61

MF82S-F-800 Saddle, Iron, 8″ 95

Bronze

MF82S-B-300 Saddle, Bronze, 3″ 74

MF82S-B-400 Saddle, Bronze, 4″ 15

PVC

MF82S-P-300 Saddle, PVC, 3″ 15

MF82S-P-400 Saddle, PVC, 4″ 31

MF82S-P-600 Saddle, PVC, 6″ 51

MF82S-P-800 Saddle, PVC, 8″ 79

Note: PVC saddles supplied with Buna-N O-rings only.

For Chemical service, O-ring must be removed and saddle glued to pipe with PVC cement.

See Instructions for more detail.

MF82S-P-300-16 Saddle, PVC, 3″, w/ 16″ Pipe Stub 84

MF82S-P-400-16 Saddle, PVC, 4″, w/ 16″ Pipe Stub 05

MF82S-P-600-16 Saddle, PVC, 6″, w/ 16″ Pipe Stub 30

MF82S-P-800-16 Saddle, PVC, 8″, w/ 16″ Pipe Stub 63

PVC saddles ordered with -16 option will be calibrated for K-Factor before shipping.

2014 Industrial  List V2 Page 50 January 01, 2014

Rev. 050114

IP800 Series Weld/Braze Fittings

Model # Description

Brass

MF82W-B-300 Weldolet, Brass, 3″ 40

MF82W-B-400 Weldolet, Brass, 4″ 40

MF82W-B-600 Weldolet, Brass, 6″ 40

MF82W-B-800 Weldolet, Brass, 8″ 40

Carbon Steel

MF82W-C-300 Weldolet, Carbon Steel, 3″ 18

MF82W-C-400 Weldolet, Carbon Steel, 4″ 18

MF82W-C-600 Weldolet, Carbon Steel, 6″ 18

MF82W-C-800 Weldolet, Carbon Steel, 8″ 18

MF82W-C-300-HP Weldolet, Carbon Steel, Hi Pres, 3″ 33

MF82W-C-400-HP Weldolet, Carbon Steel, Hi Pres, 4″ 33

MF82W-C-600-HP Weldolet, Carbon Steel, Hi Pres, 6″ 33

MF82W-C-800-HP Weldolet, Carbon Steel, Hi Pres, 8″ 33

Stainless Steel

MF82W-S-300 Weldolet, 316 SS, 3″ 06

MF82W-S-400 Weldolet, 316 SS, 4″ 06

MF82W-S-600 Weldolet, 316 SS, 6″ 06

MF82W-S-800 Weldolet, 316 SS, 8″ 06

MF82W-S-300-HP Weldolet, 316 SS, Hi Pres, 3″ 21

MF82W-S-400-HP Weldolet, 316 SS, Hi Pres, 4″ 21

MF82W-S-600-HP Weldolet, 316 SS, Hi Pres, 6″ 21

MF82W-S-800-HP Weldolet, 316 SS, Hi Pres, 8″ 21

2014 Industrial  List V2 Page 51 January 01, 2014

Rev. 050114

IP800 Series Parts & Accessories

Model # Description

103315 Bearing Assembly Kit, IP/TX, Kynar 8

100251 Cap, Blind, Brass, EX/IP/TX 80 Series 1

100249 Cap, Blind, Polypro, EX/IP/TX80 series 1

100248 Cap, Blind, PVC, EX/IP/TX80 series 1

100250 Cap, Blind, SS, EX/IP/TX80 series 0

100264 O-Ring, EPDM, Black 4

100219 O-Ring, Viton®, Brown 8

100508 Sensor Assy, Grey Micropowered, 18′ (For Battery Powered Displays) 00

100419 Sensor Assy, Blue, Low Power, 18′ (For External Powered Displays) 00

100298 Sensor Retaining Screw 1

100375 Spanner Tool, Sensor, Retain Screw 9

100035 Rotor w/ Shaft, PVDF, Kynar®, Tungsten Carbide Shaft, 6 Magnet, Hi-Res 6

100036 Rotor w/ Shaft, PVDF, Kynar®, Ceramic Shaft, 6 Magnet, Hi-Res 69

100317 Rotor Repair Kit, IP, Carbide Shaft (Rotor, Bearings, Shaft) 35

100043 Rotor Repair Kit, IP, Ceramic Shaft 08

101850 Cord Grip, 1/2″ NPT 8

100154 U-Clip, Retainer 6

100853 Seal, Security, w/12″ of Wire

100854 Wire, for Security Seal, 12″

102632 MK10, Mounting Kit, Meter Mount 6

102633 MK20, Mounting Kit, Wall Mount 19

2014 Industrial  List V2 Page 52 January 01, 2014

Rev. 050114

IP110/210 Adjustable Depth Insertion Paddlewheel Meter (Sensor Only)

Model # Description

IP110B Adj Depth Insertion Paddlewheel Meter, Brass, 3″-12″ 98

IP110P Adj Depth Insertion Paddlewheel Meter, PVC, 3″-12″ 03

IP110S Adj Depth Insertion Paddlewheel Meter, 316 SS, 3″-12″ 25

IP210B Adj Depth Insertion Paddlewheel Meter, Brass, 12″- 40″ 85

IP210P Adj Depth Insertion Paddlewheel Meter, PVC, 12″- 40″ 63

IP210S Adj Depth Insertion Paddlewheel Meter, 316 SS, 12″- 40″ 58

Option Code(s) Description

01 Rotor w/ Ceramic Shaft, PVDF, Kynar® 9

02 Adapter Fitting, 2″ NPT Threads, Brass 9

02 Adapter Fitting, 2″ NPT Threads, SS 6

04 Micropower Pickup (For Battery Powered Meters) NC

06 LMI Pump 4-Pin Connector 0

07 Seametrics Control Connector 0

23 Adapter, 1-1/2″ BSP Thread Tapered, Brass 3

24 Adapter, 1-1/2″ BSP Thread Tapered, SS 7

35 Old Style Adapter, 1-1/2″ NPT Thread 03

40 Immersible 0

72 12″ Extension (210/250 Series Only) 02

106 Roytronics® Series-A Pump 5-Pin Connector 0

IP150/250 Hot-Tap Adjustable Depth Insertion Paddlewheel Meter (Sensor Only)

Model # Description

IP150B Hot Tap Adj Depth Insertion Paddlewheel Meter, Brass, 3″-12″ 05

IP150P Hot Tap Adj Depth Insertion Paddlewheel Meter, PVC, 3″-12″ 48

IP150S Hot Tap Adj Depth Insertion Paddlewheel Meter, 316 SS, 3″-12″ 35

IP250B Hot Tap Adj Depth Insertion Paddlewheel Meter, Brass, 12″- 40″ 56

IP250P Hot Tap Adj Depth Insertion Paddlewheel Meter, PVC, 12″- 40″ 23

IP250S Hot Tap Adj Depth Insertion Paddlewheel Meter, 316 SS, 12″- 40″ 65

Option Code(s) Description

01 Rotor w/ Ceramic Shaft, PVDF, Kynar® 9

04 Micropower Pickup (For Battery Powered Meters) NC

06 LMI Pump 4-Pin Connector 0

07 Seametrics Control Connector 0

08 316 SS Valve Assy (SS Meters Only) 97

09 No Valve Assembly (Deduct ) (8)

40 Immersible 0

72 12″ Extension (210/250 Series Only) 02

106 Roytronics® Series-A Pump 5-Pin Connector 0

2014 Industrial  List V2 Page 53 January 01, 2014

Rev. 050114

IP111/211 Adjustable Depth Insertion Paddlewheel Meter (FT420 Meter Mount)

Model # Description

IP111B Adj Depth Insertion Paddlewheel Meter, Brass, 3″-12″, FT420 68

IP111P Adj Depth Insertion Paddlewheel Meter, PVC, 3″-12″, FT420 73

IP111S Adj Depth Insertion Paddlewheel Meter, 316 SS, 3″-12″, FT420 095

IP211B Adj Depth Insertion Paddlewheel Meter, Brass, 12″- 40″, FT420 055

IP211P Adj Depth Insertion Paddlewheel Meter, PVC, 12″- 40″, FT420 33

IP211S Adj Depth Insertion Paddlewheel Meter, 316 SS, 12″- 40″, FT420 128

Option Code(s) Description

01 Rotor w/ Ceramic Shaft, PVDF, Kynar® 9

02 Adapter Fitting, 2″ NPT Threads, Brass 9

02 Adapter Fitting, 2″ NPT Threads, SS 6

23 Adapter, 1-1/2″ BSP Thread Tapered, Brass 3

24 Adapter, 1-1/2″ BSP Thread Tapered, SS 7

32 Tamper-Evident Kit, Wire, Seal 1

35 Old Style Adapter, 1-1/2″ NPT Thread 03

64 Non-Resettable Total 7

72 12″ Extension (210/250 Series Only) 02

98 Dual Relay Output 9

126 Hinged Display Cover 3

IP151/251 Hot-Tap Adjustable Depth Insertion Paddlewheel Meter (FT420 Meter Mount)

Model # Description

IP151B Hot Tap Adj Depth Insertion Paddlewheel Meter, Brass, 3″-12″, FT420 275

IP151P Hot Tap Adj Depth Insertion Paddlewheel Meter, PVC, 3″-12″, FT420 218

IP151S Hot Tap Adj Depth Insertion Paddlewheel Meter, 316 SS, 3″-12″, FT420 405

IP251B Hot Tap Adj Depth Insertion Paddlewheel Meter, Brass, 12″- 40″, FT420 326

IP251P Hot Tap Adj Depth Insertion Paddlewheel Meter, PVC, 12″- 40″, FT420 293

IP251S Hot Tap Adj Depth Insertion Paddlewheel Meter, 316 SS, 12″- 40″, FT420 435

Option Code(s) Description

01 Rotor w/ Ceramic Shaft, PVDF, Kynar® 9

08 316 SS Valve Assy (SS Meters Only) 97

09 No Valve Assembly (Deduct ) (8)

64 Non-Resettable Total 7

72 12″ Extension (210/250 Series Only) 02

98 Dual Relay Output 9

126 Hinged Display Cover 3

2014 Industrial  List V2 Page 54 January 01, 2014

Rev. 050114

IP112/212 Adjustable Depth Insertion Paddlewheel Meter (AO55 Meter Mount)

Model # Description

IP112B Adj Depth Insertion Paddlewheel Meter, Brass, 3″-12″, AO55 68

IP112P Adj Depth Insertion Paddlewheel Meter, PVC, 3″-12″, AO55 73

IP112S Adj Depth Insertion Paddlewheel Meter, 316 SS, 3″-12″, AO55 95

IP212B Adj Depth Insertion Paddlewheel Meter, Brass, 12″- 40″, AO55 55

IP212P Adj Depth Insertion Paddlewheel Meter, PVC, 12″- 40″, AO55 33

IP212S Adj Depth Insertion Paddlewheel Meter, 316 SS, 12″- 40″, AO55 028

Option Code(s) Description

01 Rotor w/ Ceramic Shaft, PVDF, Kynar® 9

02 Adapter Fitting, 2″ NPT Threads, Brass 9

02 Adapter Fitting, 2″ NPT Threads, SS 6

06 LMI Pump 4-Pin Connector 0

23 Adapter, 1-1/2″ BSP Thread Tapered, Brass 3

24 Adapter, 1-1/2″ BSP Thread Tapered, SS 7

35 Old Style Adapter, 1-1/2″ NPT Thread 03

72 12″ Extension (210/250 Series Only) 02

106 Roytronics® Series-A Pump 5-Pin Connector 0

IP152/252 Hot-Tap Adjustable Depth Insertion Paddlewheel Meter (AO55 Meter Mount)

Model # Description

IP152B Hot Tap Adj Depth Insertion Paddlewheel Meter, Brass, 3″-12″, AO55 175

IP152P Hot Tap Adj Depth Insertion Paddlewheel Meter, PVC, 3″-12″, AO55 118

IP152S Hot Tap Adj Depth Insertion Paddlewheel Meter, 316 SS, 3″-12″, AO55 305

IP252B Hot Tap Adj Depth Insertion Paddlewheel Meter, Brass, 12″- 40″, AO55 226

IP252P Hot Tap Adj Depth Insertion Paddlewheel Meter, PVC, 12″- 40″, AO55 193

IP252S Hot Tap Adj Depth Insertion Paddlewheel Meter, 316 SS, 12″- 40″, AO55 335

Option Code(s) Description

01 Rotor w/ Ceramic Shaft, PVDF, Kynar® 9

06 LMI Pump 4-Pin Connector 0

08 316 SS Valve Assy (SS Meters Only) 97

09 No Valve Assembly (Deduct ) (8)

72 12″ Extension (210/250 Series Only) 02

106 Roytronics® Series-A Pump 5-Pin Connector 0

2014 Industrial  List V2 Page 55 January 01, 2014

Rev. 050114

IP114/214 Adjustable Depth Insertion Paddlewheel Meter (FT415 Meter Mount)

Model # Description

IP114B Adj Depth Insertion Paddlewheel Meter, Brass, 3″-12″, FT415 94

IP114P Adj Depth Insertion Paddlewheel Meter, PVC, 3″-12″, FT415 99

IP114S Adj Depth Insertion Paddlewheel Meter, 316 SS, 3″-12″, FT415 121

IP214B Adj Depth Insertion Paddlewheel Meter, Brass, 12″- 40″, FT415 081

IP214P Adj Depth Insertion Paddlewheel Meter, PVC, 12″- 40″, FT415 59

IP214S Adj Depth Insertion Paddlewheel Meter, 316 SS, 12″- 40″, FT415 154

Option Code(s) Description

01 Rotor w/ Ceramic Shaft, PVDF, Kynar® 9

02 Adapter Fitting, 2″ NPT Threads, Brass 9

02 Adapter Fitting, 2″ NPT Threads, SS 6

23 Adapter, 1-1/2″ BSP Thread Tapered, Brass 3

24 Adapter, 1-1/2″ BSP Thread Tapered, SS 7

32 Tamper-Evident Kit, Wire, Seal 1

35 Old Style Adapter, 1-1/2″ NPT Thread 03

64 Non-Resettable Total 7

72 12″ Extension (210/250 Series Only) 02

126 Hinged Display Cover 3

IP154/254 Hot-Tap Adjustable Depth Insertion Paddlewheel Meter (FT415 Meter Mount)

Model # Description

IP154B Hot Tap Adj Depth Insertion Paddlewheel Meter, Brass, 3″-12″, FT415 301

IP154P Hot Tap Adj Depth Insertion Paddlewheel Meter, PVC, 3″-12″, FT415 244

IP154S Hot Tap Adj Depth Insertion Paddlewheel Meter, 316 SS, 3″-12″, FT415 431

IP254B Hot Tap Adj Depth Insertion Paddlewheel Meter, Brass, 12″- 40″, FT415 461

IP254P Hot Tap Adj Depth Insertion Paddlewheel Meter, PVC, 12″- 40″, FT415 319

IP254S Hot Tap Adj Depth Insertion Paddlewheel Meter, 316 SS, 12″- 40″, FT415 352

Option Code(s) Description

01 Rotor w/ Ceramic Shaft, PVDF, Kynar® 9

08 316 SS Valve Assy (SS Meters Only) 97

09 No Valve Assembly (Deduct ) (8)

32 Tamper-Evident Kit, Wire, Seal 1

64 Non-Resettable Total 7

72 12″ Extension (210/250 Series Only) 02

126 Hinged Display Cover 3

2014 Industrial  List V2 Page 56 January 01, 2014

Rev. 050114

IP116/216 Adjustable Depth Insertion Paddlewheel Meter (DL76 Meter Mount)

Model # Description

IP116B Adj Depth Insertion Paddlewheel Meter, Brass, 3″-12″, DL76 53

IP116P Adj Depth Insertion Paddlewheel Meter, PVC, 3″-12″, DL76 58

IP116S Adj Depth Insertion Paddlewheel Meter, 316 SS, 3″-12″, DL76 80

IP216B Adj Depth Insertion Paddlewheel Meter, Brass, 12″- 40″, DL76 40

IP216P Adj Depth Insertion Paddlewheel Meter, PVC, 12″- 40″, DL76 18

IP216S Adj Depth Insertion Paddlewheel Meter, 316 SS, 12″- 40″, DL76 013

Option Code(s) Description

01 Rotor w/ Ceramic Shaft, PVDF, Kynar® 9

02 Adapter Fitting, 2″ NPT Threads, Brass 9

02 Adapter Fitting, 2″ NPT Threads, SS 6

23 Adapter, 1-1/2″ BSP Thread Tapered, Brass 3

24 Adapter, 1-1/2″ BSP Thread Tapered, SS 7

32 Tamper-Evident Kit, Wire, Seal 1

35 Old Style Adapter, 1-1/2″ NPT Thread 03

72 12″ Extension (210/250 Series Only) 02

IP156/256 Hot-Tap Adjustable Depth Insertion Paddlewheel Meter (DL76 Meter Mount)

Model # Description

IP156B Hot Tap Adj Depth Insertion Paddlewheel Meter, Brass, 3″-12″, DL76 160

IP156P Hot Tap Adj Depth Insertion Paddlewheel Meter, PVC, 3″-12″, DL76 103

IP156S Hot Tap Adj Depth Insertion Paddlewheel Meter, 316 SS, 3″-12″, DL76 290

IP256B Hot Tap Adj Depth Insertion Paddlewheel Meter, Brass, 12″- 40″, DL76 211

IP256P Hot Tap Adj Depth Insertion Paddlewheel Meter, PVC, 12″- 40″, DL76 178

IP256S Hot Tap Adj Depth Insertion Paddlewheel Meter, 316 SS, 12″- 40″, DL76 320

Option Code(s) Description

01 Rotor w/ Ceramic Shaft, PVDF, Kynar® 9

08 316 SS Valve Assy (SS Meters Only) 97

09 No Valve Assembly (Deduct ) (8)

32 Tamper-Evident Kit, Wire, Seal 1

72 12″ Extension (210/250 Series Only) 02

2014 Industrial  List V2 Page 57 January 01, 2014

Rev. 050114

IP118/218 Adjustable Depth Insertion Paddlewheel Meter (PD10 Meter Mount)

Model # Description

IP118B Adj Depth Insertion Paddlewheel Meter, Brass, 3″-12″, PD10 56

IP118P Adj Depth Insertion Paddlewheel Meter, PVC, 3″-12″, PD10 61

IP118S Adj Depth Insertion Paddlewheel Meter, 316 SS, 3″-12″, PD10 83

IP218B Adj Depth Insertion Paddlewheel Meter, Brass, 12″- 40″, PD10 43

IP218P Adj Depth Insertion Paddlewheel Meter, PVC, 12″- 40″, PD10 21

IP218S Adj Depth Insertion Paddlewheel Meter, 316 SS, 12″- 40″, PD10 16

Option Code(s) Description

01 Rotor w/ Ceramic Shaft, PVDF, Kynar® 9

02 Adapter Fitting, 2″ NPT Threads, Brass 9

02 Adapter Fitting, 2″ NPT Threads, SS 6

06 LMI Pump 4-Pin Connector 0

23 Adapter, 1-1/2″ BSP Thread Tapered, Brass 3

24 Adapter, 1-1/2″ BSP Thread Tapered, SS 7

35 Old Style Adapter, 1-1/2″ NPT Thread 03

37 10 Ft. Cable for LMI Connector 2

72 12″ Extension (210/250 Series Only) 02

106 Roytronics® Series-A Pump 5-Pin Connector 0

IP158/258 Hot-Tap Adjustable Depth Insertion Paddlewheel Meter (PD10 Meter Mount)

Model # Description

IP158B Hot Tap Adj Depth Insertion Paddlewheel Meter, Brass, 3″-12″, PD10 63

IP158P Hot Tap Adj Depth Insertion Paddlewheel Meter, PVC, 3″-12″, PD10 06

IP158S Hot Tap Adj Depth Insertion Paddlewheel Meter, 316 SS, 3″-12″, PD10 093

IP258B Hot Tap Adj Depth Insertion Paddlewheel Meter, Brass, 12″- 40″, PD10 014

IP258P Hot Tap Adj Depth Insertion Paddlewheel Meter, PVC, 12″- 40″, PD10 81

IP258S Hot Tap Adj Depth Insertion Paddlewheel Meter, 316 SS, 12″- 40″, PD10 123

Option Code(s) Description

01 Rotor w/ Ceramic Shaft, PVDF, Kynar® 9

06 LMI Pump 4-Pin Connector 0

08 316 SS Valve Assy (SS Meters Only) 97

09 No Valve Assembly (Deduct ) (8)

72 12″ Extension (210/250 Series Only) 02

106 Roytronics® Series-A Pump 5-Pin Connector 0

2014 Industrial  List V2 Page 58 January 01, 2014

Rev. 050114

Saddle Fittings For IP110/210 Meters

Model # Description

MF101F-300-150 Saddle, Iron, NPT Thread, 3″ X 1-1/2″ 36

MF101F-400-150 Saddle, Iron, NPT Thread, 4″ X 1-1/2″ 44

MF101F-600-150 Saddle, Iron, NPT Thread, 6″ X 1-1/2″ 48

MF101F-800-150 Saddle, Iron, NPT Thread, 8″ X 1-1/2″ 78

MF101F-1000-150 Saddle, Iron, NPT Thread, 10″ X 1-1/2″ 58

MF101F-1200-150 Saddle, Iron, NPT Thread, 12″ X 1-1/2″ 20

MF101F-1400-150 Saddle, Iron, NPT Thread, 14″ X 1-1/2″ 90

MF101F-1600-150 Saddle, Iron, NPT Thread, 16″ X 1-1/2″ 55

MF101F-1800-150 Saddle, Iron, NPT Thread, 18″ X 1-1/2″ 29

MF101F-2000-150 Saddle, Iron, NPT Thread, 20″ X 1-1/2″ 02

MF101F-2200-150 Saddle, Iron, NPT Thread, 22″ X 1-1/2″ 50

MF101F-2400-150 Saddle, Iron, NPT Thread, 24″ X 1-1/2″ 95

MF101B-300-150 Saddle, Bronze, NPT Thread, 3″ X 1-1/2″ 93

MF101B-400-150 Saddle, Bronze, NPT Thread 4″ X 1-1/2″ 24

Saddle Fittings For IP150/250

Model # Description

MF101F-300-200 Saddle, Iron, NPT Thread, 3″ X 2″ 36

MF101F-400-200 Saddle, Iron, NPT Thread, 4″ X 2″ 44

MF101F-600-200 Saddle, Iron, NPT Thread, 6″ X 2″ 48

MF101F-800-200 Saddle, Iron, NPT Thread, 8″ X 2″ 78

MF101F-1000-200 Saddle, Iron, NPT Thread, 10″ X 2″ 58

MF101F-1200-200 Saddle, Iron, NPT Thread, 12″ X 2″ 20

MF101F-1400-200 Saddle, Iron, NPT Thread, 14″ X 2″ 90

MF101F-1600-200 Saddle, Iron, NPT Thread, 16″ X 2″ 55

MF101F-1800-200 Saddle, Iron, NPT Thread, 18″ X 2″ 29

MF101F-2000-200 Saddle, Iron, NPT Thread, 20″ X 2″ 02

MF101F-2200-200 Saddle, Iron, NPT Thread, 22″ X 2″ 50

MF101F-2400-200 Saddle, Iron, NPT Thread, 24″ X 2″ 95

MF101B-300-200 Saddle, Bronze, NPT Thread, 3″ X 2″ 93

MF101B-400-200 Saddle, Bronze, NPT Thread, 4″ X 2″ 24

2014 Industrial  List V2 Page 59 January 01, 2014

Rev. 050114

IP110/210 Parts & Accessories

Model # Description

100845 Brass Adapter Fitting, NPT Thread, 1-1/2″ 28

100846 SS Adapter Fitting, NPT Thread, 1-1/2″ 08

100816 Brass Adapter Fitting, NPT Thread, 2″ 0

100873 SS Adapter Fitting, NPT Thread, 2″ 03

100059 Brass Adapter Fitting, NPT Thread, 1-1/2″, 2pc, Old Style 28

100082 SS Adapter Fitting, NPT Thread, 1-1/2″, 2pc, OldStyle 08

100345 O-Ring, EPDM 4

103315 Bearing Assembly Kit, IP/TX, Kynar 8

100358 Compression Ferrule, Kynar® 4

100064 Nut, Compression, Brass 4

100084 Nut, Compression, SS 7

100662 Housing Assy, Upper, Blind (Gasket, Screws, Washers, Label) 2

100411 Gasket, Upper Housing 3

100414 Screw/Washer Kit, Upper housing (Qty 4) 1

100374 Mandrel, Rotor Housing, Tool, IP/TX 4

100508 Sensor Assy, Grey Micropowered, 18′ (For Battery Powered Displays) 00

100419 Sensor Assy, Blue, Low Power, 18′ (For External Powered Displays) 00

100360 Plug, Steel, 1/2″ 8

100035 Rotor w/ Shaft, PVDF, Kynar®, Tungsten Carbide Shaft, 6 Magnet, Hi-Res 6

100036 Rotor w/ Shaft, PVDF, Kynar®, Ceramic Shaft, 6 Magnet, Hi-Res 69

100068 Housing, Rotor, Brass, IP 0

100118 Housing, Rotor, 316 SS, IP 63

100218 Rotor Housing O-Ring, EPDM 4

100317 Rotor Repair Kit, IP, Carbide Shaft (Rotor, Bearings, Shaft) 35

100043 Rotor Repair Kit, IP, Ceramic Shaft 08

101850 Cord Grip, 1/2″ NPT 8

100364 Cord Grip 1/4″ I.D. 2

100853 Seal, Security, w/12″ of Wire

100854 Wire, for Security Seal, 12″

100556 Rotor Repair Kit, Kynar® Silicone Carbide, 6 Magnet 85

2014 Industrial  List V2 Page 60 January 01, 2014

Rev. 050114

IP150/250 Parts & Accessories

Model # Description

100384 Adapter, Brass, Hot-Tap, NPT Thread 37

100358 Compression Ferrule, Kynar® 4

100345 O-Ring, EPDM 4

100069 Valve Assy, Brass, Hot-Tap 49

100119 Valve Assy, 316 SS, Hot-Tap 45

103315 Bearing Assembly Kit, IP/TX, Kynar 8

100062 Cap, Blind, Brass IP/TX 1

100063 Cap, Blind, SS, IP 7

100061 Collar, Locking, Brass 42

100116 Collar, Locking, SS 07

100358 Compression Ferrule, Kynar® 4

100064 Nut, Compression, Brass 4

100084 Nut, Compression, SS 7

100662 Housing Assy, Upper, Blind (Gasket, Screws, Washers, Label) 2

100411 Gasket, Upper Housing 3

100414 Screw/Washer Kit, Upper housing (Qty 4) 1

100374 Mandrel, Rotor Housing, Tool, IP/TX 4

100508 Sensor Assy, Grey Micropowered, 18′ (For Battery Powered Displays) 00

100419 Sensor Assy, Blue, Low Power, 18′ (For External Powered Displays) 00

100360 Plug, Steel, 1/2″ 8

100035 Rotor w/ Shaft, PVDF, Kynar®, Tungsten Carbide Shaft, 6 Magnet, Hi-Res 6

100036 Rotor w/ Shaft, PVDF, Kynar®, Ceramic Shaft, 6 Magnet, Hi-Res 69

100068 Housing, Rotor, Brass, IP 0

100118 Housing, Rotor, 316 SS, IP 63

100218 Rotor Housing O-Ring, EPDM 4

100317 Rotor Repair Kit, IP, Carbide Shaft (Rotor, Bearings, Shaft) 35

100043 Rotor Repair Kit, IP, Ceramic Shaft 08

101850 Cord Grip, 1/2″ NPT 8

100364 Cord Grip 1/4″ I.D. 2

100853 Seal, Security, w/12″ of Wire

100854 Wire, for Security Seal, 12″

Model # Description

WTC100-200 In-Line Turbine Meter, Carbon Steel, 2″ Sensor Only 035

WTC101-200 In-Line Turbine Meter, Carbon Steel, 2″, FT420 505

WTC102-200 In-Line Turbine Meter, Carbon Steel, 2″, AO55 405

WTC104-200 In-Line Turbine Meter, Carbon Steel, 2″, FT415 531

Option Code(s) Description

34 2″ Body 80

WTC100-300 In-Line Turbine Meter, Carbon Steel, 3″ Sensor Only 299

WTC101-300 In-Line Turbine Meter, Carbon Steel, 3″, FT420 769

WTC102-300 In-Line Turbine Meter, Carbon Steel, 3″, AO55 669

WTC104-300 In-Line Turbine Meter, Carbon Steel, 3″, FT415 795

WTC100-400 In-Line Turbine Meter, Carbon Steel, 4″ Sensor Only 583

WTC101-400 In-Line Turbine Meter, Carbon Steel, 4″, FT420 053

WTC102-400 In-Line Turbine Meter, Carbon Steel, 4″, AO55 953

WTC104-400 In-Line Turbine Meter, Carbon Steel, 4″, FT415 079

WTC100-600 In-Line Turbine Meter, Carbon Steel, 6″ Sensor Only 470

WTC101-600 In-Line Turbine Meter, Carbon Steel, 6″, FT420 940

WTC102-600 In-Line Turbine Meter, Carbon Steel, 6″, AO55 840

WTC104-600 In-Line Turbine Meter, Carbon Steel, 6″, FT415 966

WTC100-800 In-Line Turbine Meter, Carbon Steel, 8″ Sensor Only 214

WTC101-800 In-Line Turbine Meter, Carbon Steel, 8″, FT420 684

WTC102-800 In-Line Turbine Meter, Carbon Steel, 8″, AO55 584

WTC104-800 In-Line Turbine Meter, Carbon Steel, 8″, FT415 710

Note: -800 Meters Ship by truck only. Additional freight charge may apply.

Option Code(s) Description

04 Micropower Pickup (100 Series only) NC

64 Non-Resettable Total 7

98 Dual Relay Output 9

119 Carbide Shaft 27

126 Hinged Display Cover 3

Note: Hinged Display Cover is recommended for all outdoor applications for FT415 and FT420.

2014 Industrial  List V2 Page 64 January 01, 2014

Rev. 050114

WTP PVC In-Line Turbine Meter

Model # Description

WTP100-200 In-Line Turbine Meter, PVC, 2″ Sensor Only 02

WTP101-200 In-Line Turbine Meter, PVC, 2″, FT420 272

WTP102-200 In-Line Turbine Meter, PVC, 2″, AO55 172

WTP104-200 In-Line Turbine Meter, PVC, 2″, FT415 298

Option Code(s) Description

18 Flanged Ends 10

WTP100-300 In-Line Turbine Meter, PVC, 3″ Sensor Only 60

WTP101-300 In-Line Turbine Meter, PVC, 3″, FT420 430

WTP102-300 In-Line Turbine Meter, PVC, 3″, AO55 330

WTP104-300 In-Line Turbine Meter, PVC, 3″, FT415 456

Option Code(s) Description

18 Flanged Ends 24

WTP100-400 In-Line Turbine Meter, PVC, 4″ Sensor Only 128

WTP101-400 In-Line Turbine Meter, PVC, 4″, FT420 598

WTP102-400 In-Line Turbine Meter, PVC, 4″, AO55 498

WTP104-400 In-Line Turbine Meter, PVC, 4″, FT415 624

Option Code(s) Description

18 Flanged Ends 58

WTP100-600 In-Line Turbine Meter, PVC, 6″ Sensor Only 451

WTP101-600 In-Line Turbine Meter, PVC, 6″, FT420 921

WTP102-600 In-Line Turbine Meter, PVC, 6″, AO55 821

WTP104-600 In-Line Turbine Meter, PVC, 6″, FT415 947

Option Code(s) Description

18 Flanged Ends 34

WTP Options for all Sizes

Option Code(s) Description

04 Micropower Pickup (100 Series only) NC

64 Non-Resettable Total 7

98 Dual Relay Output 9

119 Carbide Shaft 27

126 Hinged Display Cover 3

Note: Hinged Display Cover is recommended for all outdoor applications for FT415 and FT420.

2014 Industrial  List V2 Page 65 January 01, 2014

Rev. 050114

WTS Stainless Steel In-Line Turbine Meter

Model # Description

WTS100-200 In-Line Turbine Meter, 304 SS, 2″ 655

WTS101-200 In-Line Turbine Meter, 304 SS, 2″, FT420 125

WTS102-200 In-Line Turbine Meter, 304 SS, 2″, AO55 025

WTS104-200 In-Line Turbine Meter, 304 SS, 2″, FT415 151

Option Code(s) Description

14 All 316 SS 28

20 Flanged Ends 40

WTS100-300 In-Line Turbine Meter, 304 SS, 3″ 250

WTS101-300 In-Line Turbine Meter, 304 SS, 3″, FT420 720

WTS102-300 In-Line Turbine Meter, 304 SS, 3″, AO55 620

WTS104-300 In-Line Turbine Meter, 304 SS, 3″, FT415 746

Option Code(s) Description

14 All 316 SS 54

WTS100-400 In-Line Turbine Meter, 304 SS, 4″ 670

WTS101-400 In-Line Turbine Meter, 304 SS, 4″, FT420 140

WTS102-400 In-Line Turbine Meter, 304 SS, 4″, AO55 040

WTS104-400 In-Line Turbine Meter, 304 SS, 4″, FT415 166

Option Code(s) Description

14 All 316 SS 014

WTS100-600 In-Line Turbine Meter, 304 SS, 6″ 634

WTS101-600 In-Line Turbine Meter, 304 SS, 6″, FT420 104

WTS102-600 In-Line Turbine Meter, 304 SS, 6″, AO55 004

WTS104-600 In-Line Turbine Meter, 304 SS, 6″, FT415 130

Option Code(s) Description

14 All 316 SS 380

WTS100-800 In-Line Turbine Meter, 304 SS, 8″ 317

WTS101-800 In-Line Turbine Meter, 304 SS, 8″, FT420 787

WTS102-800 In-Line Turbine Meter, 304 SS, 8″, AO55 687

WTS104-800 In-Line Turbine Meter, 304 SS, 8″, FT415 813

Note: -800 shipped by truck only, additional freight charges may apply.

Option Code(s) Description

14 All 316 SS 639

WTS Options for all Sizes

Option Code(s) Description

04 Micropower Pickup (100 Series only) NC

64 Non-Resettable Total 7

98 Dual Relay Output 9

119 Carbide Shaft 27

126 Hinged Display Cover 3

Note: Hinged Display Cover is recommended for all outdoor applications for FT415 and FT420.

2014 Industrial  List V2 Page 66 January 01, 2014

Rev. 050114

WT Series Parts & Accessories

Model # Description

Parts for all WT Meters

100471 AO55 Replacement Module 65

100373 Battery, Lithium, 3.6V, 8.5Ah, C Size 6

100262 Flange, Blanking, SS, 3-8″ 19

100469 FT415 Replacement Module 91

100495 FT420 Replacement Module 65

100662 Housing Assy, Upper, Blind (Gasket, Screws, Washers, Label) 2

100411 Gasket, Upper Housing 3

100414 Screw/Washer Kit, Upper housing (Qty 4) 1

100264 O-Ring, EPDM, Black 4

100508 Sensor Assy, Grey Micropowered, 18′ (For Battery Powered Displays) 00

100419 Sensor Assy, Blue, Low Power, 18′ (For External Powered Displays) 00

100298 Sensor Retaining Screw 1

100375 Spanner Tool, Sensor, Retain Screw 9

100360 Plug, Steel, 1/2″ 8

100152 Rotor & Bearings Assy, WT, Kynar® 75

100333 Rotor Repair Kit, WT, PVDF, Ceramic Shaft (100152 & 100227) 06

100661 Rotor Repair Kit, WT, Carbide Shaft (11152 & 100660) 15

103317 Shaft Assy Kit, Carbide, WT 3″ to 8″ 50

103312 Kit, Shaft Assembly, Ceramic, WT/TX 20

101850 Cord Grip, 1/2″ NPT 8

100364 Cord Grip 1/4″ I.D. 2

100154 U-Clip, Retainer 6

For WTC Only

101443 Flange, Blanking, Carbon Steel, 3″-8″ 25

101446 Insert Assy, WTC/WTS 2″ 52

101442 Insert Assy, WTC, 3″-8″ 11

100270 O-Ring, EPDM 1

For WTP Only

100437 Insert Assy, WTP 2″ 99

100438 Insert Assy, WTP 3″ 34

100439 Insert Assy, WTP100-4″ to 6″ 90

103309 Kit, 1/4-20 x 1″ M/S, SS, WT 2

100214 O-Ring, EPDM 8

For WTS Only

101446 Insert Assy, WTC/WTS 2″ 52

100262 Flange, Blanking, SS, 3-8″ 19

100440 Insert Assy, WTS, 3″ to 8″ 47

100270 O-Ring, EPDM 1

For WT -200 meters purchased BEFORE January 1, 2011 Only

100327 Rotor, Kynar®, Ceramic Shaft 68

100325 Rotor Repair Kit, TX, Kynar®, Ceramic Shaft (Rotor, Bearings, Shaft) 00

For WT -200 meters purchased AFTER January 1, 2011 Only

101862 Rotor Assy, Kynar® w/ Carbide Shaft, TX 35

101912 Rotor Repair Kit, TX, Kynar®, Carbide Shaft (Rotor, Bearings, Shaft) 59

2014 Industrial  List V2 Page 67 January 01, 2014WMP101-100 Plastic Bodied In-Line Magmeter, DC Powered, 1″ 64

WMP101-200 Plastic Bodied In-Line Magmeter, DC Powered, 2″ 35

WMP101-300 Plastic Bodied In-Line Magmeter, DC Powered, 3″ 128

WMP104-100 Plastic Bodied In-Line Magmeter, Battery Powered, 1″ 65

WMP104-200 Plastic Bodied In-Line Magmeter, Battery Powered, 2″ 36

WMP104-300 Plastic Bodied In-Line Magmeter, Battery Powered, 3″ 96

Option Code(s) Description

32 Tamper-Evident Kit, Wire, Seal 1

93 BSP Fitting Kit (Male Thread, Replaces Standard NPT Kit) NC

96 No Fitting Kit 2″ (Deduct ) (5)

96 No Fitting Kit 3″ (Deduct ) (5)

133 Extended Battery Life (WMP104 only) 8

Specify desired rate and total at time of order. See below for available units.

Any rate selection can be combined with any total selection.

If ordering a WMP101, a pulse rate must be specified at time of order.

Pulse rates are not available on the WMP104.

WMP FLOW MEASUREMENT UNITS

RATE

Gal/Min

Liter/Min

Liters/Sec

Cu Ft/Sec

Cu Ft/Min

Cu Meter/Min

Cu Meter/Hr

Mil Gal/Day

Meg Lit/Day

ORDER

= GPM

= LPM

= LPS

= CFS

= CFM

= CMM

= CMH

= MGD

= MLD

ORDER

= G

= GT

= L

= ML

= CM

= CMT

= CF

TOTAL

Gal

Gal x 100

Liter

Mega Liters

Cubic Meters

Cu Met x 1000

Cubic Feet

PULSE RATE

High Frequency

1 Units/Pulse

ORDER

= -HF

= -PxU

(Units = Gal or Liter based on

Rate/Total unit Selection)

Ordering Example WMP101:

WMP101-200-GPM/G-HF

Ordering Example WMP104:

WMP104-200-GPM/G

WMP Parts & Accessories

Model # Description

101222 Kit, 2″ WMP FNPT Flange Clamps 9

102073 Kit, 3″ WMP FNPT Flange Clamps 62

102203 Kit, 2″, WMP BSP Flange Clamps (Male Thread) 1

102204 Kit, 3″, WMP BSP Flange Clamps (Male Thread) 62

101492 Cordset, 5 Pin, 6 Meter, Power/Output Cable for WMP101 7

101594 Replacement Batteries, WMP, 2 C-Cell (WMP104 only) 4

101949 Hinged Display Cover 7

100853 Seal, Security, w/12″ of Wire

100854 Wire, for Security Seal, 12″

WMX101-400 Flanged In-Line Magmeter, 2 AA Backup Batteries, 4″ 962

WMX101-600 Flanged In-Line Magmeter, 2 AA Backup Batteries, 6″ 113

WMX101-800 Flanged In-Line Magmeter, 2 AA Backup Batteries, 8″ 345

WMX101-1000 Flanged In-Line Magmeter, 2 AA Backup Batteries, 10″ 699

WMX101-1200 Flanged In-Line Magmeter, 2 AA Backup Batteries, 12″ 900

WMX104-400 Flanged In-Line Magmeter, 2 DD Cell Batteries, 4″ 862

WMX104-600 Flanged In-Line Magmeter, 2 DD Cell Batteries, 6″ 013

WMX104-800 Flanged In-Line Magmeter, 2 DD Cell Batteries, 8″ 245

WMX104-1000 Flanged In-Line Magmeter, 2 DD Cell Batteries, 10″ 599

WMX104-1200 Flanged In-Line Magmeter, 2 DD Cell Batteries, 12″ 800

Option Code(s) Description

11/6 Factory-Installed Power/Output Cable, 6m (20 ft) 00

11/15 Factory-Installed Power/Output Cable, 15m (50 ft) 47

11/30 Factory-Installed Power/Output Cable, 30m (100 ft) 83

127 Internal Data Logger 75

Specify desired rate at time of order. See below for available units.

Any rate selection can be combined with any total selection. Default pulse rate is High Frequency.

If ordering the WMX101, a pulse rate must be specified as well.

WMX FLOW MEASUREMENT UNITS

RATE

Gal/Min

Liter/Min

Liters/Sec

Cu Ft/Min

Cu Meter/Hr

Mil Gal/Day

Meg Lit/Day

ORDER

= GPM

= LPM

= LPS

= CFM

= CMH

= MGD

= MLD

ORDER

= G

= GT

= L

= LT

= ML

= CM

= CMT

= CF

= CFT

TOTAL

Gal

Gal x 1000

Liter

Liter x 1000

Mega Liters

Cubic Meters

Cu Met x 1000

Cubic Feet

Cu Feet x 1000

PULSE RATE

High Frequency

10 Units/Pulse

100 Units/Pulse

1000 Units/Pulse

ORDER

= -HF

= -PxX

= -PxH

= -PxK

(Units = Gal or Liter based on

Rate/Total unit Selection)

Ordering Example WMX101 NO CABLE:

WMX101-400-GPM/CFT

Ordering Example WMX101 W/CABLE:

WMX101-400-GPM/CFT-PxX

2014 Industrial  List V2 Page 72 January 01, 2014

Rev. 050114

WMX Flanged In-Line Magmeter (IP68)

Model # Description

AG2000-168-300 Flanged In-Line Magmeter, 2 AA Backup Batteries, IP68 3″ 137

AG2000-168-400 Flanged In-Line Magmeter, 2 AA Backup Batteries, IP68, 4″ 378

AG2000-168-600 Flanged In-Line Magmeter, 2 AA Backup Batteries, IP68, 6″ 630

AG2000-168-800 Flanged In-Line Magmeter, 2 AA Backup Batteries, IP68, 8″ 858

AG2000-168-1000 Flanged In-Line Magmeter, 2 AA Backup Batteries, IP68, 10″ 238

AG2000-168-300 Flanged In-Line Magmeter, 2 DD Cell Batteries, IP68 3″ 961

AG2000-168-400 Flanged In-Line Magmeter, 2 DD Cell Batteries, IP68, 4″ 202

AG2000-168-600 Flanged In-Line Magmeter, 2 DD Cell Batteries, IP68, 6″ 454

AG2000-168-800 Flanged In-Line Magmeter, 2 DD Cell Batteries, IP68, 8″ 682

AG2000-168-1000 Flanged In-Line Magmeter, 2 DD Cell Batteries, IP68, 10″ 062

AG2000-168-1200 Flanged In-Line Magmeter, 2 DD Cell Batteries, IP68, 12″ 480

Option Code(s) Description

11/6S Factory-Installed Power/Output Cable, 6m (20 ft) 76

11/15S Factory-Installed Power/Output Cable, 15m (50 ft) 60

11/30S Factory-Installed Power/Output Cable, 30m (100 ft) 64

127S Internal Data Logger 20

Specify desired rate at time of order. See below for available units.

Any rate selection can be combined with any total selection. Default pulse rate is High Frequency.

If ordering the WMX101, a pulse rate must be specified as well.

Note: 3″ model is only available in IP68.

WMX IP68 FLOW MEASUREMENT UNITS

RATE

Gal/Min

Liter/Min

Liters/Sec

Cu Ft/Min

Cu Meter/Hr

Mil Gal/Day

Meg Lit/Day

ORDER

= GPM

= LPM

= LPS

= CFM

= CMH

= MGD

= MLD

ORDER

= G

= GT

= L

= LT

= ML

= CM

= CMT

= CF

= CFT

TOTAL

Gal

Gal x 1000

Liter

Liter x 1000

Mega Liters

Cubic Meters

Cu Met x 1000

Cubic Feet

Cu Feet x 1000

PULSE RATE

High Frequency

10 Units/Pulse

100 Units/Pulse

1000 Units/Pulse

ORDER

= -HF

= -PxX

= -PxH

= -PxK

(Units = Gal or Liter based on

Rate/Total unit Selection)

Ordering Example WMX101-168 NO

CABLE:

WMX101-400-168-GPM/CFT

Ordering Example WMX101-168 W/CABLE:

WMX101-400-168-GPM/CFT-PxX

2014 Industrial  List V2 Page 73 January 01, 2014

Rev. 050114

WMX Parts & Accessories

Model # Description

101621 Equalization Cable, AG/WMX-400 6

101622 Equalization Cable, AG/WMX-600/800 8

101623 Equalization Cable, AG/WMX-1000/1200 0

100889 Battery Pack, Lithium, 3.6V, 19Ah, 2-D Cell 03

101317 Battery Pack, Lithium, 3.6V, 2.4mAh, 2-AA Cell 4

DC30 Field-Installed Power/Output Cable, 6m (20 ft) 00

DC35 Field-Installed Power/Output Cable, 15m (50 ft) 47

DC100 Field-Installed Power/Output Cable, 30M (100 ft) 83

100876 (1) Grounding Ring, AG/WMX-400 37

100877 (1) Grounding Ring, AG/WMX-600 72

100878 (1) Grounding Ring, AG/WMX-800 05

100879 (1) Grounding Ring, AG/WMX-1000 61

103288 (1) Grounding Ring, AG/WMX-1200 90

101949 Hinged Display Cover 7

100853 Seal, Security, w/12″ of Wire

100854 Wire, for Security Seal, 12″

WMX (IP68) Parts & Accessories

Model # Description

101621 Equalization Cable, AG/WMX-400 6

101622 Equalization Cable, AG/WMX-600/800 8

101623 Equalization Cable, AG/WMX-1000/1200 0

100889 Battery Pack, Lithium, 3.6V, 19Ah, 2-D Cell 03

101317 Battery Pack, Lithium, 3.6V, 2.4mAh, 2-AA Cell 4

DC30S Field-Installed Power/Output Cable, 6m (20 ft) 76

DC35S Field-Installed Power/Output Cable, 15m (50 ft) 60

DC100S Field-Installed Power/Output Cable, 30m (100 ft) 64

102157 Grounding Ring, AG/WMX-300 04

100876 (1) Grounding Ring, AG/WMX-400 37

100877 (1) Grounding Ring, AG/WMX-600 72

100878 (1) Grounding Ring, AG/WMX-800 05

100879 (1) Grounding Ring, AG/WMX-1000 61

103288 (1) Grounding Ring, AG/WMX-1200 90

100853 Seal, Security, w/12″ of Wire

100854 Wire, for Security Seal, 12″

Note: Cables are for field installation on the WMX104.

Note: Grounding rings not required for most applications.

2014 Industrial  List V2 Page 74 January 0

Model # Description

WJ-200 In-Line Turbine Meter, Cast Iron, 2″ 62

Note: If option -17 is ordered, a pulse rate must be specified.

Available pulse rates: 10G/P or 100G/P

WJ-300 In-Line Turbine Meter, Cast Iron, 3″ 011

Note: If option -17 is ordered, a pulse rate must be specified.

Available pulse rates: 100G/P or 1000G/P

WJ-400 In-Line Turbine Meter, Cast Iron, 4″ 430

Note: If option -17 is ordered, a pulse rate must be specified.

Available pulse rates: 100G/P or 1000G/P

WJ-600 In-Line Turbine Meter, Cast Iron, 6″ 511

Note: If option -17 is ordered, a pulse rate must be specified.

Available pulse rates: 1000G/P or 10,000G/P

-600 meters shipped by truck only, additional freight charges may apply.

WJ-800 In-Line Turbine Meter, Cast Iron, 8″ 275

Note: If option -17 is ordered, a pulse rate must be specified.

Available pulse rates: 1000G/P or 10,000G/P

-800 meters shipped by truck only, additional freight charges may apply.

Option Code(s) Description

17 Reed Switch Sensor 8

WJ Series Meters ordered BEFORE January 1st, 2013

Model # Description

100582 Reed Switch, WJ Series 5

101516 Lid & Hinge Pin Assy, WJ Series

WJ Series Meters ordered AFTER January 1st, 2013

Model # Description

103109 Reed Switch, WJ Series 5

101516-01 Lid & Hinge Pin Assy WJ Series (New Style)

For Insert Assemblies, consult factory for  and availablity.

2014 Industrial  List V2 Page 76 January 01, 2014

Rev. 050114

MJ Bronze Body Pulse Meters (COLD for temperature 105°F and below)

Model # Description

MJE-075 Cold-Water, Solid-state Pickup, 3/4″ 65

MJE-100 Cold-Water, Solid-state Pickup, 1″ 31

MJE-150 Cold-Water, Solid-state Pickup, 1-1/2″ 24

MJE-200 Cold-Water, Solid-state Pickup, 2″ 32

MJR-075 Cold-Water, Reed Switch (Dry Contact), 3/4″ 41

MJR-100 Cold-Water, Reed Switch (Dry Contact), 1″ 08

MJR-150 Cold-Water, Reed Switch (Dry Contact), 1-1/2″ 77

MJR-200 Cold-Water, Reed Switch (Dry Contact), 2″ 09

MJT-075 Cold Water, Mechanical Register Only, 3/4″ 05

MJT-100 Cold Water, Mechanical Register Only, 1″ 71

MJT-150 Cold Water, Mechanical Register Only, 1-1/2″ 43

MJT-200 Cold Water, Mechanical Register Only, 2″ 70

Note: s reflect standard pulse rates expressed in gallons.

There is an additional charge of 0 if you need indication in Cubic Feet or Cubic Meters.

Available pulse rates are 20, 10, 4, 2, 1 Pulses/Gallon, and 1, 5, 10, 50, 100 Gallons/Pulse.

Specify MJR/MJE pulse rate at time of order.

Consult Spec sheet for corresponding meter sizes, and CF and CM pulse rates.

Option Code(s) Description

06 LMI Pump 4-Pin Connector 0

07 Seametrics Control Connector 0

106 Roytronics® Series-A Pump 5 Pin Connector 0

Note: Options not available with MJT

MJH Bronze Body Pulse Meters (HOT for temperatures 194°F and below)

Model # Description

MJHE-075 Hot-Water, Solid-state Pickup, 3/4″ 27

MJHE-100 Hot-Water, Solid-state Pickup, 1″ 17

MJHE-150 Hot-Water, Solid-state Pickup, 1-1/2″ 53

MJHE-200 Hot-Water, Solid-state Pickup, 2″ 20

MJHR-075 Hot-Water, Reed Switch (Dry Contact), 3/4″ 15

MJHR-100 Hot-Water, Reed Switch (Dry Contact), 1″ 00

MJHR-150 Hot-Water, Reed Switch (Dry Contact), 1-1/2″ 18

MJHR-200 Hot-Water, Reed Switch (Dry Contact), 2″ 77

MJHT-075 Hot-Water, Mechanical Register Only, 3/4″ 45

MJHT-100 Hot-Water, Mechanical Register Only, 1″ 35

MJHT-150 Hot-Water, Mechanical Register Only, 1-1/2″ 55

MJHT-200 Hot-Water, Mechanical Register Only, 2″ 24

Note: s reflect standard pulse rates expressed in gallons.

There is an additional charge of 0 if you need indication in Cubic Feet or Cubic Meters.

Available pulse rates are 20, 10, 4, 2, 1 Pulses/Gallon, and 1, 5, 10, 50, 100 Gallons/Pulse.

Specify MJR/MJE pulse rate at time of order.

Consult Spec sheet for corresponding meter sizes, and CF and CM pulse rates.

Option Code(s) Description

06 LMI Pump 4-Pin Connector 0

07 Seametrics Control Connector 0

106 Roytronics® Series-A Pump 5 Pin Connector 0

Note: Options not available with MJT

2014 Industrial  List V2 Page 77 January 01, 2014

Rev. 050114

MJ Series Parts & Accessories (COLD for temperature 105°F and below)

Model # Description

All MJ Meters

100980 Sensor, Single Reed Switch 4

100993 Sensor, Dual Reed Switch 3

101004 Lens, MJ 3/4″ to 2″ 2

101045 Screw, MJ, Sensor

101065 Sensor Assy, Single Hall Effect 4

101294 Magnet, 4 Poles MJR

3/4″ Meters

101301 Coupling Set W/Gaskets, MJ, 3/4″ 8

101081 Coupling Assy Gasket (2-pieces), 3/4″

101077 Internal Assy, CF, MJ, 3/4″ 3

101073 Internal Assy, Gal., MJ, 3/4″ 3

101016 Strainer, Internal, MJ, 3/4″

101071 Gasket Assy, Lens 3/4″

101013 Gasket, Register Chamber MJ, 3/4″

101068 Lid & Hinge Pin Assy, MJ, 3/4″

101006 Register MJ, CF, 3/4″ 8

100997 Register MJ, GAL, 3/4″ 8

101029 Strainer, Tubular, MJ, 3/4″

103222-075 Register, MJ, CM, 3/4″ 8

1″ Meters

101302 Coupling Set W/Gaskets, MJ, 1″ 0

101082 Coupling Assy Gasket (2-pieces), 1″ 3

101078 Internal Assy, CF., MJ, 1″ 35

101074 Internal Assy, Gal., MJ, 1″ 35

101043 Strainer, Internal, MJ 1″

101072 Gasket Assy, Lens 1″

101027 Gasket, Register Chamber MJ, 1″

101069 Lid & Hinge Pin Assy, MJ, 1″

101007 Register MJ, CF, 1″ 4

100998 Register MJ, GAL, 1″ 4

101030 Strainer, Tubular, MJ, 1″

103222-100 Register, MJ, CM, 1″ 4

1-1/2″ Meters

101303 Coupling Set W/Gaskets, MJ, 1-1/2″ 49

101083 Coupling Assy Gasket (2-pieces), 1-1/2″ 4

101079 Internal Assy, CF., MJ, 1-1/2″ 70

101075 Internal Assy, Gal., MJ, 1-1/2″ 70

101044 Strainer, Internal, MJ, 1-1/2″ and 2″ 3

101085 Gasket Assy, Lens 1-1/2″ & 2″

102228 O-Ring, Buna-N, 70-Duro, MJ, 1-1/2″ and 2″

101070 Lid & Hinge Pin Assy, MJ, 1-1/2″ & 2″

101008 Register MJ, CF, 1-1/2″ 11

100999 Register MJ, GAL, 1-1/2″ 11

101031 Strainer, Tubular, MJ, 1-1/2″ 1

103222-150 Register, MJ, CM, 1-1/2″ 11

2014 Industrial  List V2 Page 78 January 01, 2014

Rev. 050114

MJ Series Parts & Accessories (COLD for temperature 105°F and below)

Model # Description

2″ Meters

101304 Coupling Set W/Gasket, MJ, 2″ 13

101084 Coupling Assembly Gasket (2-pieces), 2″ 9

101080 Internal Assembly, CF., MJ, 2″ 52

101076 Internal Assembly, Gal., MJ, 2″ 52

101044 Strainer, Internal, MJ, 1-1/2″ and 2″ 3

101085 Gasket Assy, Lens 1-1/2″ & 2″

102228 O-Ring, Buna-N, 70-Duro, MJ, 1-1/2″ and 2″

101070 Lid & Hinge Pin Assy, MJ, 1-1/2″ & 2″

101009 Register MJ CF, 2″ 11

101000 Register MJ, 2″ 11

101032 Strainer, Tubular, MJ, 2″ 3

103222-200 Register, MJ, CM, 2″ 11

MJH Series Parts & Accessories (HOT for temperatures 194°F and below)

Model # Description

All MJH Meters

100980 Sensor, Single Reed Switch 4

100993 Sensor, Dual Reed Switch 3

101004 Lens, MJ 3/4″ to 2″ 2

101045 Screw, MJ, Sensor

101065 Sensor Assy, Single Hall Effect 4

3/4″ Meters

101328 Coupling Set W/Gasket, MJH, 3/4″ 9

101324 Coupling Assy Gasket (2-pieces), MJH, 3/4″

101346 Internal Assy, CF., MJH, 3/4″ 04

101350 Internal Assy, Gal., MJH, 3/4″ 04

101379 Strainer, Internal, MJH, 3/4″ 0

101332 Gasket Assy, Lens MJH, 3/4″

101339 Gasket, Register Chamber MJH, 3/4″

101354 Lid & Hinge Pin Assy, MJH, 3/4″ 0

101368 Register, MJH CF, 3/4″ 6

101372 Register, MJH, GAL, 3/4″ 6

101382 Strainer, Tubular, MJH, 3/4″

103223-075 Register, MJH, CM, 3/4″ 6

1″ Meters

101329 Coupling Set W/Gasket, MJH, 1″ 08

101325 Coupling Assy Gasket (2-pieces), MJH 1″ 7

101347 Internal Assy, CF., MJH, 1″ 69

101351 Internal Assy, Gal., MJH, 1″ 69

101380 Strainer, Internal, MJH, 1″ 1

101333 Gasket Assy, Lens MJH, 1″

101340 Gasket, Register Chamber MJH, 1″

101355 Lid & Hinge Pin Assy, MJH, 1″ 0

101369 Register, MJH CF, 1″ 2

101373 Register, MJH, GAL, 1″ 2

101383 Strainer, Tubular, MJH, 1″

103223-100 Register, MJH, CM, 1″ 2

2014 Industrial  List V2 Page 79 January 01, 2014

Rev. 050114

MJH Series Parts & Accessories (HOT for temperatures 194°F and below)

Model # Description

1-1/2″ Meters

101330 Coupling Set W/Gasket, MJH, 1-1/2″ 84

101326 Coupling Gasket (2-pieces), MJH, 1-1/2″ 9

101348 Internal Assy, CF., MJH, 1-1/2″ 37

101352 Internal Assy, Gal., MJH, 1-1/2″ 37

101381 Strainer, Internal, MJH, 1-1/2″ and 2″ 6

101334 Gasket Assy, Lens MJH, 1-1/2″ and 2″

101341 Gasket, Register Chamber MJH, 1-1/2″ and 2″

101356 Lid & Hinge Pin Assy, MJH, 1-1/2″ 1

101370 Register, MJH CF, 1-1/2″ 39

101374 Register, MJH, GAL, 1-1/2″ 39

101384 Strainer, Tubular, MJH, 1-1/2″ 4

103223-150 Register, MJH, CM, 1-1/2″ 39

2″ Meters

101331 Coupling Set W/Gasket, MJH, 2″ 51

101327 Coupling Gasket (2-pieces), MJH, 2″ 3

101349 Internal Assy, CF., MJH, 2″ 40

101353 Internal Assy, Gal., MJH, 2″ 40

101381 Strainer, Internal, MJH, 1-1/2″ and 2″ 6

101334 Gasket Assy, Lens MJH, 1-1/2″ and 2″

101341 Gasket, Register Chamber MJH, 1-1/2″ and 2″

101356 Lid & Hinge Pin Assy, MJH, 1-1/2″ 1

101371 Register, MJH CF, 2″ 39

101375 Register, MJH, GAL, 2″ 39

101385 Strainer, Tubular, MJH, 2″ 6

103223-200 Register, MJH, CM, 2″ 39

2014 Industrial  List V2 Page 80 January 01, 2014

Rev. 050114

MJN NSF Bronze Body Pulse Meters (Cold Water)

Model # Description

MJNE-075 Cold-Water, Solid-state Pickup, 3/4″ NSF 82

MJNE-100 Cold-Water, Solid-state Pickup, 1″ NSF 84

MJNE-150 Cold-Water, Solid-state Pickup, 1-1/2″ NSF 43

MJNE-200 Cold-Water, Solid-state Pickup, 2″ NSF 86

MJNR-075 Cold Water Reed Switch Dry Contact, 3/4″ NSF 54

MJNR-100 Cold Water Reed Switch Dry Contact, 1″ NSF 55

MJNR-150 Cold Water Reed Switch Dry Contact, 1-1/2″ NSF 80

MJNR-200 Cold Water Reed Switch Dry Contact, 2″ NSF 53

MJNT-075 Cold-Water Mechanical Register Only, 3/4″ NSF 16

MJNT-100 Cold-Water Mechanical Register Only, 1″ NSF 10

MJNT-150 Cold-Water Mechanical Register Only, 1-1/2″ NSF 51

MJNT-200 Cold-Water Mechanical Register Only, 2″ NSF 88

Note: s reflect standard pulse rates expressed in gallons.

There is an additional charge of 0 if you need indication in Cubic Feet or Cubic Meters.

Available pulse rates are 20, 10, 4, 2, 1 Pulses/Gallon, and 1, 5, 10, 50, 100 Gallons/Pulse.

Specify MJNR/MJNE pulse rate at time of order.

Consult Spec sheet for corresponding meter sizes, and CF and CM pulse rates.

Option Code(s) Description

06 LMI Pump 4-Pin Connector 0

07 Seametrics Control Connector 0

106 Roytronics® Series-A Pump 5 Pin Connector 0

Note: Options not available with MJNT

2014 Industrial  List V2 Page 81 January 01, 2014

Rev. 050114

MJN Series Parts & Accessories (COLD for temperature 105°F and below)

Model # Description

All MJN Meters

100980 Sensor, Single Reed Switch 4

100993 Sensor, Dual Reed Switch 3

101004 Lens, MJ 3/4″ to 2″ 2

101045 Screw, MJ, Sensor

101065 Sensor Assy, Single Hall Effect 4

101294 Magnet, 4 Poles MJR

3/4″ Meters

101301 Coupling Set W/Gaskets, MJ, 3/4″ 8

101081 Coupling Assy Gasket (2-pieces), 3/4″

101077 Internal Assy, CF, MJ, 3/4″ 3

101073 Internal Assy, Gal., MJ, 3/4″ 3

101016 Strainer, Internal, MJ, 3/4″

101071 Gasket Assy, Lens 3/4″

101013 Gasket, Register Chamber MJ, 3/4″

101068 Lid & Hinge Pin Assy, MJ, 3/4″

101006 Register MJ, CF, 3/4″ 8

100997 Register MJ, GAL, 3/4″ 8

101029 Strainer, Tubular, MJ, 3/4″

103222-075 Register, MJ, CM, 3/4″ 8

1″ Meters

101302 Coupling Set W/Gaskets, MJ, 1″ 0

101082 Coupling Assy Gasket (2-pieces), 1″ 3

101078 Internal Assy, CF., MJ, 1″ 35

101074 Internal Assy, Gal., MJ, 1″ 35

101043 Strainer, Internal, MJ 1″

101072 Gasket Assy, Lens 1″

101027 Gasket, Register Chamber MJ, 1″

101069 Lid & Hinge Pin Assy, MJ, 1″

101007 Register MJ, CF, 1″ 4

100998 Register MJ, GAL, 1″ 4

101030 Strainer, Tubular, MJ, 1″

103222-100 Register, MJ, CM, 1″ 4

1-1/2″ Meters

101303 Coupling Set W/Gaskets, MJ, 1-1/2″ 49

101083 Coupling Assy Gasket (2-pieces), 1-1/2″ 4

101079 Internal Assy, CF., MJ, 1-1/2″ 70

101075 Internal Assy, Gal., MJ, 1-1/2″ 70

101044 Strainer, Internal, MJ, 1-1/2″ and 2″ 3

101085 Gasket Assy, Lens 1-1/2″ & 2″

102228 O-Ring, Buna-N, 70-Duro, MJ, 1-1/2″ and 2″

101070 Lid & Hinge Pin Assy, MJ, 1-1/2″ & 2″

101008 Register MJ, CF, 1-1/2″ 11

100999 Register MJ, GAL, 1-1/2″ 11

101031 Strainer, Tubular, MJ, 1-1/2″ 1

103222-150 Register, MJ, CM, 1-1/2″ 11

2014 Industrial  List V2 Page 82 January 01, 2014

Rev. 050114

MJN Series Parts & Accessories (COLD for temperature 105°F and below)

Model # Description

2″ Meters

101304 Coupling Set W/Gasket, MJ, 2″ 13

101084 Coupling Assembly Gasket (2-pieces), 2″ 9

101080 Internal Assembly, CF., MJ, 2″ 52

101076 Internal Assembly, Gal., MJ, 2″ 52

101044 Strainer, Internal, MJ, 1-1/2″ and 2″ 3

101085 Gasket Assy, Lens 1-1/2″ & 2″

102228 O-Ring, Buna-N, 70-Duro, MJ, 1-1/2″ and 2″

101070 Lid & Hinge Pin Assy, MJ, 1-1/2″ & 2″

101009 Register MJ CF, 2″ 11

101000 Register MJ, 2″ 11

101032 Strainer, Tubular, MJ, 2″ 3

103222-200 Register, MJ, CM, 2″ 11

2014 Industrial  List V2 Page 83 January 01, 2014

SEB-050 Single Jet Low Flow Meter, Nickel-Plated Brass, 1/2″ 54

SEB-075 Single Jet Low Flow Meter, Nickel-Plated Brass, 3/4″ 61

Option Code(s) Description

06 LMI Pump 4-Pin Connector 0

07 Seametrics Control Connector 0

106 Roytronics® Series-A Pump 5 Pin Connector 0

SEB Parts & Accessories

Model # Description

103326 Coupling Assy, Brass, SEB-075 2

103325 Coupling Assy, Brass, SEB-050 4

103311 Kit, Gasket Coupling Fiber, 0.625″ 0

103316 Gasket Kit, Coupling, Fiber, SEB, 3/4″ 0

100701 Lid Assy, SEB-050/075 04

SES Single Jet Low Flow Meters

Model # Description

SES-050 Single Jet Low Flow Meter, 316 SS, 1/2″ 54

SES-075 Single Jet Low Flow Meter, 316 SS, 3/4″ 54

SES-100 Single Jet Low Flow Meter, 316 SS, 1″ 54

Option Code(s) Description

01 Rotor w/ Ceramic Shaft, PVDF, Kynar® 9

04 Micropower Pickup (For Battery Powered Meters) NC

06 LMI Pump 4-Pin Connector 0

07 Seametrics Control Connector 0

13 High Resolution 7

13-68 High Resolution, Silicone Carbide Shaft 47

60 Viton® O-Ring 6

68 Silicon Carbide Shaft 10

69 EPDM O-Ring NC

106 Roytronics® Series-A Pump 5 Pin Connector 0

SES Parts & Accessories

Model # Description

103313 Bearing Assembly Kit, SPX/SPT/SES 8

100372 Tool, Bearing Removal, SPX/SPT/SES 59

100508 Sensor Assy, Grey Micropowered, 18′ (For Battery Powered Displays) 00

100419 Sensor Assy, Blue, Low Power, 18′ (For External Powered Displays) 00

100034 Rotor w/ Shaft, PVDF, Kynar®, Tungsten Carbide Shaft, 2 Magnet 4

100033 Rotor w/ Shaft, PVDF, Kynar®, Ceramic Shaft, 2 Magnet 37

100035 Rotor w/ Shaft, PVDF, Kynar®, Tungsten Carbide Shaft, 6 Magnet, Hi-Res 6

100036 Rotor w/ Shaft, PVDF, Kynar®, Ceramic Shaft, 6 Magnet, Hi-Res 69

103318 Screw Kit, 1/4-20 x 0.625″, SH, SS 2

100264 O-Ring, EPDM, Black 4

100973 O-Ring, Viton® Teflon Coated 3

100556 Rotor Repair Kit, Kynar® Silicone Carbide, 6 Magnet 85

2014 Industrial  List V2 Page 86 January 01, 2014

Rev. 050114

SPT Single Jet Low Flow Meters

Model # Description

SPT-038 Single Jet Low Flow, PTFE, PTFE Cover, 3/8″ 20

SPT-038-70 Single Jet Low Flow, PTFE, PTFE Cover, SAE Ports, 3/8″ 79

SPT-038-117 Single Jet Low Flow, PTFE, PTFE Cover, BSP Threads, 3/8″ 74

SPT-050 Single Jet Low Flow, PTFE, PTFE Cover, 1/2″ 20

SPT-050-70 Single Jet Low Flow, PTFE, PTFE Cover, SAE Ports, 1/2″ 79

SPT-050-117 Single Jet Low Flow, PTFE, PTFE Cover, BSP Threads, 1/2″ 74

SPT-075 Single Jet Low Flow, PTFE, PTFE Cover, 3/4″ 20

SPT-075-70 Single Jet Low Flow, PTFE, PTFE Cover, SAE Ports, 3/4″ 79

SPT-075-117 Single Jet Low Flow, PTFE, PTFE Cover, BSP Threads, 3/4″ 74

SPT-100 Single Jet Low Flow, PTFE, PTFE Cover, 1″ 20

SPT-100-70 Single Jet Low Flow, PTFE, PTFE Cover, SAE Ports, 1″ 79

SPT-100-117 Single Jet Low Flow, PTFE, PTFE Cover, BSP Threads, 1″ 74

Option Code(s) Description

04 Micropower Pickup NC

06 LMI Pump 4-Pin Connector 0

07 Seametrics Control Connector 0

13 High Resolution 7

60 Viton® O-Ring 6

68 Silicon Carbide Shaft 10

69 EPDM O-Ring 6

106 Roytronics® Series-A Pump 5 Pin Connector 0

SPT Parts & Accessories

Model # Description

103313 Bearing Assembly Kit, SPX/SPT/SES 8

100372 Tool, Bearing Removal, SPX/SPT/SES 59

100508 Sensor Assy, Grey Micropowered, 18′ (For Battery Powered Displays) 00

100419 Sensor Assy, Blue, Low Power, 18′ (For External Powered Displays) 00

100034 Rotor w/ Shaft, PVDF, Kynar®, Tungsten Carbide Shaft, 2 Magnet 4

100033 Rotor w/ Shaft, PVDF, Kynar®, Ceramic Shaft, 2 Magnet 37

100035 Rotor w/ Shaft, PVDF, Kynar®, Tungsten Carbide Shaft, 6 Magnet, Hi-Res 6

100036 Rotor w/ Shaft, PVDF, Kynar®, Ceramic Shaft, 6 Magnet, Hi-Res 69

103310 Kit, Nut 10-32 Hex, SS 2

100264 O-Ring, EPDM, Black 4

100973 O-Ring, Viton® Teflon Coated 3

103308 Kit, Capscrew 10-32 x 2″, Socket Head, SS 0

100556 Rotor Repair Kit, Kynar® Silicone Carbide, 6 Magnet 85

2014 Industrial  List V2 Page 87 January 01, 2014

Rev. 050114

SPX Single Jet Low Flow Meters

Model # Description

SPX-038 Single Jet Low Flow, Acrylic Cover, Polypro, 3/8″ 95

SPX-038-70 Single Jet Low Flow, Acrylic Cover, SAE Ports, Polypro, 3/8″ 54

SPX-038-116 Single Jet Low Flow, Acrylic Cover, BSP Threads, Polypro, 3/8″ 49

SPX-050 Single Jet Low Flow, Acrylic Cover, Polypro, 1/2″ 95

SPX-050-70 Single Jet Low Flow, Acrylic Cover, SAE Ports, Polypro, 1/2″ 54

SPX-050-116 Single Jet Low Flow, Acrylic Cover, BSP Threads, Polypro, 1/2″ 49

SPX-075 Single Jet Low Flow, Acrylic Cover, Polypro, 3/4″ 95

SPX-075-70 Single Jet Low Flow, Acrylic Cover, SAE Ports, Polypro, 3/4″ 54

SPX-075-116 Single Jet Low Flow, Acrylic Cover, BSP Threads, Polypro, 3/4″ 49

SPX-100 Single Jet Low Flow, Acrylic Cover, Polypro, 1″ 95

SPX-100-70 Single Jet Low Flow, Acrylic Cover, SAE Ports, Polypro, 1″ 54

SPX-100-116 Single Jet Low Flow, Acrylic Cover, BSP Threads, Polypro, 1″ 49

Option Code(s) Description

01 Rotor w/ Ceramic Shaft, PVDF, Kynar® 9

04 Micropower Pickup (For Battery Powered Meters) NC

06 LMI Pump 4-Pin Connector 0

07 Seametrics Control Connector 0

12 Polypro Cover 0

13 High Resolution 7

25 Viton® O-Ring, Teflon-coated 0

60 Viton® O-Ring 6

68 Silicon Carbide Shaft 10

106 Roytronics® Series-A Pump 5 Pin Connector 0

SPX Parts & Accessories

Model # Description

103313 Bearing Assembly Kit, SPX/SPT/SES 8

100372 Tool, Bearing Removal, SPX/SPT/SES 59

100508 Sensor Assy, Grey Micropowered, 18′ (For Battery Powered Displays) 00

100419 Sensor Assy, Blue, Low Power, 18′ (For External Powered Displays) 00

100034 Rotor w/ Shaft, PVDF, Kynar®, Tungsten Carbide Shaft, 2 Magnet 4

100033 Rotor w/ Shaft, PVDF, Kynar®, Ceramic Shaft, 2 Magnet 37

100035 Rotor w/ Shaft, PVDF, Kynar®, Tungsten Carbide Shaft, 6 Magnet, Hi-Res 6

100036 Rotor w/ Shaft, PVDF, Kynar®, Ceramic Shaft, 6 Magnet, Hi-Res 69

103314 Kit, Screw, 10-24 x 1″, SS, S/H 0

100231 Lens Assembly, Acrylic, SPX with Bearing 33

100970 Lens Assembly, Acrylic, New Style 08

100232 Lens Assembly, Polypro, SPX with Bearing 49

100971 Lens Assembly, PolyPro, New Style 25

100264 O-Ring, EPDM, Black 4

100219 O-Ring, Viton®, Brown 8

100556 Rotor Repair Kit, Kynar® Silicone Carbide, 6 Magnet 85

2014 Industrial  List V2 Page 88 January 01, 2014

Rev. 050114

PE102 Electromagnetic Low Flow Meters

Model # Description

PE102-038 Electromagnetic Low Flow Meter, 3/8″ 12

PE102-075 Electromagnetic Low Flow Meter, 3/4″ 12

Note: Specific accessories are required. You must select an Adapter Kit.

See accessories table below.

Adapter kits come with 2 adapters and 2 O-Rings

PE102 Parts & Accessories

Model # Description

PE102-038

101422 Cable, PE Output, 8 Pin, 6 Meter, Shield 3

103254 PE102-038 PVDF Adapter Kit, 1/4″ MNPT, EPDM O-Ring (101688 & 101684) 26

103255 PE102-038 PVDF Adapter Kit, 1/4″ MNPT Viton® O-Ring (101688 & 101685) 34

103256 PE102-038 PP Adapter Kit, 1/4″ MNPT EPDM O-Ring (103014 & 101684) 4

103257 PE102-038 PP Adapter Kit, 1/4″ MNPT Viton® O-Ring (103014 & 101685) 2

103258 PE102-038 PVDF Adapter Kit, 3/8″ MNPT EPDM O-Ring (101672 & 101684) 26

103259 PE102-038 PVDF Adapter Kit, 3/8″ MNPT Viton® O-Ring (101672 & 101685) 34

103260 PE102-038 PP Adapter Kit, 3/8″ MNPT EPDM O-Ring (103013 & 101684) 4

103261 PE102-038 PP Adapter Kit, 3/8″ MNPT Viton® O-Ring (103013 & 101685) 2

103262 PE102-038 PVDF Adapter Kit, 1/2″ MNPT EPDM O-Ring (101940 & 101684) 4

103263 PE102-038 PVDF Adapter Kit, 1/2″ MNPT Viton® O-Ring (101940 & 101685) 2

103264 PE102-038 PVDF Adapter Kit, 1/2″ FNPT EPDM O-Ring (102180 & 101684) 26

103265 PE102-038 PVDF Adapter Kit, 1/2″ FNPT Viton® O-Ring (102180 & 101685) 34

103266 PE102-038 PP Adapter Kit, 1/2″ FNPT EPDM O-Ring (103011 & 101684) 4

103267 PE102-038 PP Adapter Kit, 1/2″ FNPT Viton® O-Ring (103011 & 101685) 2

101689 Nut, Flaretek, 0.375″ (2 Required) 8

101690 Tool, Flaretek 0.375″ 94

103320 O-Ring Kit, EPDM, 70-Duro, 2-205 8

103321 O-Ring Kit, Viton, Brown, 75-Duro, 2-205 6

PE102-075

101422 Cable, PE Output, 8 Pin, 6 Meter, Shield 3

103270 PE102-075 PVDF Adapter Kit, 1/2″ MNPT EPDM O-Ring (101396 & 100996) 26

103271 PE102-075 PVDF Adapter Kit, 1/2″ MNPT Viton® O-Ring (101396 & 101290) 34

103272 PE102-075 PP Adapter Kit, 1/2″ MNPT EPDM O-Ring (103016 & 100996) 4

103273 PE102-075 PP Adapter Kit, 1/2″ MNPT Viton® O-Ring (103016 & 101290) 2

103274 PE102-075 PVDF Adapter Kit, 1/2″ FNPT EPDM O-Ring (102181 & 100996) 26

103275 PE102-075 PVDF Adapter Kit, 1/2″ FNPT Viton® O-Ring (102181 &101290) 34

103276 PE102-075 PP Adapter Kit, 1/2″ FNPT EPDM O-Ring (103012 &100996) 4

103277 PE102-075 PP Adapter Kit, 1/2″ FNPT Viton® O-Ring (103012 & 101290) 2

103278 PE102-075 PVDF Adapter Kit, 3/4″ MNPT EPDM O-Ring (101252 & 100996) 26

103279 PE102-075 PVDF Adapter Kit, 3/4″ MNPT Viton® O-Ring (101252 & 101290) 34

103280 PE102-075 PP Adapter Kit, 3/4″ MNPT EPDM O-Ring (103015 & 100996)) 4

103281 PE102-075 PP Adapter Kit, 3/4″ MNPT Viton® O-Ring (103015 & 101290) 2

101284 Nut, Flaretek , 3/4″ (2 Required) 8

101285 Tool, Flaretek 3/4″ 94

103322 O-Ring Kit, EPDM, 70-Duro, 2-117 8

103323 O-Ring Kit, Viton, Brown, 75-Duro, 2-117 6

2014 Industrial  List V2 Page 89 January 01, 2014IMAG3600-300 Flanged In-Line MagMeter, IP68, 3″ w/ Remote Display 524

IMAG3600-400 Flanged In-Line MagMeter, IP68, 4″ w/ Remote Display 867

IMAG3600-600 Flanged In-Line MagMeter, IP68, 6″ w/ Remote Display 956

IMAG3600-800 Flanged In-Line MagMeter, IP68, 8″ w/ Remote Display 216

IMAG3600-1000 Flanged In-Line MagMeter, IP68, 10″ w/ Remote Display 603

IMAG3600-1200 Flanged In-Line MagMeter, IP68, 12″ w/ Remote Display 250

Option Code(s) Description

F1 F1 (ANSI 150#) NC

ADDX AC Power, 1 Digital Output NC

ADLX AC Power, Current Loop, Digital Out 10

APLX AC Power, Pulse, Current Loop NC

ARRX AC Power, 1 Relay Output NC

APXX AC Power, 1 Pulse Output NC

DDDX DC Power, 1 Digital Out NC

DDLX DC Power, Current Loop, Digital Out 10

DPLX DC Power, Pulse, Current Loop NC

DRRX DC Power, 1 Relay Output NC

DPXX DC Power, 1 Pulse Output NC

000 No External Power/Output Cable NC

006 20 ft. (6m) Power/Output Cable NC

010 33ft. (10m) Power/Output Cable 00

020 66 ft. (20m) Power/Output Cable 62

030 100 ft. (30m) Power/Output Cable 52

010 33 ft. (10m) Sensor Cable NC

020 66 ft. (20m) Sensor Cable 62

030 100 ft. (30m) Sensor Cable 00

iMAG4600 Flanged In-Line Magmeter (IP68)

Model # Description

IMAG4600-300 Flanged In-Line MagMeter, IP68, 3″ w/ Integral Display 374

IMAG4600-400 Flanged In-Line MagMeter, IP68, 4″ w/ Integral Display 642

IMAG4600-600 Flanged In-Line MagMeter, IP68, 6″ w/ Integral Display 922

IMAG4600-800 Flanged In-Line MagMeter, IP68, 8″ w/ Integral Display 176

IMAG4600-1000 Flanged In-Line MagMeter, IP68, 10″ w/ Integral Display 597

IMAG4600-1200 Flanged In-Line MagMeter, IP68, 12″ w/ Integral Display 150

Option Code(s) Description

F1 F1 (ANSI 150#) NC

DDDX DC Power, 1 Digital Output NC

DDLX DC Power, Current Loop, Digital Out 10

DPLX DC Power, Pulse, Current Loop NC

DRRX DC POWER, 1 Relay Output NC

DPXX DC Power, 1 Pulse Output NC

006 20 ft. (6m) Power/Output Cable NC

010 33 ft. (10m) Power/Output Cable 00

020 66 ft. (20m) Power/Output Cable 62

030 100 ft. (30m) Power/Output Cable 52

2014 Industrial  List V2 Page 92 January 01, 2014

Rev. 050114

Example: iMAG3600 – 0400 – F1 – DPLX – 006

(1) (2) (3) (4) (5)

– 010

HOW TO ORDER

-0300 3″

-0400 4″

-0600 6″

-0800 8″

-1000 10″

-1200 12″

-F1 ANSI 150# -ADDX AC Power, 1 Digital Output

-ADLX AC Power, Current Loop, Digital Output

-APLX AC Power, Pulse, Current Loop

-ARRX AC Power, 1 Relay Output

-DDDX DC Power, 1 Digital Output

-DDLX DC Power, Current Loop, Digital Output

-DPLX DC Power, Pulse, Current Loop

-DRRX DC Power, 1 Relay Output

-DPXX DC Power, 1 Pulse Output

-000 No Cable

-006 6 Meter (20′)

-010 10 Meter (33′)

-020 20 Meter (66′)

-030 30 Meter (100′)

-010 10 Meter (33′)

-020 20 Meter (66′)

-030 30 Meter (100′)



Example: iMAG4600 – 0400 – F1 – DPLX – 006

(1) (2) (3) (4)

-0300 3″

-0400 4″

-0600 6″

-0800 8″

-1000 10″

-1200 12″

-F1 ANSI 150# -DDDX DC Power, 1 Digital Output

-DDLX DC Power, Current Loop, Digital Output

-DPLX DC Power, Pulse, Current Loop

-DRRX DC Power, 1 Relay Output

-DPXX DC Power, 1 Pulse Output

-000 No Cable

-006 6 Meter (20′)

-010 10 Meter (33′)

-020 20 Meter (66′)

-030 30 Meter (100′)

(1) Size (2) Flange/Fitting (3) Power & communications (4) Power/Output Cable

(1) Size (2) Flange/Fitting (3) Power & communications (4) Power/Output Cable (5) Sensor Cable

6 Meter (20′) power cable (iMAG3600 or iMAG4600) and 10 Meter (33′) sensor cable (iMAG3600 only) are included at not addModel # Description

100007 Connector, Seametrics 3-Pin Cable End 2

100006 Connector, Seametrics 3-Pin BulkHead 2

100008 Connector, Female, LMI 4pin, Female 2

101783 Roytronics® Series-A Pump 5 Pin Connector 3

100852 Cable, Shielded, 4-Con, EX W/O Reverse Flow (Per Ft.)

100835 Cable, Shielded, 6-Con, EX W/ Reverse Flow (Per Ft.)

100010 Cable, Unshielded, 2 Con, MJ-WJ-AO55 (Per Ft.)

100451 Cable, Unshielded, 3 Con, Blue, Low Power, IP-TX-WT-S Series (Per Ft.)

100011 Cable, Unshielded, 3 Con, Grey Micropower (IP,TX,WT,SPX,SPT,SES)

100014 Cable, Unshielded, 4 Con, FT420, (Per Ft.)

100649 Cable, Unshielded, 3 Con, MJE (Per Ft.)

Cables & Connectors Assemblies

Model # Description

100039 Cable Assy, 12′ Unshielded, 2 Con, LMI 4-Pin Connector 5

100013 Cable Assy, 12′ Unshielded, 3 Con, LMI 4-Pin Connector, 1K Resistor 5

100395 Cable Assy, 12′ Unshielded, 2 Con, Seametrics 3-Pin Connector 5

100041 Cable Assy, 12′ Unshielded, 3 Con, Seametrics 3-Pin Connector 5

101587 Cable Assy, 12′ Unshielded, 2 Con, LMI 5-Pin Connector 5

101576 Cable Assy, 12′ Unshielded, 3 Con, LMI 5-Pin Connector 5

Note: For applications using an FT420 or PD10 and power is not supplied by the pump, use PN 101587 or 100039

If power is supplied by the pump, use PN 101576 or 100013.

100044 Sensor Assy, MJR, Single Reed Switch, LMI Pump 4-Pin Connector 4

100045 Sensor Assy, MJR, Dual Reed Switch, LMI Pump 4-Pin Connector 03

100049 Sensor Assy, MJE, Single Hall Effect, LMI Pump 4-Pin Connector 4

100046 Sensor Assy, MJR, Single Reed Switch, Seametrics Control Connector 4

100047 Sensor Assy, MJR, Dual Reed Switch, Seametrics Control Connector 03

100048 Sensor Assy, MJE, Single Hall Effect, Seametrics Control Cable 4

101588 Sensor Assy, MJR, Single Reed Switch, LMI Pump 5-Pin Connector 4

101589 Sensor Assy, MJR, Dual Reed SW, LMI Pump 5-Pin Connector 4

101590 Sensor Assy, MJE, Single Hall Effect, LMI Pump 5-Pin Connector 03

2014 Industrial  List V2 Page 95 January 01, 2014

Rev. 050114

Accessories & Tools

Model # Description

100372 Tool, Bearing Removal, SPX/SPT/SES 59

101949 Hinged Display Cover 7

100374 Mandrel, Rotor Housing, Tool, IP/TX 4

102632 MK10, Mounting Kit, Meter Mount 6

102633 MK20, Mounting Kit, Wall Mount 19

100763 Pin, Safety, 18-8 SS Coil Tension 7

103319 Security Screw Kit, 10-24 x 0.625″, 2

100853 Seal, Security, w/12″ of Wire

101424 Socket, Cable Nut, IP/TX Sensors 9

100375 Spanner Tool, Sensor, Retain Screw 9

100854 Wire, for Security Seal, 12″

Services

Model # Description

HANDLING See Terms & Conditions page 0

RUSH1 Rush Charge 5

RUSH2 Rush Charge 50

RESTOCK See Terms & Conditions page (Consult Factory) NC

CALIBRATION Consult Factory NC

2014 Industrial  List V2 Page 96 January 01, 2014

Rev. 050114

Part # Description Page(s)

100018 Cord Grip, Large Cable, Black 7, 9

100033 Rotor w/ Shaft, PVDF, Kynar®, Ceramic Shaft, 2 Magnet 86, 87

100034 Rotor w/ Shaft, PVDF, Kynar®, Tungsten Carbide Shaft, 2 Magnet 86, 87

100035 Rotor w/ Shaft, PVDF, Kynar®, Tungsten Carbide Shaft, 6 Magnet, HiRes

52, 60, 61, 86

100036 Rotor w/ Shaft, PVDF, Kynar®, Ceramic Shaft, 6 Magnet, Hi-Res 52, 60, 61, 86, 87

100043 Rotor Repair Kit, IP, Ceramic Shaft 52, 60, 61

100059 Brass Adapter Fitting, NPT Thread, 1-1/2″, 2pc, Old Style 42, 60

100061 Collar, Locking, Brass 43, 61

100062 Cap, Blind, Brass IP/TX 25, 43, 61

100063 Cap, Blind, SS, IP 43, 61

100064 Nut, Compression, Brass 42, 43, 60, 61

100068 Housing, Rotor, Brass, IP 60, 61

100069 Valve Assy, Brass, Hot-Tap 25, 43, 61

100082 SS Adapter Fitting, NPT Thread, 1-1/2″, 2pc, OldStyle 42, 60

100084 Nut, Compression, SS 42, 43, 60, 61

100116 Collar, Locking, SS 43, 61

100118 Housing, Rotor, 316 SS, IP 60, 61

100119 Valve Assy, 316 SS, Hot-Tap 25, 43, 61

100152 Rotor & Bearings Assy, WT, Kynar® 67

100154 U-Clip, Retainer 18, 34, 52, 67

100214 O-Ring, EPDM 67

100218 Rotor Housing O-Ring, EPDM 42, 43, 60, 61

100219 O-Ring, Viton®, Brown 18, 34, 52

100248 Cap, Blind, PVC, EX/IP/TX80 series 18, 34, 52

100249 Cap, Blind, Polypro, EX/IP/TX80 series 18, 34, 52

100250 Cap, Blind, SS, EX/IP/TX80 series 18, 34, 52

100251 Cap, Blind, Brass, EX/IP/TX 80 Series 18, 34, 52

100262 Flange, Blanking, SS, 3-8″ 67

100264 O-Ring, EPDM, Black 18, 34, 52, 67, 86, 87

100270 O-Ring, EPDM 67

100298 Sensor Retaining Screw 34, 52, 67

100317 Rotor Repair Kit, IP, Carbide Shaft (Rotor, Bearings, Shaft) 52, 60, 61

100324 Rotor Repair Kit, TX, Polypro, (Rotor, Bearings, Carbide Shaft) 34, 42, 43

100325 Rotor Repair Kit, TX, Kynar®, Ceramic Shaft (Rotor, Bearings, Shaft) 34, 42, 43, 67

100326 Rotor, Polypro, Carbide Shaft 34, 42, 43

100327 Rotor, Kynar®, Ceramic Shaft 34, 42, 43, 67

100333 Rotor Repair Kit, WT, PVDF, Ceramic Shaft (100152 & 100227) 67

100339 Housing, Rotor, Brass, TX 42, 43

100340 Housing, Rotor, 316 SS, TX 42, 43

100345 O-Ring, EPDM 25, 42, 43, 60, 61

100358 Compression Ferrule, Kynar® 42, 43, 60, 61

100360 Plug, Steel, 1/2″ 42, 43, 60, 61, 67

100364 Cord Grip 1/4″ I.D. 7, 8, 42, 43, 60, 61, 67

100372 Tool, Bearing Removal, SPX/SPT/SES 86, 87

100373 Battery, Lithium, 3.6V, 8.5Ah, C Size 7, 67

100374 Mandrel, Rotor Housing, Tool, IP/TX 42, 43, 60, 61

100375 Spanner Tool, Sensor, Retain Screw 34, 52, 67

100384 Adapter, Brass, Hot-Tap, NPT Thread 43, 61

100385 Adapter, 316 SS, Hot-Tap, NPT Thread 43

100411 Gasket, Upper Housing 7, 18, 25, 42, 43, 60, 61, 67

100414 Screw/Washer Kit, Upper housing (Qty 4) 7, 8, 18, 25, 42, 43, 60, 61, 67

100419 Sensor Assy, Blue, Low Power, 18′ (For External Powered Displays) 34, 42, 43, 52, 60, 61, 67, 86, 87

2014 Industrial  List V2 Page 97 January 01, 2014

Rev. 050114

100437 Insert Assy, WTP 2″ 67

100438 Insert Assy, WTP 3″ 67

100439 Insert Assy, WTP100-4″ to 6″ 67

100440 Insert Assy, WTS, 3″ to 8″ 67

100469 FT415 Replacement Module 7, 67

100470 PD10 Replacement Module 9

100471 AO55 Replacement Module 8, 67

100495 FT420 Replacement Module 7, 67

100508 Sensor Assy, Grey Micropowered, 18′ (For Battery Powered Displays) 34, 42, 43, 52, 60, 61, 67, 86, 87

100545 FT420-65 Replacement Module, For 110 Vac 7

100557 PCA, FT420/421 Relay Option, w/ Wire and Tape 7

100582 Reed Switch, WJ Series 76

100661 Rotor Repair Kit, WT, Carbide Shaft (11152 & 100660) 67

100662 Housing Assy, Upper, Blind (Gasket, Screws, Washers, Label) 18, 25, 42, 43, 60, 61, 67

100701 Lid Assy, SEB-050/075 86

100845 Brass Adapter Fitting, NPT Thread, 1-1/2″ 42, 60

100846 SS Adapter Fitting, NPT Thread, 1-1/2″ 42, 60

100876 (1) Grounding Ring, AG/WMX-400 74

100877 (1) Grounding Ring, AG/WMX-600 74

100878 (1) Grounding Ring, AG/WMX-800 74

100879 (1) Grounding Ring, AG/WMX-1000 74

100889 Battery Pack, Lithium, 3.6V, 19Ah, 2-D Cell 74

100973 O-Ring, Viton® Teflon Coated 86, 87

100980 Sensor, Single Reed Switch 78, 79, 82

100993 Sensor, Dual Reed Switch 78, 79, 82

100997 Register MJ, GAL, 3/4″ 78, 82

100998 Register MJ, GAL, 1″ 78, 82

100999 Register MJ, GAL, 1-1/2″ 78, 82

101000 Register MJ, 2″ 79, 83

101004 Lens, MJ 3/4″ to 2″ 78, 79, 82

101006 Register MJ, CF, 3/4″ 78, 82

101007 Register MJ, CF, 1″ 78, 82

101008 Register MJ, CF, 1-1/2″ 78, 82

101009 Register MJ CF, 2″ 79, 83

101013 Gasket, Register Chamber MJ, 3/4″ 78, 82

101016 Strainer, Internal, MJ, 3/4″ 78, 82

101027 Gasket, Register Chamber MJ, 1″ 78, 82

101029 Strainer, Tubular, MJ, 3/4″ 78, 82

101030 Strainer, Tubular, MJ, 1″ 78, 82

101031 Strainer, Tubular, MJ, 1-1/2″ 78, 82

101032 Strainer, Tubular, MJ, 2″ 79, 83

101043 Strainer, Internal, MJ 1″ 78, 82

101044 Strainer, Internal, MJ, 1-1/2″ and 2″ 78, 79, 82, 83

101045 Screw, MJ, Sensor 78, 79, 82

101065 Sensor Assy, Single Hall Effect 78, 79, 82

101068 Lid & Hinge Pin Assy, MJ, 3/4″ 78, 82

101069 Lid & Hinge Pin Assy, MJ, 1″ 78, 82

101070 Lid & Hinge Pin Assy, MJ, 1-1/2″ & 2″ 78, 79, 82, 83

101071 Gasket Assy, Lens 3/4″ 78, 82

101072 Gasket Assy, Lens 1″ 78, 82

101073 Internal Assy, Gal., MJ, 3/4″ 78, 82

101074 Internal Assy, Gal., MJ, 1″ 78, 82

101075 Internal Assy, Gal., MJ, 1-1/2″ 78, 82

101076 Internal Assembly, Gal., MJ, 2″ 79, 83

2014 Industrial  List V2 Page 98 January 01, 2014

Rev. 050114

101077 Internal Assy, CF, MJ, 3/4″ 78, 82

101078 Internal Assy, CF., MJ, 1″ 78, 82

101079 Internal Assy, CF., MJ, 1-1/2″ 78, 82

101080 Internal Assembly, CF., MJ, 2″ 79, 83

101081 Coupling Assy Gasket (2-pieces), 3/4″ 78, 82

101082 Coupling Assy Gasket (2-pieces), 1″ 78, 82

101083 Coupling Assy Gasket (2-pieces), 1-1/2″ 78, 82

101084 Coupling Assembly Gasket (2-pieces), 2″ 79, 83

101085 Gasket Assy, Lens 1-1/2″ & 2″ 78, 79, 82, 83

101222 Kit, 2″ WMP FNPT Flange Clamps 70

101294 Magnet, 4 Poles MJR 78, 82

101301 Coupling Set W/Gaskets, MJ, 3/4″ 78, 82

101302 Coupling Set W/Gaskets, MJ, 1″ 78, 82

101303 Coupling Set W/Gaskets, MJ, 1-1/2″ 78, 82

101304 Coupling Set W/Gasket, MJ, 2″ 79, 83

101317 Battery Pack, Lithium, 3.6V, 2.4mAh, 2-AA Cell 74

101324 Coupling Assy Gasket (2-pieces), MJH, 3/4″ 79

101325 Coupling Assy Gasket (2-pieces), MJH 1″ 79

101326 Coupling Gasket (2-pieces), MJH, 1-1/2″ 80

101327 Coupling Gasket (2-pieces), MJH, 2″ 80

101328 Coupling Set W/Gasket, MJH, 3/4″ 79

101329 Coupling Set W/Gasket, MJH, 1″ 79

101330 Coupling Set W/Gasket, MJH, 1-1/2″ 80

101331 Coupling Set W/Gasket, MJH, 2″ 80

101332 Gasket Assy, Lens MJH, 3/4″ 79

101333 Gasket Assy, Lens MJH, 1″ 79

101334 Gasket Assy, Lens MJH, 1-1/2″ and 2″ 80

101339 Gasket, Register Chamber MJH, 3/4″ 79

101340 Gasket, Register Chamber MJH, 1″ 79

101341 Gasket, Register Chamber MJH, 1-1/2″ and 2″ 80

101346 Internal Assy, CF., MJH, 3/4″ 79

101347 Internal Assy, CF., MJH, 1″ 79

101348 Internal Assy, CF., MJH, 1-1/2″ 80

101349 Internal Assy, CF., MJH, 2″ 80

101350 Internal Assy, Gal., MJH, 3/4″ 79

101351 Internal Assy, Gal., MJH, 1″ 79

101352 Internal Assy, Gal., MJH, 1-1/2″ 80

101353 Internal Assy, Gal., MJH, 2″ 80

101354 Lid & Hinge Pin Assy, MJH, 3/4″ 79

101355 Lid & Hinge Pin Assy, MJH, 1″ 79

101356 Lid & Hinge Pin Assy, MJH, 1-1/2″ 80

101368 Register, MJH CF, 3/4″ 79

101369 Register, MJH CF, 1″ 79

101370 Register, MJH CF, 1-1/2″ 80

101371 Register, MJH CF, 2″ 80

101372 Register, MJH, GAL, 3/4″ 79

101373 Register, MJH, GAL, 1″ 79

101374 Register, MJH, GAL, 1-1/2″ 80

101375 Register, MJH, GAL, 2″ 80

101379 Strainer, Internal, MJH, 3/4″ 79

101380 Strainer, Internal, MJH, 1″ 79

101381 Strainer, Internal, MJH, 1-1/2″ and 2″ 80

101382 Strainer, Tubular, MJH, 3/4″ 79

101383 Strainer, Tubular, MJH, 1″ 79

2014 Industrial  List V2 Page 99 January 01, 2014

Rev. 050114

101384 Strainer, Tubular, MJH, 1-1/2″ 80

101385 Strainer, Tubular, MJH, 2″ 80

101442 Insert Assy, WTC, 3″-8″ 67

101443 Flange, Blanking, Carbon Steel, 3″-8″ 67

101446 Insert Assy, WTC/WTS 2″ 67

101492 Cordset, 5 Pin, 6 Meter, Power/Output Cable for WMP101 70

101516 Lid & Hinge Pin Assy, WJ Series 76

101594 Replacement Batteries, WMP, 2 C-Cell (WMP104 only) 70

101621 Equalization Cable, AG/WMX-400 74

101622 Equalization Cable, AG/WMX-600/800 74

101623 Equalization Cable, AG/WMX-1000/1200 74

101850 Cord Grip, 1/2″ NPT 7, 8, 18, 25, 34, 42, 43, 52, 60, 61,

67 101862 Rotor Assy, Kynar® w/ Carbide Shaft, TX 34, 42, 43, 67

101868 Housing, Rotor, Brass, TX 42, 43

101869 Housing, Rotor, 316 SS, TX 42, 43

101912 Rotor Repair Kit, TX, Kynar®, Carbide Shaft (Rotor, Bearings, Shaft) 34, 43, 67

101949 Hinged Display Cover 70, 74

102073 Kit, 3″ WMP FNPT Flange Clamps 70

102157 Grounding Ring, AG/WMX-300 74

102203 Kit, 2″, WMP BSP Flange Clamps (Male Thread) 70

102204 Kit, 3″, WMP BSP Flange Clamps (Male Thread) 70

102228 O-Ring, Buna-N, 70-Duro, MJ, 1-1/2″ and 2″ 78, 79, 82, 83

103254 PE102-038 PVDF Adapter Kit, 1/4″ MNPT, EPDM O-Ring (101688 &

101684)

89

103255 PE102-038 PVDF Adapter Kit, 1/4″ MNPT Viton® O-Ring (101688 &

101685)

89

103256 PE102-038 PP Adapter Kit, 1/4″ MNPT EPDM O-Ring (103014 &

101684)

89

103257 PE102-038 PP Adapter Kit, 1/4″ MNPT Viton® O-Ring (103014 &

101685)

89

103258 PE102-038 PVDF Adapter Kit, 3/8″ MNPT EPDM O-Ring (101672 &

101684)

89

103259 PE102-038 PVDF Adapter Kit, 3/8″ MNPT Viton® O-Ring (101672 &

101685)

89

103260 PE102-038 PP Adapter Kit, 3/8″ MNPT EPDM O-Ring (103013 &

101684)

89

103261 PE102-038 PP Adapter Kit, 3/8″ MNPT Viton® O-Ring (103013 &

101685)

89

103262 PE102-038 PVDF Adapter Kit, 1/2″ MNPT EPDM O-Ring (101940 &

101684)

89

103263 PE102-038 PVDF Adapter Kit, 1/2″ MNPT Viton® O-Ring (101940 &

101685)

89

103264 PE102-038 PVDF Adapter Kit, 1/2″ FNPT EPDM O-Ring (102180 &

101684)

89

103270 PE102-075 PVDF Adapter Kit, 1/2″ MNPT EPDM O-Ring (101396 &

100996)

89

103271 PE102-075 PVDF Adapter Kit, 1/2″ MNPT Viton® O-Ring (101396 &

101290)

89

103272 PE102-075 PP Adapter Kit, 1/2″ MNPT EPDM O-Ring (103016 &

100996)

89

103273 PE102-075 PP Adapter Kit, 1/2″ MNPT Viton® O-Ring (103016 &

101290)

89

103274 PE102-075 PVDF Adapter Kit, 1/2″ FNPT EPDM O-Ring (102181 &

100996)

89

103275 PE102-075 PVDF Adapter Kit, 1/2″ FNPT Viton® O-Ring (102181

&101290)

89

103276 PE102-075 PP Adapter Kit, 1/2″ FNPT EPDM O-Ring (103012

&100996)

89

103277 PE102-075 PP Adapter Kit, 1/2″ FNPT Viton® O-Ring (103012 &

101290)

89

103278 PE102-075 PVDF Adapter Kit, 3/4″ MNPT EPDM O-Ring (101252 &

100996)

89

103308 Kit, Capscrew 10-32 x 2″, Socket Head, SS 87

103309 Kit, 1/4-20 x 1″ M/S, SS, WT 67

103310 Kit, Nut 10-32 Hex, SS 87

103311 Kit, Gasket Coupling Fiber, 0.625″ 86

103312 Kit, Shaft Assembly, Ceramic, WT/TX 34, 42, 43, 67

103313 Bearing Assembly Kit, SPX/SPT/SES 86, 87

103315 Bearing Assembly Kit, IP/TX, Kynar 34, 42, 43, 52, 60, 61

103316 Gasket Kit, Coupling, Fiber, SEB, 3/4″ 86

103317 Shaft Assy Kit, Carbide, WT 3″ to 8″ 67

103318 Screw Kit, 1/4-20 x 0.625″, SH, SS 86

103324 Strain Relief Kit, .069″ to .25″ Cable 7

103325 Coupling Assy, Brass, SEB-050 86

2014 Industrial  List V2 Page 100 January 01, 2014

Rev. 050114

103326 Coupling Assy, Brass, SEB-075 86

DC100 Field-Installed Power/Output Cable, 30M (100 ft) 74

DC30 Field-Installed Power/Output Cable, 6m (20 ft) 74

DC30S Field-Installed Power/Output Cable, 6m (20 ft) 74

DC35 Field-Installed Power/Output Cable, 15m (50 ft) 74

DC35S Field-Installed Power/Output Cable, 15m (50 ft) 74

EF81T-B-100 Tee Fitting, Bronze, Threaded, 1″, EX 15

EF81T-B-150 Tee Fitting, Bronze, Threaded, 1-1/2″, EX 15

EF81T-B-200 Tee Fitting, Bronze, Threaded, 2″, EX 15

EF81T-B-300 Tee Fitting, Bronze, Threaded, 3″, EX 15

EF81T-B-400 Tee Fitting, Bronze, Threaded, 4″, EX 15

EF81T-C-100 Tee Fitting, Carbon Steel, 1″, EX 15

EF81T-C-150 Tee Fitting, Carbon Steel, 1-1/2″, EX 15

EF81T-C-200 Tee Fitting, Carbon Steel, 2″, EX 15

EF81T-C-200-34 Tee Fitting, Carbon Steel, Flanged Ends, 2″, EX 15

EF81TC-B-100 Tee Fitting, Bronze, Sweat, 1″, EX 15

EF81TC-B-150 Tee Fitting, Bronze, Sweat, 1-1/2″, EX 15

EF81TC-B-200 Tee Fitting, Bronze, Sweat, 2″, EX 15

EF81TC-B-300 Tee Fitting, Bronze, Sweat, 3″, EX 15

EF81TC-B-400 Tee Fitting, Bronze, Sweat, 4″, EX 15

EF81T-P-100 Tee Fitting, PVC, 1″, EX 15

EF81T-P-150 Tee Fitting, PVC, 1-1/2″, EX 15

EF81T-P-200 Tee Fitting, PVC, 2″, EX 15

EF81T-P-200-18 Tee Fitting, PVC, Flanged Ends, 2″,EX 15

EF81T-S-100 Tee Fitting, 304 SS, 1″,EX 15

EF81T-S-100-14 Tee Fitting, 316 SS, 1″,EX 15

EF81T-S-150 Tee Fitting, 304 SS, 1-1/2″, EX 15

EF81T-S-150-14 Tee Fitting, 316 SS , 1-1/2″, EX 15

EF81T-S-200 Tee Fitting, 304 SS, 2″, EX 15

EF81T-S-200-14 Tee Fitting, 316 SS, 2″, EX 15

EF81T-S-200-20 Tee Fitting, 304 SS, Flanged Ends, 2″, EX 15

EF82S-B-300 Saddle, Bronze, 3″, EX 16

EF82S-B-400 Saddle, Bronze, 4″, EX 16

EF82S-F-1000 Saddle, Iron, 10″, EX 16

EF82S-F-1200 Saddle, Iron, 12″, EX 16

EF82S-F-300 Saddle, Iron, 3″, EX 16

EF82S-F-400 Saddle, Iron, 4″, EX 16

EF82S-F-600 Saddle, Iron, 6″, EX 16

EF82S-F-800 Saddle, Iron, 8″, EX 16

EF82S-P-300 Saddle, PVC, 3″, EX 16

EF82S-P-300-16 Saddle, PVC, 3″, w/ 16″ Pipe Stub, EX 16

EF82S-P-400 Saddle, PVC, 4″, EX 16

EF82S-P-400-16 Saddle, PVC, 4″, w/ 16″ Pipe Stub, EX 16

EF82S-P-600 Saddle, PVC, 6″, EX 16

EF82S-P-600-16 Saddle, PVC, 6″, w/ 16″ Pipe Stub, EX 16

EF82S-P-800 Saddle, PVC, 8″, EX 16

EF82S-P-800-16 Saddle, PVC, 8″, w/ 16″ Pipe Stub, EX 16

EF82W-B-1000 Weldolet, Brass, 10″, EX 17

EF82W-B-1200 Weldolet, Brass, 12″, EX 17

EF82W-B-300 Weldolet, Brass, 3″, EX 17

EF82W-B-400 Weldolet, Brass, 4″, EX 17

EF82W-B-600 Weldolet, Brass, 6″, EX 17

EF82W-B-800 Weldolet, Brass, 8″, EX 17

EF82W-C-1000 Weldolet, Carbon Steel, 10″, EX 17

2014 Industrial  List V2 Page 101 January 01, 2014

Rev. 050114

EF82W-C-1200 Weldolet, Carbon Steel, 12″, EX 17

EF82W-C-300 Weldolet, Carbon Steel, 3″, EX 17

EF82W-C-400 Weldolet, Carbon Steel, 4″, EX 17

EF82W-C-600 Weldolet, Carbon Steel, 6″, EX 17

EF82W-C-800 Weldolet, Carbon Steel, 8″, EX 17

EF82W-S-1000 Weldolet, 316 SS, 10″, EX 17

EF82W-S-1200 Weldolet, 316 SS, 12″, EX 17

EF82W-S-300 Weldolet, 316 SS, 3″, EX 17

EF82W-S-400 Weldolet, 316 SS, 4″, EX 17

EF82W-S-600 Weldolet, 316 SS, 6″, EX 17

EF82W-S-800 Weldolet, 316 SS, 8″, EX 17

MF101B-300-150 Saddle, Bronze, NPT Thread, 3″ X 1-1/2″ 24, 41, 59

MF101B-300-200 Saddle, Bronze, NPT Thread, 3″ X 2″ 24, 41, 59

MF101B-400-150 Saddle, Bronze, NPT Thread 4″ X 1-1/2″ 24, 41, 59

MF101B-400-200 Saddle, Bronze, NPT Thread, 4″ X 2″ 24, 41, 59

MF101F-1000-150 Saddle, Iron, NPT Thread, 10″ X 1-1/2″ 24, 41, 59

MF101F-1000-200 Saddle, Iron, NPT Thread, 10″ X 2″ 24, 41, 59

MF101F-1200-150 Saddle, Iron, NPT Thread, 12″ X 1-1/2″ 24, 41, 59

MF101F-1200-200 Saddle, Iron, NPT Thread, 12″ X 2″ 24, 41, 59

MF101F-1400-150 Saddle, Iron, NPT Thread, 14″ X 1-1/2″ 24, 41, 59

MF101F-1400-200 Saddle, Iron, NPT Thread, 14″ X 2″ 24, 41, 59

MF101F-1600-150 Saddle, Iron, NPT Thread, 16″ X 1-1/2″ 24, 41, 59

MF101F-1600-200 Saddle, Iron, NPT Thread, 16″ X 2″ 24, 41, 59

MF101F-1800-150 Saddle, Iron, NPT Thread, 18″ X 1-1/2″ 24, 41, 59

MF101F-1800-200 Saddle, Iron, NPT Thread, 18″ X 2″ 24, 41, 59

MF101F-2000-150 Saddle, Iron, NPT Thread, 20″ X 1-1/2″ 24, 41, 59

MF101F-2000-200 Saddle, Iron, NPT Thread, 20″ X 2″ 24, 41, 59

MF101F-2200-150 Saddle, Iron, NPT Thread, 22″ X 1-1/2″ 24, 41, 59

MF101F-2200-200 Saddle, Iron, NPT Thread, 22″ X 2″ 24, 41, 59

MF101F-2400-150 Saddle, Iron, NPT Thread, 24″ X 1-1/2″ 24, 41, 59

MF101F-2400-200 Saddle, Iron, NPT Thread, 24″ X 2″ 24, 41, 59

MF101F-300-150 Saddle, Iron, NPT Thread, 3″ X 1-1/2″ 24, 41, 59

MF101F-300-200 Saddle, Iron, NPT Thread, 3″ X 2″ 24, 41, 59

MF101F-400-150 Saddle, Iron, NPT Thread, 4″ X 1-1/2″ 24, 41, 59

MF101F-400-200 Saddle, Iron, NPT Thread, 4″ X 2″ 24, 41, 59

MF101F-600-150 Saddle, Iron, NPT Thread, 6″ X 1-1/2″ 24, 41, 59

MF101F-600-200 Saddle, Iron, NPT Thread, 6″ X 2″ 24, 41, 59

MF101F-800-150 Saddle, Iron, NPT Thread, 8″ X 1-1/2″ 24, 41, 59

MF101F-800-200 Saddle, Iron, NPT Thread, 8″ X 2″ 24, 41, 59

MF81T-B-050 Tee Fitting, Bronze, 1/2″, Threaded, IP 49

MF81T-B-075 Tee Fitting, Bronze, 3/4″, Threaded, IP 49

MF81T-B-100 Tee Fitting, Bronze, 1″, Threaded, IP 49

MF81T-B-150 Tee Fitting, Bronze, 1-1/2″, Threaded, IP 49

MF81T-B-200 Tee Fitting, Bronze, 2″, Threaded, IP 49

MF81T-B-300 Tee Fitting, Bronze, 3″, Threaded, IP 49

MF81T-B-400 Tee Fitting, Bronze, 4″, Threaded, IP 49

MF81T-C-050 Tee Fitting, Carbon Steel, 1/2″, IP 49

MF81T-C-050-HP Tee Fitting, Carbon Steel, Hi Pres, 1/2″, IP 49

MF81T-C-075 Tee Fitting, Carbon Steel, 3/4″, IP 49

MF81T-C-075-HP Tee Fitting, Carbon Steel, Hi Pres, 3/4″, IP 49

MF81T-C-100 Tee Fitting, Carbon Steel, 1″, IP 49

MF81T-C-100-HP Tee Fitting, Carbon Steel, Hi Pres, 1″, IP 49

MF81T-C-150 Tee Fitting, Carbon Steel, 1-1/2″, IP 49

MF81T-C-150-HP Tee Fitting, Carbon Steel, Hi Pres, 1-1/2″, IP 49

2014 Industrial  List V2 Page 102 January 01, 2014

Rev. 050114

MF81T-C-200 Tee Fitting, Carbon Steel, 2″, IP 49

MF81T-C-200-34 Tee Fitting, Carbon Steel, Flanged Ends, 2″, IP 49

MF81T-C-200-HP Tee Fitting, Carbon Steel, Hi Pres, 2″, IP 49

MF81TC-B-050 Tee Fitting, Bronze, Sweat, 1/2″, IP 49

MF81TC-B-075 Tee Fitting, Bronze, Sweat, 3/4″, IP 49

MF81TC-B-100 Tee Fitting, Bronze, Sweat, 1″, IP 49

MF81TC-B-150 Tee Fitting, Bronze, Sweat, 1-1/2″, IP 49

MF81TC-B-200 Tee Fitting, Bronze, Sweat, 2″, IP 49

MF81TC-B-300 Tee Fitting, Bronze, Sweat, 3″, IP 49

MF81TC-B-400 Tee Fitting, Bronze, Sweat, 4, IP 49

MF81T-P-050 Tee Fitting, PVC, 1/2″, IP 49

MF81T-P-075 Tee Fitting, PVC, 3/4″, IP 49

MF81T-P-100 Tee Fitting, PVC, 1″, IP 49

MF81T-P-150 Tee Fitting, PVC, 1-1/2″, IP 49

MF81T-P-200 Tee Fitting, PVC, 2″, IP 49

MF81T-P-200-18 Tee Fitting, PVC, Flanged Ends, 2″, IP 49

MF81T-S-050 Tee Fitting, 304 SS, 1/2″, IP 50

MF81T-S-050-14 Tee Fitting, 316 SS, 1/2″, IP 50

MF81T-S-050-14-HP Tee Fitting, 316 SS, Hi Pres, 1/2″, IP 50

MF81T-S-050-HP Tee Fitting, 304 SS, Hi Pres, 1/2″, IP 50

MF81T-S-075 Tee Fitting, 304 SS, 3/4″, IP 50

MF81T-S-075-14 Tee Fitting, 316 SS, 3/4″, IP 50

MF81T-S-075-14-HP Tee Fitting, 316 SS, Hi Pres, 3/4″, IP 50

MF81T-S-075-HP Tee Fitting, 304 SS, Hi Pres, 3/4″, IP 50

MF81T-S-100 Tee Fitting, 304 SS, 1″, IP 50

MF81T-S-100-14 Tee Fitting, 316 SS, 1″, IP 50

MF81T-S-100-14-HP Tee Fitting, 316 SS, Hi Pres, 1″, IP 50

MF81T-S-100-HP Tee Fitting, 304 SS, Hi Pres, 1″, IP 50

MF81T-S-150 Tee Fitting, 304 SS, 1-1/2″, IP 50

MF81T-S-150-14 Tee Fitting, 316 SS, 1-1/2″, IP 50

MF81T-S-150-14-HP Tee Fitting, 316 SS, Hi Pres, 1-1/2″, IP 50

MF81T-S-150-HP Tee Fitting, 304 SS, Hi Pres, 1-1/2″, IP 50

MF81T-S-200 Tee Fitting, 304 SS, 2″, IP 50

MF81T-S-200-14 Tee Fitting, 316 SS, 2″, IP 50

MF81T-S-200-14-HP Tee Fitting, 316 SS, Hi Pres, 2″, IP 50

MF81T-S-200-20 Tee Fitting, 304 SS, 2″, Flanged Ends, IP 50

MF81T-S-200-HP Tee Fitting, 304 SS, Hi Pres, 2″, IP 50

MF82S-B-300 Saddle, Bronze, 3″ 32, 50

MF82S-B-400 Saddle, Bronze, 4″ 32, 50

MF82S-F-300 Saddle, Iron, 3″ 32, 50

MF82S-F-400 Saddle, Iron, 4″ 32, 50

MF82S-F-600 Saddle, Iron, 6″ 32, 50

MF82S-F-800 Saddle, Iron, 8″ 32, 50

MF82S-P-300 Saddle, PVC, 3″ 32, 50

MF82S-P-300-16 Saddle, PVC, 3″, w/ 16″ Pipe Stub 32, 50

MF82S-P-400 Saddle, PVC, 4″ 32, 50

MF82S-P-400-16 Saddle, PVC, 4″, w/ 16″ Pipe Stub 32, 50

MF82S-P-600 Saddle, PVC, 6″ 32, 50

MF82S-P-600-16 Saddle, PVC, 6″, w/ 16″ Pipe Stub 32, 50

MF82S-P-800 Saddle, PVC, 8″ 32, 50

MF82S-P-800-16 Saddle, PVC, 8″, w/ 16″ Pipe Stub 32, 50

MF82W-B-300 Weldolet, Brass, 3″ 33, 51

MF82W-B-400 Weldolet, Brass, 4″ 33, 51

MF82W-B-600 Weldolet, Brass, 6″ 33, 51

2014 Industrial  List V2 Page 103 January 01, 2014

Rev. 050114

MF82W-B-800 Weldolet, Brass, 8″ 33, 51

MF82W-C-300 Weldolet, Carbon Steel, 3″ 33, 51

MF82W-C-300-HP Weldolet, Carbon Steel, Hi Pres, 3″ 33, 51

MF82W-C-400 Weldolet, Carbon Steel, 4″ 33, 51

MF82W-C-400-HP Weldolet, Carbon Steel, Hi Pres, 4″ 33, 51

MF82W-C-600 Weldolet, Carbon Steel, 6″ 33, 51

MF82W-C-600-HP Weldolet, Carbon Steel, Hi Pres, 6″ 33, 51

MF82W-C-800 Weldolet, Carbon Steel, 8″ 33, 51

MF82W-C-800-HP Weldolet, Carbon Steel, Hi Pres, 8″ 33, 51

MF82W-S-300 Weldolet, 316 SS, 3″ 33, 51

MF82W-S-300-HP Weldolet, 316 SS, Hi Pres, 3″ 33, 51

MF82W-S-400 Weldolet, 316 SS, 4″ 33, 51

MF82W-S-400-HP Weldolet, 316 SS, Hi Pres, 4″ 33, 51

MF82W-S-600 Weldolet, 316 SS, 6″ 33, 51

MF82W-S-600-HP Weldolet, 316 SS, Hi Pres, 6″ 33, 51

MF82W-S-800 Weldolet, 316 SS, 8″ 33, 51

MF82W-S-800-HP Weldolet, 316 SS, Hi Pres, 8″ 33, 51

TF81T-B-150 Tee Fitting, Bronze, Threaded, 1-1/2″, TX 31

TF81T-B-200 Tee Fitting, Bronze, Threaded, 2″, TX 31

TF81T-B-300 Tee Fitting, Bronze, Threaded, 3″, TX 31

TF81T-B-400 Tee Fitting, Bronze, Threaded, 4″, TX 31

TF81T-C-150 Tee Fitting, Carbon Steel, 1-1/2″, TX 31

TF81T-C-150-HP Tee Fitting, Carbon Steel, Hi Pres, 1-1/2″, TX 31

TF81T-C-200 Tee Fitting, Carbon Steel, 2″, TX 31

TF81T-C-200-HP Tee Fitting, Carbon Steel, Hi Pres, 2″, TX 31

TF81TC-B-150 Tee Fitting, Bronze, Sweat, 1-1/2″, TX 31

TF81TC-B-200 Tee Fitting, Bronze, Sweat, 2″, TX 31

TF81TC-B-300 Tee Fitting, Bronze, Sweat, 3″, TX 31

TF81TC-B-400 Tee Fitting, Bronze, Sweat, 4″, TX 31

TF81T-P-150 Tee Fitting, PVC, 1-1/2″, TX 31

TF81T-P-200 Tee Fitting, PVC, 2″, TX 31

TF81T-S-150 Tee Fitting, 304 SS, 1-1/2″, TX 31

TF81T-S-150-14 Tee Fitting, 316 SS, 1-1/2″, TX 31

TF81T-S-150-14-HP Tee Fitting, 316 SS, Hi Pres, 1-1/2″, TX 31

TF81T-S-150-HP Tee Fitting, 304 SS, Hi Pres, 1-1/2″, TX 31

TF81T-S-200 Tee Fitting, 304 SS, 2″, TX 31

TF81T-S-200-14 Tee Fitting, 316 SS, 2″, TX 31

TF81T-S-200-14-HP Tee Fitting, 316 SS, Hi Pres, 2″, TX 31

TF81T-S-200-HP Tee Fitting, 304 SS, Hi Pres, 2″, TX 31
